POSIFLEX PP6800 Manual

COMMAND DETAILS
CODES
(HEX/CONTROL):
NAME:
Horizontal tab
FUNCTION:
EXPLANATION:
1. If all horizontal tab position has been cleared by {ESC} D {NUL}, this command
is ignored.
2. The default setting of the horizontal tab positions are set at every 8th character
(9th, 17th, 25th, ...column).
3. If there is no more horizontal tab position set to the right of the print position
within the printing area, this command advances print position to the beginning of
next line.
4. Horizontal tab positions can be set with {ESC} D command. When horizontal tab
positions are set in font A (12 x 24) characters printing mode, switching into font
B (8 x 16) characters mode the tab positions will still align to that in font A
printing.
5. Horizontal tab positions can be reset to default values with {ESC} @.
6. Since the printer executes print buffer-full printing when print data before a {LF}
received exceeds a line's worth, if this command is received when the printing
position is already at next line the horizontal tab processing is executed from the
beginning of this next line.
CODES
(HEX/CONTROL):
NAME:
Print and line feed
FUNCTION:
PP6800/PP8000
<09> / {HT}
Moves the print position to the next horizontal tab
position
<0A> / {LF}
Print data in print buffer and feed one line
PP6000 Command Details - Page 1
