  • Page 1 RAMPAGE V EDITION 10...
  • Page 2 Product warranty or service will not be extended if: (1) the product is repaired, modified or altered, unless such repair, modification of alteration is authorized in writing by ASUS; or (2) the serial number of the product is defaced or missing.

  • Page 3: Table Of Contents

    Contents Safety information ...................... vi About this guide ......................vii RAMPAGE V EDITION 10 specifications summary ..........ix SupremeFX Hi-Fi specifications summary ............. xv Package contents ..................... xvi Installation tools and components ................ xvii Chapter 1: Product Introduction Motherboard overview ................1-1 1.1.1...
  • Page 4 Monitor menu ................... 3-25 Boot menu ....................3-26 Tool menu ....................3-28 3.9.1 GPU Post .................. 3-28 3.9.2 ASUS EZ Flash 3 Utility ............3-28 3.9.3 Secure Erase ................3-29 3.9.4 ASUS Overclocking Profile ............3-30 3.9.5 ASUS SPD Information ............. 3-31 3.10...
  • Page 5 Rapid Storage Technology in UEFI BIOS ......4-2 ® 4.1.4 Intel Rapid Storage Technology Option ROM utility ....4-6 Creating a RAID driver disk ..............4-10 ® 4.2.1 Creating a RAID driver disk in Windows ......... 4-10 Appendix Notices ........................A-1 ASUS contact information ..................A-6...

  • Page 6: Safety Information

    Safety information Electrical safety • To prevent electrical shock hazard, disconnect the power cable from the electrical outlet before relocating the system. • When adding or removing devices to or from the system, ensure that the power cables for the devices are unplugged before the signal cables are connected. If possible, disconnect all power cables from the existing system before you add a device.

  • Page 7: About This Guide

    Refer to the following sources for additional information and for product and software updates. ASUS website The ASUS website ( ) provides updated information on ASUS hardware www.asus.com and software products. Optional documentation Your product package may include optional documentation, such as warranty flyers, that may have been added by your dealer.
  • Page 8 Conventions used in this guide To ensure that you perform certain tasks properly, take note of the following symbols used throughout this manual. DANGER/WARNING: Information to prevent injury to yourself when trying to complete a task. CAUTION: Information to prevent damage to the components when trying to complete a task.

  • Page 9: Rampage V Edition 10 Specifications Summary

    RAMPAGE V EDITION 10 specifications summary ® New Intel Core™ i7 X-Series Processors on LGA 2011-v3 Socket Supports 14nm CPU ® Supports Intel Turbo Boost Max Technology 3.0* * The support of these features depends on the CPU types. Chipset Intel ®...
  • Page 10 - 6 x USB 2.0 ports (2 ports at back panel [black], 4 ports at mid- board)** ASMedia USB 3.1 Controller - support ASUS USB 3.1 Boost: ® - 4 x USB 3.1 ports (2 x Type-A [red] and 2 x Type-C ports [black] at...
  • Page 11 RAMPAGE V EDITION 10 specifications summary Extreme Engine Digi+ - MicroFine Alloy Choke ® - IR3555 PoweIRstage - 10K Black Metallic Capacitors OC Zone - ReTry button - Safe Boot button - LN2 Mode header - Slow Mode switch - Start button...
  • Page 12 4 x USB 3.1 ports (2 x Type-C [black] and 2 x Type-A [red]) 2 x Anti-surge LAN (RJ45) ports Back Panel I/O Ports 1 x ASUS Wi-Fi GO! module (Wi-Fi 3x3 802.11 a/b/g/n/ac and Bluetooth v4.0) 1 x PS/2 keyboard/mouse combo port 2 x USB 2.0 ports [black]...
  • Page 13 1 x Thunderbolt header 128 Mb Flash ROM, UEFI AMI BIOS, PnP, WfM2.0, SM BIOS 3.0, ACPI 5.0, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, BIOS Features F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Quick Note, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information.
  • Page 14 RAMPAGE V EDITION 10 specifications summary Drivers ROG GameFirst Technology ROG RAMDisk ROG RAMCache ROG CPU-Z Software ROG Mem TweakIt AURA Kaspersky ® Anti-Virus ASUS WebStorage ASUS Utilities Operating Systems ® ® ® Windows 10 / Windows 8.1 / Windows...

  • Page 15: Supremefx Hi-Fi Specifications Summary

    SupremeFX Hi-Fi specifications summary 1 x ESS ES9018K2M SABRE DAC 2 x LM4562 Op amps Hardware 1 x TPA6120A2 Headphone amp 1 x Cirrus Logic CS5361 5 x RC4580 Op amps Supported formats: Up to 32-bit/384kHz and DSD 64/128* Output (32Ohms): 4.8VRMS (720mW RMS per channel) Output (600Ohms): 6.8VRMS (77mW RMS per channel) Headphone Output THD+N @ 1K (-3dB): -104dB (<0.0007%)

  • Page 16: Package Contents

    1 x 3-in-1 thermistor cables 1 x Wafer cable 1 x Cable for SupremeFX Hi-Fi 1 x AURA cable 1 x ASUS 3T3R dual band Wi-Fi moving antennas (Wi-Fi 802.11a/b/g/n/ac compliant) 1 x FAN Extension Card 1 x Q-Connector Kit...

  • Page 17: Installation Tools And Components

    Installation tools and components Intel LGA2011-v3 CPU ® Intel LGA2011-v3 compatible CPU Fan ® Phillips (cross) screwdriver SATA hard disk drive PC chassis 1 bag of screws DIMM Power supply unit SATA optical disc drive (optional) Graphics card The tools and components listed above are not included in the motherboard package. xvii...
  • Page 18 xviii...

  • Page 19: Chapter 1: Product Introduction

    • Before handling components, use a grounded wrist strap or touch a safely grounded object or a metal object, such as the power supply case, to avoid damaging them due to static electricity. • Hold components by the edges to avoid touching the ICs on them. • Whenever you uninstall any component, place it on a grounded antistatic pad or in the bag that came with the component. • Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. ASUS RAMPAGE V EDITION 10...

  • Page 20: Motherboard Layout

    1.1.2 Motherboard layout Refer to 1.1.9 Internal connectors and 2.3.1 Rear I/O Connection sections for more information about the internal connectors and rear panel connectors. Chapter 1: Product Introduction...
  • Page 21 1-12 ReTry button (RETRY_BUTTON) 1-11 ProbeIt 1-36 USB 3.0 connector (20-1 pin USB3_12; USB3_34) 1-27 M.2 (SOCKET3) 1-30 Intel X99 Serial ATA 6 Gb/s connectors (7-pin SATA6G_1-10) ® 1-25 U.2 connector (U.2) 1-35 SLI/CFX switch (SLI/CFX) 1-12 Thermal sensor cable connector (2-pin T_SENSOR1) 1-26 BIOS Switch button (BIOS_SWITCH) 1-11 System panel connector (20-3 pin PANEL) 1-34 Thunderbolt header (5-pin TB_HEADER) 1-29 USB 2.0 connector (10-1 pin USB1112, USB1314) 1-28 ROG Extension connector (18-1 pin ROG_EXT) 1-26 RGB header (4-pin RGB_HEADER) 1-31 TPM connector (14-1 pin TPM) 1-29 Front panel audio connector (10-1 pin AAFP) 1-30 ASUS RAMPAGE V EDITION 10...

  • Page 22: Central Processing Unit (Cpu)

    1.1.3 Central Processing Unit (CPU) The motherboard comes with a surface mount LGA2011-v3 socket designed for New Intel ® Core™ i7 X-Series Processors on LGA 2011-v3 socket. Ensure that all power cables are unplugged before installing the CPU. • Upon purchase of the motherboard, ensure that the PnP cap is on the socket and the socket contacts are not bent. Contact your retailer immediately if the PnP cap is missing, or if you see any damage to the PnP cap/socket contacts/motherboard components. ASUS will shoulder the cost of repair only if the damage is shipment/ transit-related. • Keep the cap after installing the motherboard. ASUS will process Return Merchandise Authorization (RMA) requests only if the motherboard comes with the cap on the LGA2011-v3 socket. • The product warranty does not cover damage to the socket contacts resulting from incorrect CPU installation/removal, or misplacement/loss/incorrect removal of the PnP cap. Chapter 1: Product Introduction...

  • Page 23: System Memory

    1.1.4 System memory The motherboard comes with eight (8) Double Data Rate 4 (DDR4) Dual Inline Memory Module (DIMM) slots. A DDR4 module is notched differently from a DDR3 or DDR2 module. DO NOT install a DDR3 or DDR2 memory module to the DDR4 slot. Recommended memory configurations ASUS RAMPAGE V EDITION 10...
  • Page 24 • The design of the DIMM fan may vary. Ensure that the DIMM fan fits to the motherboard. • The default memory operation frequency is dependent on its Serial Presence Detect (SPD), which is the standard way of accessing information from a memory module. Under the default state, some memory modules for overclocking may operate at a lower frequency than the vendor-marked value. To operate at the vendor-marked or at a higher frequency, refer to section 3.5 Extreme Tweaker menu for manual memory frequency adjustment. • For system stability, use a more efficient memory cooling system to support a full memory load (4 DIMMs) or overclocking condition. • Memory modules with memory frequency higher than 2133MHz and their corresponding timing or the loaded XMP profile is not the JEDEC memory standard. The stability and compatibility of the memory modules depend on the CPU’s capabilities and other installed devices. • Always install the DIMMS with the same CAS latency. For an optimum compatibility, we recommend that you install memory modules of the same version or data code (D/C) from the same vendor. Check with the vendor to get the correct memory modules. • ASUS exclusively provides hyper DIMM support function. • Hyper DIMM support is subject to the physical characteristics of individual CPUs. Load the X.M.P. or D.O.C.P. settings in the BIOS for the hyper DIMM support. • Visit the ASUS website for the latest QVL. Chapter 1: Product Introduction...

  • Page 25: Expansion Slots

    1.1.5 Expansion slots Ensure to unplug the power cord before adding or removing expansion cards. Failure to do so may cause you physical injury and damage motherboard components. Slot No. Slot Description PCIe 3.0 x16/x8_1 slot PCIe 3.0 x8_2 slot PCIe 2.0 x4_1 slot PCIe 3.0 x16/8_3 slot PCIe 2.0 x1_1 slot PCIe 3.0 x8_4 slot ASUS RAMPAGE V EDITION 10...
  • Page 26 • We recommend that you provide sufficient power when running CrossFireX™ or SLI ® mode. • While running at four heavy loaded VGA cards, ensure to plug in the 4-pin extra PCIe power supply for stability. Refer to the following configuration table for installation. PCIe 3.0 operating mode for 40 lanes CPU 3-way 4-way Slot # Single VGA SLI/CFX SLI/CFX SLI/CFX PCIEX16/X8_1 PCIEX8_2 — — PCIEX16/X8_3 — PCIEX8_4 — — — PCIe 3.0 operating mode for 28 lanes CPU 3-way SLI/ Slot # Single VGA...

  • Page 27: Onboard Buttons And Switches

    The button also lights up when the system is plugged to a power source indicating that you should shut down the system and unplug the power cable before removing or installing any motherboard component. RESET button Press the Reset button to reboot the system. ASUS RAMPAGE V EDITION 10...
  • Page 28 • Refer to the 1.1.7 Onboard LEDs section for the exact location of the DRAM_LED. • The DRAM_LED also lights up when the DIMM is not properly installed. Turn off the system and reinstall the DIMM before using the MemOK! function. • The MemOK! button does not function under Windows OS environment. ® • During the tuning process, the system loads and tests failsafe memory settings. It takes about 30 seconds for the system to test one set of failsafe settings. If the test fails, the system reboots and test the next set of failsafe settings. The blinking speed of the DRAM_LED increases, indicating different test processes. • Due to memory tuning requirement, the system automatically reboots when each timing set is tested. If the installed DIMMs still fail to boot after the tuning process is completed, the DRAM_LED lights continuously. Replace the DIMMs with ones recommended in the Memory QVL (Qualified Vendors Lists) at www.asus.com. • If you turn off the computer and replace DIMMs during the tuning process, the system continues memory tuning after turning on the computer. To stop memory tuning, turn off the computer and unplug the power cord for about 5–10 seconds. • If your system fails to boot up due to BIOS overclocking, press the MemOK! button to boot and load the BIOS default settings. A message will appear during POST to remind you that the BIOS has been restored to its default settings. • We recommend that you download and update to the latest BIOS version from www.asus.com after using the MemOK! function. 1-10 Chapter 1: Product Introduction...
  • Page 29 ReTry button (RETRY_BUTTON) The ReTry button is specially designed for overclockers and is most useful during the booting process where the Reset button is rendered useless. When pressed, it forces the system to reboot while retaining the same settings to be retried in quick succession to achieve a successful POST. BIOS Switch button (BIOS_SWITCH) The motherboard comes with two BIOS. Press the BIOS button to switch BIOS and load different BIOS settings. The nearby BIOS LEDs indicate the currently selected BIOS. ASUS RAMPAGE V EDITION 10 1-11...
  • Page 30 Safe Boot button (SAFE_BOOT) The Safe Boot button can be pressed anytime to force the system to reboot into the BIOS safe mode. This button temporarily applies safe settings to the BIOS while retaining any overclocked settings allowing you to modify the settings causing boot failure. Use this button when overclocking or tweaking the settings of your system. SLI/CFX switch (SLI/CFX) This switch allows you to determine the slots for 2-WAY or 3-WAY graphics card installation. When enabled, the PCIE LEDs near the slots light up, telling you to install the graphics cards to the specific slots. • The LEDs below the SLI/CFX switch and near the PCIE slots light up when the SLI/ CFX switch is enabled. Refer to section 1.1.7 Onboard LEDs for the exact location of the SLI/CFX and PCIE LEDs. • After adjusting PCIE bandwidth in the BIOS, shut down the system for the PCIE LEDs to update the lighting effect. 1-12 Chapter 1: Product Introduction...
  • Page 31 DRAM Lane switch (DRAM_SM_SW) These slide switches allows you to enable and disable the corresponding DIMM slots. When one of the installed DIMMs is out of order, you can use the slide switch to find out the faulty one without removing the DIMMS. PCIe x16 Lane switch (PCIEX16_SW) These slide switches allows you to enable and disable the corresponding PCIe x16 slots. When one of the installed PCIe x16 cards is out of order, you can use the slide switch to find out the faulty one without removing the cards. ASUS RAMPAGE V EDITION 10 1-13...
  • Page 32 Slow Mode Switch (SLOW_MODE) Slow Mode Switch is employed during LN2 benching. Some processors have a small optimum temperature range to run at their highest frequency. Temperatures that fall outside this band may yield instability. For example, a processor may need to operate at -80°C under load and only 75°C when idle to maintain stability at 5.8GHz. At lower frequencies, the CPU’s temperature tolerance increases. It will however remain stable at lower frequencies at much colder or warmer temperatures. Once it comes out of a heavy load while transitioning over to a light load, when the temperature does not warm fast enough, it may crash. To overcome this, simply flip the switch over to decrease the processor frequency. Switching over to Slow-Mode during critical moments when Temperature/Max Frequency alignment is off-sync can prevent a lot of crashes, even when trying to boot into the OS at cold temperatures. 1-14 Chapter 1: Product Introduction...

  • Page 33: Onboard Leds

    1.1.7 Onboard LEDs BIOS LEDs (BIOS_LED1-2) The BIOS LEDs help indicate the BIOS activity. Press the BIOS button to switch between BIOS1 and BIOS2 and the LED lights up when the corresponding BIOS is in use. PCIex16 lane LED indicator (PCIEX16_1_LED1; PCIEX16_2_LED1; PCIEX16_3_ LED1; PCIEX16_4_LED1) Indicates the PCIE lane used. ASUS RAMPAGE V EDITION 10 1-15...
  • Page 34 PCIE LEDs (PCIE_LED1-4) The PCIE LEDs light up to indicate which PCIE slots to use when SLI/CFX switch is enabled. SLI/CFX LED (SLI/CFX_LED) The SLI/CFX LEDs light up when SLI/CFX switch is enabled. 1-16 Chapter 1: Product Introduction...
  • Page 35 Q LEDs (BOOT_DEVICE_LED; VGA_LED; DRAM_LED; CPU_LED) Q LEDs check key components (CPU, DRAM, VGA card, and boot devices) in sequence during motherboard booting process. If an error is found, the corresponding LED will continue lighting until the problem is solved. This user-friendly design provides an intuitive way to locate the root-cause of the problem within seconds. DIMM LED (DIMM_A_LED; DIMM_B_LED; DIMM_C_LED; DIMM_D_LED) The DIMM LED indicates when the corresponding memory channel is enabled. ASUS RAMPAGE V EDITION 10 1-17...
  • Page 36 Q-Code LED (Q_CODE1) The Q-Code LED design provides you with a 2-digit error code that displays the system status. Refer to the Q-Code table on the next page for details. 1-18 Chapter 1: Product Introduction...
  • Page 37 Pre-memory PCH initialization is started 19 – 1C Memory initialization 2B – 2F Reserved for ASL (see ASL Status Codes section below) Memory Installed CPU post-memory initialization 32 – 36 37 – 3A Post-Memory System Agent initialization is started Post-Memory PCH initialization is started 3B – 3E DXE IPL is started Memory initialization error. Invalid memory type or incompatible memory 50 – 53 speed Unspecified memory initialization error Memory not installed Invalid CPU type or Speed CPU mismatch CPU self test failed or possible CPU cache error (continued on the next page) ASUS RAMPAGE V EDITION 10 1-19...
  • Page 38 Q-Code table Code Description CPU micro-code is not found or micro-code update is failed Internal CPU error Reset PPI is not available Reserved for future AMI error codes 5C – 5F S3 Resume is stared (S3 Resume PPI is called by the DXE IPL) S3 Boot Script execution Video repost OS S3 wake vector call Reserved for future AMI progress codes E4 – E7 S3 Resume Failed S3 Resume PPI not Found S3 Resume Boot Script Error S3 OS Wake Error Reserved for future AMI error codes EC – EF Recovery condition triggered by firmware (Auto recovery) Recovery condition triggered by user (Forced recovery) Recovery process started Recovery firmware image is found Recovery firmware image is loaded Reserved for future AMI progress codes F5 – F7 Recovery PPI is not available Recovery capsule is not found Invalid recovery capsule Reserved for future AMI error codes FB –...
  • Page 39 73 – 77 ACPI module initialization CSM initialization Reserved for future AMI DXE codes 7A – 7F Boot Device Selection (BDS) phase is started Driver connecting is started PCI Bus initialization is started PCI Bus Hot Plug Controller Initialization PCI Bus Enumeration PCI Bus Request Resources PCI Bus Assign Resources Console Output devices connect Console input devices connect Super IO Initialization USB initialization is started USB Reset USB Detect USB Enable 9E – 9F Reserved for future AMI codes IDE initialization is started IDE Reset IDE Detect IDE Enable SCSI initialization is started SCSI Reset SCSI Detect SCSI Enable (continued on the next page) ASUS RAMPAGE V EDITION 10 1-21...
  • Page 40 Q-Code table Code Description Setup Verifying Password Start of Setup Reserved for ASL (see ASL Status Codes section below) Setup Input Wait Reserved for ASL (see ASL Status Codes section below) Ready To Boot event Legacy Boot event Exit Boot Services event Runtime Set Virtual Address MAP Begin Runtime Set Virtual Address MAP End Legacy Option ROM Initialization System Reset USB hot plug PCI bus hot plug Clean-up of NVRAM Configuration Reset (reset of NVRAM settings) Reserved for future AMI codes B8– BF CPU initialization error System Agent initialization error PCH initialization error Some of the Architectural Protocols are not available PCI resource allocation error. Out of Resources No Space for Legacy Option ROM No Console Output Devices are found No Console Input Devices are found Invalid password Error loading Boot Option (LoadImage returned error) Boot Option is failed (StartImage returned error) Flash update is failed Reset protocol is not available 1-22 Chapter 1: Product Introduction...
  • Page 41 ACPI/ASL Checkpoints Code Description System is entering S1 sleep state 0x01 System is entering S2 sleep state 0x02 System is entering S3 sleep state 0x03 System is entering S4 sleep state 0x04 System is entering S5 sleep state 0x05 0x10 System is waking up from the S1 sleep state 0x20 System is waking up from the S2 sleep state System is waking up from the S3 sleep state 0x30 System is waking up from the S4 sleep state 0x40 System has transitioned into ACPI mode. Interrupt controller is in PIC mode. 0xAC System has transitioned into ACPI mode. Interrupt controller is in APIC mode. 0xAA ASUS RAMPAGE V EDITION 10 1-23...

  • Page 42: Jumper

    1.1.8 Jumper LN2 Mode jumper (3-pin LN2_MODE) With LN2 mode activated, the ROG motherboard is optimized to remedy the cold-boot bug during POST and help the system boot successfully. 1-24 Chapter 1: Product Introduction...

  • Page 43: Internal Connectors

    These connectors connect to Serial ATA 6 Gb/s hard disk drives via Serial ATA 6 Gb/s signal cables. If you installed Serial ATA hard disk drives, you can create a RAID 0, 1, 5, and 10 configuration with the Intel Rapid Storage Technology through the onboard Intel X99 ® ® chipset. • These connectors are set to [AHCI Mode] by default. If you intend to create a Serial ATA RAID array using these connectors, set the SATA Mode item in the BIOS to [RAID Mode]. Refer to the PCH Storage Configuration section for details. • Before creating a RAID array, refer to 4.1 RAID configurations section or the manual bundled in the motherboard support USB drive. ASUS RAMPAGE V EDITION 10 1-25...
  • Page 44 ROG Extension connector (18-1 pin ROG_EXT) This connector is for the OC Panel I/II, Front Base, and other ROG devices. • The Front Base is purchased separately. • Visit www.asus.com for more information about the OC Panel and Front Base. Thermal sensor cable connector (2-pin T_SENSOR1) This connector is for the thermistor cable that monitors the temperature of the devices and the critical components inside the motherboard. Connect the thermistor cable and place the sensor on the device or the motherboard’s component to detect its temperature. To monitor the temperature at the BIOS, go to BIOS>Monitor>Temperature Monitor. 1-26 Chapter 1: Product Introduction...
  • Page 45 USB 3.0 connector (20-1 pin USB3_12, USB3_34) This connector allows you to connect a USB 3.0 module for additional USB 3.0 front or rear panel ports. With an installed USB 3.0 module, you can enjoy all the benefits of USB 3.0 including faster data transfer speeds of up to 5 Gbps, faster charging time for USB-chargeable devices, optimized power efficiency, and backward compatibility with USB 2.0. • The USB 3.0 module is purchased separately. • These connectors are based on xHCI specification. We recommend you to install the related driver to fully use the USB 3.0 ports under Windows ® ASUS RAMPAGE V EDITION 10 1-27...
  • Page 46 USB 2.0 connectors (10-1 pin USB1112; USB1314) These connectors are for USB 2.0 ports. Connect the USB module cable to any of these connectors, then install the module to a slot opening at the back of the system chassis. These USB connectors comply with USB 2.0 specification that support up to 480 Mb/s connection speed. DO NOT connect a 1394 cable to the USB connectors. Doing so will damage the motherboard! You can connect the front panel USB cable to the ASUS Q-Connector (USB) first, and then install the Q-Connector (USB) to the USB connector onboard if your chassis supports front panel USB ports. • The USB 2.0 module is purchased separately. • 1 x USB 2.0 port (USB1112) at mid-board shares with ROG extension (ROG_EXT) port. 1-28 Chapter 1: Product Introduction...
  • Page 47 TPM connector (14-1 pin TPM) This connector supports a Trusted Platform Module (TPM) system, which securely stores keys, digital certificates, passwords and data. A TPM system also helps enhance network security, protect digital identities, and ensures platform integrity. The TPM module is purchased separately. Thunderbolt header (5-pin TB_HEADER) This connector is for the add-on Thunderbolt I/O card that supports Intel’s Thunderbolt Technology, allowing you to connect up to six Thunderbolt-enabled devices and a DisplayPort-enabled display in a daisy-chain configuration. The add-on Thunderbolt I/O card and Thunderbolt cables are purchased separately. ASUS RAMPAGE V EDITION 10 1-29...
  • Page 48 Front panel audio connector (10-1 pin AAFP) This connector is for a chassis-mounted front panel audio I/O module that supports either HD Audio or legacy AC’97 audio standard. Connect one end of the front panel audio I/O module cable to this connector. • We recommend that you connect a high-definition front panel audio module to this connector to take advantage of the motherboard’s high-definition audio capability. • If you want to connect a high-definition or an AC’97 front panel audio module to this connector, set the Front Panel Type item in the BIOS setup to [HD] or [AC97]. M.2 (SOCKET3) The M.2 (Socket 3) with M Key supports type 2260 (22mm x 60mm), 2280 (22mm x 80mm), and 22110 (22mm x 110mm) PCIe interface storage devices. • The PCIEX8_4 slot shares bandwidth with M.2 and U.2. • The M.2 (NGFF) SSD module is purchased separately. 1-30 Chapter 1: Product Introduction...
  • Page 49 RGB header (4-pin RGB_HEADER) This connector is for RGB LED strips. The RGB header supports 5050 RGB multi-color LED strips (12V/G/R/B), with a maximum power rating of 2A (12V), and no longer than 2 m. Before you install or remove any component, ensure that the ATX power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. • Actual lighting and color will vary with LED strip. • If your LED strip does not light up, check if the RGB LED extension cable and the RGB LED strip is connected in the correct orientation, and the 12V connector is aligned with the 12V header on the motherboard. • The LED strip will only light up under the operating system. ASUS RAMPAGE V EDITION 10 1-31...
  • Page 50 CPU, CPU optional, high amp, water pump, extension and chassis fan connectors (4-pin CPU_FAN; 4-pin CPU_OPT; 4-pin H_AMP_FAN; 4-pin W_ PUMP; 5-pin EXT_FAN; 4-pin CHA_FAN1-3) Connect the fan cables to the fan connectors on the motherboard, ensuring that the black wire of each cable matches the ground pin of the connector. DO NOT forget to connect the fan cables to the fan connectors. Insufficient air flow inside the system may damage the motherboard components. These are not jumpers! Do not place jumper caps on the fan connectors! The CPU_FAN connector supports the CPU fan of maximum 1A (12 W) fan power.
  • Page 51 ATX power connectors (24-pin EATXPWR; 8-pin EATX12V_1; 4-pin EATX12V_2; 4-pin EZ_PLUG) These connectors are for ATX power supply plugs. The power supply plugs are designed to fit these connectors in only one orientation. Find the proper orientation and push down firmly until the connectors completely fit. • For a fully configured system, we recommend that you use a power supply unit (PSU) that complies with ATX 12 V Specification 2.0 (or later version) and provides a minimum power of 450 W. • Do not forget to connect the 4-pin/8-pin EATX12 V power plug; otherwise, the system will not boot. • Connect the 4-pin EZ_PLUG power plugs to ensure sufficient power when you install multiple graphics cards. • Use of a PSU with higher power output is recommended when configuring a system with more power-consuming devices. The system may become unstable or may not boot up if the power is inadequate. • If you want to use two or more high-end PCI Express x16 cards, use a PSU with at least 1000W of output power to ensure system stability. ASUS RAMPAGE V EDITION 10 1-33...
  • Page 52 System panel connector (20-3 pin PANEL) This connector supports several chassis-mounted functions. • System power LED (2-pin or 3-1 pin PLED) The 2-pin or 3-1 pin connector is for the system power LED. Connect the chassis power LED cable to this connector. The system power LED lights up when you turn on the system power, and blinks when the system is in sleep mode. • Hard disk drive activity LED (2-pin HDD_LED) This 2-pin connector is for the HDD Activity LED. Connect the HDD Activity LED cable to this connector. The HDD LED lights up or flashes when data is read from or written to the HDD. • System warning speaker (4-pin SPEAKER) This 4-pin connector is for the chassis-mounted system warning speaker. The speaker allows you to hear system beeps and warnings. • ATX power button/soft-off button (2-pin PWRSW) This connector is for the system power button. Pressing the power button turns the system on or puts the system in sleep or soft-off mode depending on the operating...
  • Page 53 U.2 connector (U.2_1-2) This motherboard comes with a U.2 connector which supports PCIe 3.0 x4 NVM Express storage. The PCIEX8_4 slot shares bandwidth with M.2 and U.2. ASUS RAMPAGE V EDITION 10 1-35...

  • Page 54: Probeit

    1.1.10 ProbeIt The ROG ProbeIt allows you to detect your system’s current voltage and OC settings. Use a multimeter to measure the ProbeIt points even during overclocking. See the illustration below to locate the respective ProbeIt points. Using ProbeIt You can connect the multimeter to the motherboard as shown on the following figure. The illustration above are for reference only, the actual motherboard layout and measure points location may differ by models. 1-36 Chapter 1: Product Introduction...

  • Page 55: Chapter 2: Basic Installation

    Install the I/O frame to the chassis rear I/O panel. Place the motherboard into the chassis ensuring that its rear I/O ports are aligned to the chassis’ rear I/O panel. ASUS RAMPAGE V EDITION 10...
  • Page 56 Place nine (9) screws into the holes indicated by circles to secure the motherboard to the chassis. DO NOT overtighten the screws! Doing so can damage the motherboard. Chapter 2: Basic Installation...

  • Page 57: Cpu Installation

    • Ensure that the CPU is firmly clicked into place before installing it into the CPU socket or socket slot. • Use the CPU Installation Tool for installing the CPU only. DO NOT damage or bend the CPU Installation Tool. • Always firmly hold both sides of the CPU Installation Tool when installing, removing, or picking up the CPU Installation Tool. • Ensure to use a soft stable surface when installing the CPU to the CPU Installation Tool to prevent CPU damage. • ASUS will not cover damages resulting from incorrect CPU installation/removal, incorrect CPU orientation/placement, or other damages resulting from negligence by the user. Installing CPU ASUS RAMPAGE V EDITION 10...
  • Page 58 Antistatic sheet Align pin Bottom of CPU CPU Installation Tool Align pin Socket slot Bottom of CPU Chapter 2: Basic Installation...
  • Page 59 PnP cap Removing CPU Handle ASUS RAMPAGE V EDITION 10...

  • Page 60: Cpu Heatsink And Fan Assembly Installation

    2.1.3 CPU heatsink and fan assembly installation Apply the thermal interface material to the CPU heatsink and CPU before you install the heatsink and fan, if necessary. Installing the CPU heatsink and fan assembly Chapter 2: Basic Installation...
  • Page 61 Uninstalling the CPU heatsink and fan assembly ASUS RAMPAGE V EDITION 10...

  • Page 62: Dimm Installation

    2.1.4 DIMM installation To remove a DIMM Chapter 2: Basic Installation...

  • Page 63: Atx Power Connection

    2.1.5 ATX power connection • DO NOT connect the 4-pin power plug only, the motherboard may overheat under heavy usage. • Ensure to connect the 8-pin power plug, or connect both the 8-pin and 4-pin power plugs. ASUS RAMPAGE V EDITION 10...

  • Page 64: Sata Device Connection

    2.1.6 SATA device connection 2-10 Chapter 2: Basic Installation...

  • Page 65: Front I/O Connector

    2.1.7 Front I/O connector To install ASUS Q-Connector To install USB 2.0 connector To install front panel audio connector AAFP USB 2.0 To install USB 3.0 connector USB 3.0 ASUS RAMPAGE V EDITION 10 2-11...

  • Page 66: Expansion Card Installation

    2.1.8 Expansion card installation To install PCIe x16 cards To install PCIe x1 cards 2-12 Chapter 2: Basic Installation...

  • Page 67: Supremefx Hi-Fi Installation

    2.1.9 SupremeFX Hi-Fi installation • Unplug the power cord from the wall socket before touching any component. • Before you install or remove any component, ensure that the power supply is switched off or the power cord is detached from the power supply. Failure to do so may cause severe damage to the motherboard, peripherals, or components. Using the bundled USB 2.0 connector cable to connect your SupremeFX Hi-Fi panel is the best way to use your SupremeFX Hi-Fi panel. USB 2.0 ASUS RAMPAGE V EDITION 10 2-13...

  • Page 68: Wi-Fi Antenna Installation

    2.1.10 Wi-Fi antenna installation Installing the ASUS 3T3R dual band W-Fi antenna Connect the bundled ASUS 3T3R dual band Wi-Fi antenna connector to the Wi-Fi ports at the back of the chassis. IO Shield • Ensure that the ASUS 3T3R dual band Wi-Fi antenna is securely installed to the Wi-Fi ports. • Ensure to install the Bluetooth driver before installing the Wi-Fi GO! software. • Ensure that the antenna is at least 20 cm away from all persons. The illustration above is for reference only. The I/O port layout may vary with models, but the Wi-Fi antenna installation procedure is the same for all models.

  • Page 69: Bios Update Utility

    To use USB BIOS Flashback: 1. Download the latest BIOS file from the ASUS website. Extract and rename the BIOS image file to R5E10.CAP. Copy R5E10.CAP to the root directory of your USB storage device. Turn off the system and connect the USB storage device to the USB BIOS Flashback port. Press the USB BIOS Flashback button for 3 seconds until the BIOS_LED1 or BIOS_ LED2 flashes. A flashing light indicates that the BIOS Flashback function is enabled. The light goes out when the process of updating the BIOS is complete. USB BIOS Flashback button KeyBot II port USB BIOS Flashback port • For more BIOS update utilities in BIOS setup, refer to the section Updating BIOS in Chapter 3. • Connect your USB keyboard on the KeyBot II port if you want to use the KeyBot feature. Updating BIOS may have risks. If the BIOS program is damaged during the process and results to the system’s failure to boot up, please contact your local ASUS Service Center. ASUS RAMPAGE V EDITION 10 2-15...

  • Page 70: Motherboard Rear And Audio Connections

    Motherboard rear and audio connections 2.3.1 Rear I/O connection Rear panel connectors Clear CMOS button ® ASMedia USB 3.0 ports E1234. Supports USB 3.0 Boost. ® LAN (RJ-45) port* Intel ® LAN (RJ-45) port* Intel Wi-Fi 802.11 a/b/g/n/ac, Bluetooth V4.0 PS/2 Keyboard/Mouse combo port USB BIOS Flashback button ASMedia USB 3.1 Type-C port EC1. Supports USB 3.1 Boost. ® ASMedia USB 3.1 Type-A port EA2. Supports USB 3.1 Boost. ® ASMedia USB 3.1 Type-C port EC3. Supports USB 3.1 Boost. ® ASMedia USB 3.1 Type-A port EA4. Supports USB 3.1 Boost. ® USB 2.0 ports 7 and 8. Upper port supports the KeyBot II feature, and lower ® Intel port supports USB BIOS Flashback function.
  • Page 71 Side Speaker Out Line In Line In Line In Front Speaker Out Front Speaker Out Front Speaker Out Lime Line Out Pink Mic In Mic In Mic In Mic In Center/Sub Center/Sub Orange – – woofer woofer Black Rear Speaker Out Rear Speaker Out Rear Speaker Out – ASUS RAMPAGE V EDITION 10 2-17...

  • Page 72: Audio I/O Connections

    2.3.2 Audio I/O connections Audio I/O ports Connect to Headphone and Mic Connect to Stereo Speakers Connect to 2.1 channel Speakers 2-18 Chapter 2: Basic Installation...
  • Page 73 Connect to 4.1 channel Speakers Connect to 5.1 channel Speakers Connect to 7.1 channel Speakers ASUS RAMPAGE V EDITION 10 2-19...

  • Page 74: Supremefx Hi-Fi Audio I/O Connections

    2.3.3 SupremeFX Hi-Fi Audio I/O connections Audio I/O ports Volume control knob 6.3mm 3.5mm Microphone headphone headphone / Line input output jack output jack jack The volume will be set at the minimal level upon first installation. Please slowly adjust the volume to a comfortable level after plugging in a headphone. Ensure to always run the impedance detect function before playback every time you switch headphones to avoid damage to your headphones. Connect to 3.5mm headphones Connect to 6.3mm headphones Connect to microphone...

  • Page 75: Starting Up For The First Time

    (repeated) One continuous beep followed by three No VGA detected short beeps One continuous beep followed by four Hardware component failure short beeps Hold down the <Delete> key during power on to enter the BIOS Setup. Follow the instructions in Chapter 3. Turning off the computer While the system is ON, press the power button for less than four seconds to put the system to sleep mode or soft-off mode, depending on the BIOS setting. Press the power switch for more than four seconds to let the system enter the soft-off mode regardless of the BIOS setting. ASUS RAMPAGE V EDITION 10 2-21...
  • Page 76 2-22 Chapter 2: Basic Installation...

  • Page 77: Chapter 3: Bios Setup

    BIOS setup Knowing BIOS The new ASUS UEFI BIOS is a Unified Extensible Interface that complies with UEFI architecture, offering a user-friendly interface that goes beyond the traditional keyboard- only BIOS controls to enable a more flexible and convenient mouse input. You can easily navigate the new UEFI BIOS with the same smoothness as your operating system.

  • Page 78: Bios Setup Program

    Clear CMOS button to clear RTC RAM. • The BIOS setup program does not support bluetooth devices. Please visit ASUS website for the detailed BIOS content manual. BIOS menu screen The BIOS Setup program can be used under two modes: EZ Mode and Advanced Mode.

  • Page 79: Ez Mode

    Click to go to Advanced mode Search on the FAQ Loads optimized default settings Click to display boot devices Selects the boot device priority The boot device options vary depending on the devices you installed to the system. ASUS RAMPAGE V EDITION 10...

  • Page 80: Advanced Mode

    3.2.2 Advanced Mode The Advanced Mode provides advanced options for experienced end-users to configure the BIOS settings. The figure below shows an example of the Advanced Mode. Refer to the following sections for the detailed configurations. To switch from EZ Mode to Advanced Mode, click Advanced Mode(F7) or press the <F7> hotkey.
  • Page 81 This button above the menu bar allows you to view and tweak the overclocking settings of your system. It also allows you to change the motherboard’s SATA mode from AHCI to RAID mode. Refer to section 3.2.4 EZ Tuning Wizard for more information. ASUS RAMPAGE V EDITION 10...
  • Page 82 Move your mouse over this button to show a QR code, scan this QR code on your mobile device to connect to the BIOS FAQ web page of the ASUS support website. You can also scan the following QR code:...

  • Page 83: Qfan Control

    PWM Mode Select a profile to apply to Click to apply the fan setting your fans Click to undo the Click to go back to main menu changes Select to manually configure your fans ASUS RAMPAGE V EDITION 10...
  • Page 84 Configuring fans manually Select Manual from the list of profiles to manually configure your fans’ operating speed. Speed points Select to manually configure your fans To configure your fans: Select the fan that you want to configure and to view its current status. Click and drag the speed points to adjust the fans’...

  • Page 85: Ez Tuning Wizard

    To start OC Tuning: Press <F11> on your keyboard or click from the BIOS screen to open EZ Tuning Wizard screen. Click OC then click Next. Select a PC scenario Daily Computing or Gaming/Media Editing, then click Next. ASUS RAMPAGE V EDITION 10...
  • Page 86 Select a Main Cooling System BOX cooler, Tower cooler, Water cooler, or I’m not sure, then click Next. After selecting the Main Cooling System, click Next then click Yes to start the OC Tuning. Creating RAID To create RAID: Press <F11> on your keyboard or click from the BIOS screen to open EZ Tuning Wizard screen.
  • Page 87 After selecting the type of RAID, click Next then click Yes to continue the RAID setup. After the RAID setup is done, click Yes to exit the setup then click OK to reset your system. ASUS RAMPAGE V EDITION 10 3-11...

  • Page 88: My Favorites

    My Favorites My Favorites is your personal space where you can easily save and access your favorite BIOS items. My Favorites comes with several performance, power saving, and fast boot related items by default. You can personalize this screen by adding or removing items. 3-12 Chapter 3: BIOS Setup...
  • Page 89 Configuration items such as Memory SPD Information, system time and date. Click Exit (ESC) or press <Esc> key to close Setup Tree Map screen. Go to My Favorites menu to view the saved BIOS items. ASUS RAMPAGE V EDITION 10 3-13...

  • Page 90: Main Menu

    Main menu The Main menu screen appears when you enter the Advanced Mode of the BIOS Setup program. The Main menu provides you an overview of the basic system information, and allows you to set the system date, time, language, and security settings. 3-14 Chapter 3: BIOS Setup...
  • Page 91 Clear CMOS button to clear RTC RAM. • The Administrator or User Password items on top of the screen show the default [Not Installed]. After you set a password, these items show [Installed]. ASUS RAMPAGE V EDITION 10 3-15...

  • Page 92: Extreme Tweaker Menu

    Extreme Tweaker menu The Extreme Tweaker menu items allow you to configure overclocking-related items. Be cautious when changing the settings of the Extreme Tweaker menu items. Incorrect field values can cause the system to malfunction The configuration options for this section vary depending on the CPU and DIMM model you installed on the motherboard.
  • Page 93 [Keep Current Settings] Keep the current settings without changing anything. [TPU I] Applies air cooling overclocking conditions. [TPU II] Applies water cooling overclocking conditions. Ensure to use water cooling device before selecting [TPU II]. 3-17 ASUS RAMPAGE V EDITION 10...

  • Page 94: Advanced Menu

    EPU Power Saving Mode The ASUS EPU (Energy Processing Unit) sets the CPU in its minimum power consumption settings. Enable this item to set lower CPU core/cache voltage and achieve the best energy saving condition. Configuration options: [Disabled] [Enabled] Internal CPU Power Management The subitems in this menu allow you to set the CPU ratio and features.

  • Page 95: Cpu Configuration

    Configuration options: [Disabled] [Enabled] CPU C-States This item allows you to set the power saving of the CPU states. Configuration options: [Auto] [Disabled] [Enabled] ASUS RAMPAGE V EDITION 10 3-19...

  • Page 96: Pch Configuration

    3.6.2 PCH Configuration PCI Express Configuration This item allows you to configure the PCI Express slots. PCIEX4_1 Speed This item allows your system to automatically select the PCI Express port speed. Configuration options: [Auto] [Gen1] [Gen2] 3.6.3 PCH Storage Configuration While entering Setup, the BIOS automatically detects the presence of SATA devices.

  • Page 97: System Agent (Sa) Configuration

    Hot Plug These items appear only when the SATA Mode Selection is set to [AHCI] and allows you to enable or disable SATA Hot Plug Support. Configuration options: [Disabled] [Enabled] 3.6.4 System Agent (SA) Configuration ASUS RAMPAGE V EDITION 10 3-21...

  • Page 98: Usb Configuration

    3.6.5 USB Configuration The items in this menu allow you to change the USB-related features. The Mass Storage Devices item will only appear when a USB device is detected. USB Single Port Control This item allows you to enable or disable the individual USB ports. Refer to section 1.1.2 Motherboard layout for the location of the USB ports.

  • Page 99: Onboard Devices Configuration

    LED lighting effect will revert to the default setting the next time the motherboard is powered on. • The following item appears only when you set the RGB LED lighting effects to [Static], [Breathing], or [Strobing]. ASUS RAMPAGE V EDITION 10 3-23...

  • Page 100: Apm Configuration

    RGB LED lighting color This item allows you to set the RGB LED lighting colors. Bluetooth Controller This item allows you to enable or disable the Bluetooth Controller. Configuration options: [Disabled] [Enabled] Wi-Fi Controller This item allows you to enable or disable the Wi-Fi Controller. Configuration options: [Disabled] [Enabled] Intel LAN1 Controller This item allows you to enable or disable the GbE Controller.

  • Page 101: Rog Effects

    The Monitor menu displays the system temperature/power status, and allows you to change the fan settings. Scroll down to display other BIOS items. Optimize All This item will automatically detect the lowest speed and configure the minimum duty cycle for each fan. ASUS RAMPAGE V EDITION 10 3-25...

  • Page 102: Boot Menu

    Water Pump Control [Disabled] Disable the Water Pump control feature. [Auto] Detect the type of Water Pump installed and automatically switches the mode control. [DC mode] Enable the Water Pump control in DC mode for 3-pin Water Pump. [PWM mode] Enable the Water Pump control in PWM mode for 4-pin Water Pump.
  • Page 103 Configuration options: [Legacy only] [UEFI driver first] Secure Boot This item allows you to configure the Windows Secure Boot settings and manage its keys to ® protect the system from unauthorized access and malwares during POST. 3-27 ASUS RAMPAGE V EDITION 10...

  • Page 104: Tool Menu

    3.9.2 ASUS EZ Flash 3 Utility Allows you to run ASUS EZ Flash 3. When you press <Enter>, a confirmation message appears. Use the Left/Right arrow key to select between [via Storage Devices(s)] or [via Internet], then press <Enter> to confirm your choice.

  • Page 105: Secure Erase

    To launch Secure Erase, click Tool > Secure Erase on the Advanced mode menu. Check the ASUS support site for a full list of SSDs tested with Secure Erase. The drive may become unstable if you run Secure Erase on an incompatible SSD.

  • Page 106: Asus Overclocking Profile

    3.9.4 ASUS Overclocking Profile This item allows you to store or load multiple BIOS settings. Load from Profile This item allows you to load the previous BIOS settings saved in the BIOS Flash. Key in the profile number that saved your BIOS settings, press <Enter>, and then select Yes.

  • Page 107: Asus Spd Information

    This option allows you to exit the Setup program without saving your changes. When you select this option or if you press <Esc>, a confirmation window appears. Select Yes to discard changes and exit. ASUS RAMPAGE V EDITION 10 3-31...

  • Page 108: Updating Bios

    3.11 Updating BIOS The ASUS website publishes the latest BIOS versions to provide enhancements on system stability, compatibility,and performance. However, BIOS updating is potentially risky. If there is no problem using the current version of BIOS, DO NOT manually update the BIOS.

  • Page 109: Asus Ez Flash 3 Utility

    3.11.2 ASUS EZ Flash 3 Utility ASUS EZ Flash 3 Utility allows you to update the BIOS without having to use a bootable floppy disk or an OS-based utility. Updating through the Internet varies per region and Internet conditions. Check your local Internet connection before updating through the Internet.
  • Page 110 To update the BIOS by Internet: Enter the Advanced Mode of the BIOS setup program. Go to the Tool menu to select ASUS EZ Flash 3 Utility and press <Enter>. Select via Internet. Press the Left/Right arrow keys to select an Internet connection method, and then press <Enter>...

  • Page 111: Asus Crashfree Bios 3

    3.11.3 ASUS CrashFree BIOS 3 The ASUS CrashFree BIOS 3 utility is an auto recovery tool that allows you to restore the BIOS file when it fails or gets corrupted during the updating process. You can restore a corrupted BIOS file using the motherboard support USB drive that contains the BIOS file.
  • Page 112 3-36 Chapter 3: BIOS Setup...

  • Page 113: Chapter 4: Raid Support

    With the RAID 10 configuration you get all the benefits of both RAID 0 and RAID 1 configurations. Use four new hard disk drives or use an existing drive and three new drives for this setup. ASUS RAMPAGE V EDITION 10...

  • Page 114: Installing Serial Ata Hard Disks

    4.1.2 Installing Serial ATA hard disks The motherboard supports Serial ATA hard disk drives. For optimal performance, install identical drives of the same model and capacity when creating a disk array. To install the SATA hard disks for a RAID configuration: Install the SATA hard disks into the drive bays.
  • Page 115 When the RAID Level item is selected, press <Enter> to select the RAID level to create, and then press <Enter>. Under Select Disks, press <Enter> and select X for the disks you want to include in the RAID set. ASUS RAMPAGE V EDITION 10...
  • Page 116 When the Strip Size item is selected, press <Enter> to select strip size for the RAID array (for RAID 0, 10 and 5 only), and then press <Enter>. The available strip size values range from 4 KB to 128 KB. The following are typical values: RAID 0: 128 KB RAID 10: 64 KB RAID 5: 64 KB...
  • Page 117 <Enter>. The following screen appears: When the Delete item is selected, press <Enter>, then select Yes to delete the RAID Rapid Storage Technology menu, or select No to volume and return to the Intel ® cancel. ASUS RAMPAGE V EDITION 10...

  • Page 118: Intel ® Rapid Storage Technology Option Rom Utility

    4.1.4 Intel Rapid Storage Technology Option ROM utility ® To enter the Intel Rapid Storage Technology Option ROM utility: ® Turn on the system. During POST, press <Ctrl> + <I> to display the utility main menu. RAID Volumes: None defined. Physical Devices: Port Device Model...
  • Page 119 Size Status ST3160812AS 9LS0HJA4 149.0GB Non-RAID Disk ST3160812AS 9LS0F4HL 149.0GB Non-RAID Disk ST3160812AS 3LS0JYL8 149.0GB Non-RAID Disk ST3160812AS 9LS0BJ5H 149.0GB Non-RAID Disk Select 2 to 6 to use in creating the volume. [↑↓]-Prev/Next [SPACE]-SelectDisk [ENTER]-Done ASUS RAMPAGE V EDITION 10...
  • Page 120 Use the up/down arrow key to select a drive, and then press <Space> to select. A small triangle marks the selected drive. Press <Enter> after completing your selection. Use the up/down arrow key to select the strip size for the RAID array (for RAID 0, 10 and 5 only),and then press <Enter>.
  • Page 121 (This does not apply to Recovery volumes) Are you sure you want to delete “Volume0”? (Y/N): Press <Y> to delete the RAID set and return to the utility main menu, or press <N> to return to the DELETE VOLUME menu. ASUS RAMPAGE V EDITION 10...

  • Page 122: Creating A Raid Driver Disk

    Exiting the Intel Rapid Storage Technology Option ROM utility ® To exit the utility: From the utility main menu, select 5. Exit, and then press <Enter>. The following warning message appears: [CONFIRM EXIT] Are you sure you want to exit? (Y/N): Press <Y>...

  • Page 123: Appendix

    Consult the dealer or an experienced radio/TV technician for help. The use of shielded cables for connection of the monitor to the graphics card is required to assure compliance with FCC regulations. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate this equipment. ASUS RAMPAGE V EDITION 10...
  • Page 124 IC: Canadian Compliance Statement Complies with the Canadian ICES-003 Class B specifications. This device complies with RSS 210 of Industry Canada. This Class B device meets all the requirements of the Canadian interference-causing equipment regulations. This device complies with Industry Canada license exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
  • Page 125 ASUS Recycling/Takeback Services ASUS recycling and takeback programs come from our commitment to the highest standards for protecting our environment. We believe in providing solutions for you to be able to responsibly recycle our products, batteries, other components as well as the packaging materials.
  • Page 126 License. Warranty ASUS warrants the Product to be free from defects in workmanship and materials for the Warranty Period. The Warranty does not cover bundled accessories, which were delivered together with the Product such as: USB, cables, I/O shield, bag, mouse etc. If the Product...
  • Page 127 1995/5/ EZ. Cijeli tekst EU izjave o sukladnosti dostupan je na: www.asus.com/support Toto zariadenie môže byť prevádzkované v dolu uvedených krajinách: Ovaj uređaj može se koristiti u dolje navedenim zemljama: Slovenščina ASUSTeK Computer Inc.

  • Page 128: Asus Contact Information

    800 Corporate Way, Fremont, CA 94539, USA Telephone +1-510-739-3777 +1-510-608-4555 Web site http://www.asus.com/us/ Technical Support Support fax +1-812-284-0883 Telephone +1-812-282-2787 Online support http://qr.asus.com/techserv ASUS COMPUTER GmbH (Germany and Austria) Address Harkort Str. 21-23, 40880 Ratingen, Germany +49-2102-959931 Web site http://www.asus.com/de Online contact http://eu-rma.asus.com/sales Technical Support Telephone +49-2102-5789555 Support Fax +49-2102-959911 Online support http://qr.asus.com/techserv...
  • Page 129 800 Corporate Way, Fremont Phone/Fax No: (510)739-3777/(510)608-4555 hereby declares that the product Product Name : Motherboard Model Number : RAMPAGE V EDITION 10 Conforms to the following specifications: FCC Part 15, Subpart B, Unintentional Radiators Supplementary Information: This device complies with part 15 of the FCC Rules. Operation is subject to the...
  • Page 130 Appendix...

Table of Contents
