Swing-N-Slide PB 4446 Assembly Instructions Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
NOTE:
THIS
ONLY
USE
PLAN
TO BUILD ENTIRE KIT
PB 4446
Minimum Use Zone
31'
32'
No. of Children: Up to 12
Min. Use Zone: 32 ' x 31 '
Set Dim. 20 'W x 14 'L x 12'H
Est. Building Time: 12 hr.
check out http://www.swing-n-slide.com
for updates to these instructions.
THIS PLAN SUPERCEDES ALL
ASSEMBLY INSTRUCTIONS
BEFORE 5/21/2010
Swing•N•Slide • 1212 Barberry Drive • Janesville, Wisconsin 53545
Visit our web site at: www.swing-n-slide.com or call us at 1-800-888-1232
