Project Source W3012B Assembly Instruction Manual page 8

Wall cabinet

Hide thumbs Also See for W3012B:

Table of Contents

Available languages

ASSEMBLY INSTRUCTIONS

7. Assemble the cabinets parts as per the illustration.

Using a phillips head screwdriver, rotate the minifix

cam clockwise to fasten into place. Ensure all cams

are locked into place before moving the cabinet.

8. Assemble the cabinets parts as per the illustration.

Using a phillips head screwdriver, rotate the minifix

cam clockwise to fasten into place. Ensure all cams

are locked into place before moving the cabinet.

9. Insert the back panel as shown in the drawing.
