Tab B
Stoper
Tab A
1. Plug the light wire connector on the faceguard into the connector on the vehicle.
2-3. Insert the tab A on the faceguard into the biggest hole (A) on the vehicle. Then fit the
tab B & tab C into the hole B & hole C in the vehicle body, also fit the both stopers into
the holes in the vehicle body. Push the faceguard down still hear it "click" into place.
Attach the Faceguard │ 8
1
Tab C
Stoper
3
3
2
Hole A
Hole C
Hole B
