ASSEMBLY INSTRUCTIONS
4. Using a phillips head screwdriver, attach the
mounting plate as shown in the illustration.
Hardware Used
DD Hinge mounting plate
5. Insert the hinge in the bore hole. Using a phillips
head screwdriver, turn the pre-installed screws
clockwise to lock into place.
Hardware Used
EE 105 Hinge
o
6. Place the bumper on the door as shown
Hardware Used
FF
Bumper 2MM
4
x 4
5
x 4
6
x 4
7
DD
EE
FF
