Variobot variAnt Instructions Manual page 26

19) Installing the Battery
Mount the 2 battery holders on the small spacers in
the center of the body using 4 short screws.
Begin by placing the elastic band around the two
protruding tips of the acrylic parts at the back.
Then, pull the lower part of the elastic band
towards the center and stretch it from below over
the protruding tips at the front.
Now, place the battery between the holders with
the USB port facing upwards, and secure it with the
two elastic loops.
Lastly, bend the red-black clip cable 180° towards
the back and connect the clip connector to the
contacts of the battery.
2 battery holders
4 short screws (4 mm)
1 elastic band (Ø 40 mm)
1 Li-ion battery (9 V)
If your kit does not include a battery, make
sure to use a rechargeable 9 V lithium-ion
battery or, a 9 V lithium battery.
Standard 9 V alkaline block batteries are not
suitable as they do not provide enough power.
