Variobot variAnt Instructions Manual page 15

8) Connecting the Body Components
Now, press the diagonally positioned motors apart
at the top, and push the cables that are in between
downwards. Then, position the top acrylic compo-
nent in a way that all the components (cables etc.)
protrude through their respective openings.
Check if the top acrylic component can be
easily pressed against the black spacers
without pinching any cables.
Also ensure the push buttons of the control
board do not stick on the acrylic when pushed.
For now, secure the upper component only to the
head and the abdomen using 5 long screws.
Then, attach 2 balls with 6 mm screws to the short
spacers in the head area.
Ensure that these screws are firmly tightened.
5 long screws (8 mm)
2 medium screws (6 mm)
2 perforated brass balls (5 mm)
