PRASTEL M1000 Quick Start Manual

M1000E
1.

GENERAL DESCRIPTION

M1000E is an access control unit for the operation of one door.
It is equipped with an input for an external reader, an output relay with 5A-capacity contacts for direct connection to an electric lock, and an internal
memory with a storage capacity of 999 user codes.
It is also fitted with 4 keys and a 4-digit display for code and functional parameter setting, and more precisely for
•
programming new codes into the memory (through self-learning via the reader connected to the input);
•
deleting single codes from the memory;
•
deleting all the codes from the memory;
•
selecting either bistable or timed operation mode for the relay;
•
setting activation time for the relay (in the timed operation mode);
•
setting a user password to protect programming operations;
All M1000E circuits and components are housed in a plastic enclosure suitable for indoor installation and for mounting on bars according to DIN
standards.
2.

TECHNICAL FEATURES

Power supply 12-24Vac/dc
Inputs 1 data input with Wiegand protocol
Memory capacity 999 users
No. of output relays
1 contact for enabling reading function on the door.
Inputs for forcing activation of the door ("door opener" push-button)
Relay operating mode timed from 1 to 180 seconds
Relay contact capacity 5 A
Programming 4 keys (FUN, INC, DEC, VAL) and 4 displays
Dimensions and weight 70x90x60, 260 grams
3.

FUNCTIONS

The M1000E can be programmed by means of the 4 colour keys in the front panel.
In the following paragraphs, keys are referred to as FUN, INC, DEC and VAL. Colour correspondence is as follows:
FUN = yellow
INC = blue
DEC = red
VAL = green

Programming new codes

1. Simultaneously press keys INC and DEC.
2. Select a free storage location via keys INC and DEC (free location is indicated by decimal points being off).
3. Perform transmission or have the badge to be stored read by the badge reader (decimal points will go on).
4. Confirm by pressing key VAL (decimal points will briefly flash).
5. Repeat procedure from step 2 to enter other codes or simultaneously press keys INC and DEC to exit from programming mode.

Deleting codes

1. Simultaneously press keys INC and DEC.
2. Select the storage location to be deleted via keys INC and DEC (decimal points on indicate that the location is engaged)
3. Press the VAL key. The letter -C- will now appear on the left-hand side of the display.
4. Press the VAL key again to confirm deletion. The decimal points will go off and the storage location 'h' will be deleted.
5. Repeat procedure from step 2 to delete other codes and simultaneously press keys INC and DEC to exit from the programming mode.

Selecting operation mode and relay timing

1. Simultaneously press keys INC and DEC.
2. Press key FUN to access the function selection menu.
3. Select function F01 by pressing keys INC and DEC.
4. Confirm selection by pressing the VAL key; current parameter value will appear on the display.
5. Select the value to be assigned to the parameter by pressing keys INC and DEC. If value 000 is set, the relay will operate in the bistable mode.
If a value between 1 and 180 is selected, the relay will operate in the monostable mode with activation time corresponding to the set value
(expressed in seconds).
6. Confirm by pressing key VAL; display will return to function selection and the new parameter will be stored.
7. Simultaneously press keys INC and DEC to exit from programming mode.
8.

Assigning radio channel to the relay

1. Simultaneously press keys INC and DEC.
2. Press the FUN key to access the function selection menu.
3. Select function F02 (relay 1) by pressing keys INC and DEC.
4. Confirm selection by pressing the VAL key; current parameter value will appear on the display.
5. Select the desired radio transmitter channel (1, 2, 3 or 4) to be assigned to the relay by pressing keys INC and DEC.
6. Confirm by pressing key VAL; display will return to function selection and the new parameter will be stored.
Simultaneously press keys INC and DEC to exit from programming mode

Entering the password

1. Access programming mode by pressing keys INC + DEC.
2. Press the FUN key to access the function selection menu.
3. Select function F03 by pressing keys INC and DEC and confirm by pressing the VAL key.
4. The letter P will appear on the left side of the display. Digit a sequence of six keys within 10 seconds. Each time a key is pressed, the letter P will
flash.
5. Upon the full sequence of six keys having been completed, the function selection menu will reappear on the display.
Failure to complete sequence within 10 seconds will abort password entry. This also avoids entry of incorrect passwords in case of any doubts as to
the sequence to be entered or erroneous pressing of any key.
The password is stored in EEPROM and is requested whenever INC+DEC are pressed to access programming mode starting from the stand-by
status (displays being off). In this case:
M1000
