20: xproc
•
21: preserved
•
22: one_end_disc
The allowable condensed call states are as follows:
Note: If a call is condensed with a state other than those listed as allowable
condensed call state, the call will be killed by an audit.
•
dialing
•
talking
•
multiport
•
termtone
•
held
•
testing
•
ovlpulsing
•
custom.
XBITS special call processing bits assigned to a terminal identifier (TID)
with the state of SELECTCPTLB. When a CPTLB is selected for the TID,
the bits are copied into the selected CPTLB.
FORCEUNAVAIL a boolean indicating whether the terminal linkage
block state has been forced to unavailable.
IBN indicates an IBN line; boolean.
SA if true, this bit indicates service analysis.
FASTSEQNO is an integer used only by CPIO system.
CMI Cross Matrix Index is used to categorize a connection, such as a
line-to-line or a trunk-to-trunk. Refer to Figure 5-7 on page 5-12 for CMI
diagram.
DISPCALL user Guide Technical Assistance Manual BCS34 and up
Interpreting DISPCALL output 5-11
all messages are driven from the starter to the
cross processor.
calls preserved over WARM SWACT, LM/RLM
WARM takeback/takeover.
a call is waiting on the last agent in the call to be
disconnected, which usually occurs after talking
and before idle.
