3-8 DISPCALL level commands

disptid

Function
Use the disptid command to convert the terminal identifier (TID) number of
an agent to a call process identifier (CPID) designation (text). To determine
the TID of an agent, refer to "Calculating Terminal Identifiers" on page
2-1.
disptid command parameters and variables
Command Parameters and variables
disptid nodeno
Parameters
and variables Description
nodeno is the node number. Range is 0 to 4095.
termno is the terminal number. Range is 0 to 4095.
Qualifications
A valid node number and a valid terminal number must be entered.
Examples
Following is a possible example of the disptid command.
Examples of the disptid command
Example Task, response, and explanation
disptid 25 54
and pressing the Enter key. ↵
where
25 is the node number
54 is the terminal number.
Task:
Response:
Explanation:
TAM-1001-003 Standard 3.01 July 1992
termno
End
Display the LEN and DN associated with the given TID.
End
