- Page 1 Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 User Instruction RFL-P200MX Wuhan Raycus Fiber Laser Technologies CO., Ltd. 2021...
- Page 2 Raycus pulsed fiber laser is classified as a high power Class IV laser device. Before supplying the power to the device, please make sure that the correct voltage of 48V DC is connected and the anode and cathode are right. Incorrect polarity or voltage will damage the device.
-
Page 3: Table Of Contents
Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 Content 1. Description........................1 1.1. Product description........................1 1.2. Actual configuration list......................1 1.3. Environmental requirements and cautions................1 1.4. Specifications..........................2 2. Installation........................4 2.1. Installation dimensions......................4 2.2. -
Page 4: Description
Caution: Make sure the corresponding wires of the device are properly grounded. All the maintenance to the device should only be done by Raycus because there is no replacement or accessory provided with the device. To prevent against electric shock Please do not try to damage the labels or open the cover, or the warranty will be invalid. -
Page 5: Specifications
Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 When the laser is in operation, it is strictly prohibited to install the output collimator. The laser has seven fans at the tail plate for heat dissipation, which must ensure sufficient airflow for heat dissipation. - Page 6 Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 Table 2 shows the performance parameters of the laser at the default pulse width of 350ns. Table 3 Frequency parameters at different pulse durations for 200MX...
-
Page 7: Installation
Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 2. Installation 2.1. Installation dimensions Dimension drawing Figure 1 Dimension drawing of laser module (Unit: mm) Optical isolator output head size diagram Figure 2 Dimension drawing of output isolator (Unit: mm). - Page 8 Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 clear to the polarity of the electric current: Anode-brown, Cathode-blue, PE-yellow- green. Figure 3 Definition of power line wires The power consumption of single-mode 200W laser is about 800W, please ensure that the output power of 48V DC power supply reaches more than 1000W.
-
Page 9: Control Interface
Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 3. Control Interface The DB25 on the back of the power module is the interface between the control system (e.g. marking machine) and the laser system. Be sure to connect it reliably before working. The pins are defined as follows. - Page 10 Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 Table 5 Definition of pin1-8 Setting 1 Setting 2 Setting 3 Setting 4 Pin 1 Pin 2 Pin 3 Pin 4 Pin 5 Pin 6 Pin 7...
- Page 11 Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 The signal input needs to be able to provide at least 7mA of current. The schematic diagram of the output signal interface circuit is shown in Figure 7.
-
Page 12: Pre-Inspection
Wuhan Raycus Fiber Laser Technologies CO., LTD. P200MX Pulsed Fiber Laser User Instruction V1 3.1. Pre-inspection Make sure the device appearance is in good condition and the output fiber is neither excessively bended nor broken. Make sure signal line of laser and marking system are properly connected. -
Page 13: Instructions For Warranty, Return And Maintenance
Raycus has the right to choose to repair or replace any product that proves to be defective in materials and workmanship selectively during the warranty period. Only products with particular defects are under warranty.
