User's Guide
BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation
Modules
The BQ79616-Q1 and BQ75614-Q1 Evaluation Modules user's guide describes the general features, theory of
operation, hardware setup, and use of the BQ79616EVM and BQ75614EVM. Throughout this user's guide, the
abbreviations BMS021, EVM, and the term evaluation module are synonymous with the two different variants
of BMS021, BQ79616-Q1 Evaluation Module and BQ75614-Q1 Evaluation Module, unless otherwise noted.
When a difference is noted between the two variants, each variant is differentiated as BQ79616EVM for the
BQ79616-Q1 Evaluation Module, and the BQ75614EVM for the BQ75614-Q1 Evaluation Module. These EVMs
are evaluation boards for the BQ79616-Q1 and BQ75614-Q1 devices for use in large format lithium-ion battery
pack applications to provide monitoring, protecting, balancing, and communications.
General Texas Instruments High Voltage Evaluation (TI HV EVM) User Safety Guidelines...............................................
Description................................................................................................................................................................5
Features......................................................................................................................................................................5
Parameters..................................................................................................................................................5
2 Theory of Operation - Stackable BQ79616EVM...................................................................................................................
Board.......................................................................................................................................................................7
2.2 Stacked Systems...............................................................................................................................................................
4
Connectors............................................................................................................................................................................10
Guide..................................................................................................................................................................14
5.1 Required Devices for using the Example Code...............................................................................................................
5.2 Power Connections..........................................................................................................................................................
5.3 Connecting the EVM to TMS570 LaunchPad..................................................................................................................
BQ79616EVMs..................................................................................................................................................15
5.5 Software...........................................................................................................................................................................
5.6
GUI...................................................................................................................................................................................16
Dimensions............................................................................................................................................................17
Dimensions............................................................................................................................................................17
Mounting................................................................................................................................................................17
7 BQ79616EVM Schematic, Assembly, Layout, and BOM...................................................................................................
7.1 Schematic........................................................................................................................................................................
7.2
Assembly..........................................................................................................................................................................22
7.3 Layout..............................................................................................................................................................................
7.4 BQ79616EVM-021 Bill of Materials (BOM)......................................................................................................................
8 BQ75614EVM Schematic, Assembly, Layout, and BOM...................................................................................................
8.1 Schematic........................................................................................................................................................................
8.2
Assembly..........................................................................................................................................................................42
8.3 Layout..............................................................................................................................................................................
8.4 BQ75614EVM Bill of Materials (BOM).............................................................................................................................
9 BQ79656EVM Schematic, Assembly, Layout, and BOM...................................................................................................
9.1 Schematic........................................................................................................................................................................
9.2
Assembly..........................................................................................................................................................................53
9.3 Layout..............................................................................................................................................................................
9.4 BQ79656EVM Bill of Materials (BOM).............................................................................................................................
SLUUC37C - JULY 2019 - REVISED AUGUST 2023
Submit Document Feedback
ABSTRACT
Table of Contents
BQ75614EVM.................................................................................................................8
Connectors..............................................................................................................................10
Copyright © 2023 Texas Instruments Incorporated
Applications............................................................7
BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules
Table of Contents
3
6
7
14
14
15
15
18
18
24
33
38
38
43
44
49
49
54
55
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Texas Instruments BQ75614-Q1
Summary of Contents for Texas Instruments BQ75614-Q1
-
Page 1: Table Of Contents
When a difference is noted between the two variants, each variant is differentiated as BQ79616EVM for the BQ79616-Q1 Evaluation Module, and the BQ75614EVM for the BQ75614-Q1 Evaluation Module. These EVMs are evaluation boards for the BQ79616-Q1 and BQ75614-Q1 devices for use in large format lithium-ion battery pack applications to provide monitoring, protecting, balancing, and communications. - Page 2 Code Composer Studio ™ are trademarks of Texas Instruments. All trademarks are the property of their respective owners. BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 3: General Texas Instruments High Voltage Evaluation (Ti Hv Evm) User Safety Guidelines
General Texas Instruments High Voltage Evaluation (TI HV EVM) User Safety Guidelines General Texas Instruments High Voltage Evaluation (TI HV EVM) User Safety Guidelines WARNING Warning: To minimize risk of fire hazard, always verify and follow any specific safety instructions and application considerations related to the batteries being used in conjunction with this EVM. - Page 4 General Texas Instruments High Voltage Evaluation (TI HV EVM) User Safety Guidelines www.ti.com a. EVMs are not to be used as all or part of a production unit. The following warnings and cautions are noted for the safety of anyone using or working close to the BQ79616 EVM.
-
Page 5: General Description
BQ75614EVM module includes integrated current sense. Each system provides fast cell balancing, diagnostics, and module to controller communication. Independent protection circuitry is also provided. Please see the BQ79616-Q1 or BQ75614-Q1 data sheet for more details on each respective part. Each EVM is equipped with precision measurement and synchronous communication to enable a controller to perform State of Charge (SOC) and State of Health (SOH) estimation. -
Page 6: Theory Of Operation - Stackable Bq79616Evm
5. The host can then decide to repeat the process (back to step 2) or send commands to shutdown the BQ79616EVM and return later. BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback... -
Page 7: Single Board
View Poll Settings and then select their desired active cell configuration by using the dropdown selection below the No. of cells column. SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 8: Theory Of Operation - Standalone Bq75614Evm
Optional: a digital isolator between the host domain and the BQ75614EVM domain All commands and data are communicated with a host through UART. The BQ75614-Q1 remains idle until a command is received from the host. The BQ75614EVM can support a host PC or microcontroller (via the UART connection header). - Page 9 The host uses the current measurement data to estimate SOC and SOH. 4. If no stop command is sent, then the BQ75614-Q1 has a built-in timeout (set by the user), after which time the discharge is stopped automatically.
-
Page 10: Connectors
Figure 4-1. Molex 50-57-9422 (Reference Image Only) Table 4-1. Connector Information Designator Manufacturer Part Number Mating Connector Manufacturer:0705550056 Manufacturer:50-57-9422 Molex Digi-Key: 0705550056-ND Digi-Key:WM2920-ND BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 11 The 10-pin J17 - Serial connector is used to connect the EVM to a PC running the GUI or to a host controller. Texas Instruments recommends using the USB2ANY that is available to order through TI.com, which includes the proper 10 pin cable.
- Page 12 Name nFAULT signal from BQ79616-Q1 or BQ75614-Q1 USB2ANY 3.3V USB2ANY TX ( RX of BQ79616-Q1 or BQ75614-Q1 ) USB2ANY RX ( TX of BQ79616-Q1 or BQ75614-Q1 ) 4.1.4 GPIO or Thermistor Inputs There are 8 GPIO pins, which can either be floated, connected to a thermistor and 10k pullup, or forced to certain voltage for a measurement.
- Page 13 Connectors Table 4-6. Pin Description - J4 Name Comments GPIO1 GPIO1 Pin of BQ79616-Q1 or BQ75614-Q1 GPIO1_R Connection for GPIO1 to 10k pullup and thermistor GPIO2 GPIO2 Pin of BQ79616-Q1 or BQ75614-Q1 GPIO2_R Connection for GPIO2 to 10k pullup and thermistor...
-
Page 14: Quick Start Guide
The part numbers of the evaluation modules are LAUNCHXL2-TMS57012 and BQ79616EVM-021 (for BQ79616-Q1 evaluation) or BQ75614EVM-021 (for BQ75614-Q1 evaluation). These boards are available from the TI eStore (https://estore.ti.com/) or from your local TI sales representative. For more details and information related to the LaunchPad modules, see the specific module user's guide. -
Page 15: Connecting The Evm To Tms570 Launchpad
This firmware provided with this application note provides source code examples of the command sequences described in the BQ79616-Q1 Software Design Reference. SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 16: Gui
An initial evaluation can be more beneficial to use the graphical user's interface (GUI), which provides a point and click interface to become familiar with the BQ79616-Q1 or BQ75614-Q1. During the initial sampling phase, please contact your local TI FAE to get the latest GUI version. -
Page 17: Physical Dimensions
Bottom - Tallest component if populated (Transformers) is 0.41 in (10.5 mm) above PCB (Depopulated by default). 6.2 Board Mounting Figure 6-1 illustrates the EVM dimension drawing. Figure 6-1. Board Dimensions SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 18: Bq79616Evm Schematic, Assembly, Layout, And Bom
CELL5 CELL4 CELL4 CELL3 CELL3 CELL2 CELL2 CELL1 CELL1 CELL0 CELL0 Figure 7-1. BQ79616EVM Schematic Block Diagram BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 19 TP19 0.47uF 100k Resistors for Lower Cell Count Applications (614, 612) Figure 7-2. BQ79616EVM Schematic Part 1 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 20 BQ79616EVM Schematic, Assembly, Layout, and BOM www.ti.com Figure 7-3. BQ79616EVM Schematic Part 2 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 21 470uH ISO_COMML_P ISO_COMMH_P 470uH TP41 ISO_COMML_N COMML_N_OPT COMMH_N_OPT ISO_COMMH_N 2200pF 2200pF Figure 7-5. BQ79616EVM Schematic Part 4 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 22: Assembly
BQ79616EVM Schematic, Assembly, Layout, and BOM www.ti.com 7.2 Assembly Figure 7-6. BQ79616EVM Assembly Top BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 23 BQ79616EVM Schematic, Assembly, Layout, and BOM Figure 7-7. BQ79616EVM Assembly Bottom SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 24: Layout
BQ79616EVM Schematic, Assembly, Layout, and BOM www.ti.com 7.3 Layout Figure 7-8. BQ79616EVM Top Overlay BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 25 BQ79616EVM Schematic, Assembly, Layout, and BOM Figure 7-9. BQ79616EVM Bottom Overlay SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 26 BQ79616EVM Schematic, Assembly, Layout, and BOM www.ti.com Figure 7-10. BQ79616EVM Top Solder BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 27 BQ79616EVM Schematic, Assembly, Layout, and BOM Figure 7-11. BQ79616EVM Top Layer SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 28 BQ79616EVM Schematic, Assembly, Layout, and BOM www.ti.com Figure 7-12. BQ79616EVM Internal Signal Layer 1 - GND Plane BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 29 BQ79616EVM Schematic, Assembly, Layout, and BOM Figure 7-13. BQ79616EVM Internal Signal Layer 2 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 30 BQ79616EVM Schematic, Assembly, Layout, and BOM www.ti.com Figure 7-14. BQ79616EVM Bottom Layer BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 31 BQ79616EVM Schematic, Assembly, Layout, and BOM Figure 7-15. BQ79616EVM Bottom Solder SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 32 BQ79616EVM Schematic, Assembly, Layout, and BOM www.ti.com Figure 7-16. BQ79616EVM Drill Drawing BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 33: Bq79616Evm-021 Bill Of Materials (Bom)
#4-40 x 1/4, Nylon, Philips 0025 PH Supply panhead H5, H6, H7, Standoff, Hex, 0.5"L #4-40 Standoff 1902C Keystone Nylon SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 34 R18, R19 R9, R12 RES, 402, 1%, 0.1 W, 0603 CRCW060340 Vishay-Dale AEC-Q200 Grade 0, 0603 2RFKEA BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 35 RT1, RT2, Thermistor NTC, 10k ohm, 0603 ERT- Panasonic RT3, RT4, 2%, 0603 J1VG103GA RT5, RT6, RT7, RT8 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 36 CAP, CERM, 1 uF, 16 V, 0603 GCM188R71C MuRata +/- 10%, X7R, AEC-Q200 105KA64D Grade 1, 0603 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 37 0603 RC0603FR-07 Yageo R116, 0603 499RL R117, R118 T1, T2 BMS TRANSFORMER SMT_TRANS HMU1228NL Pulse FORMER_8M M89_10MM0 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 38: Bq75614Evm Schematic, Assembly, Layout, And Bom
0.47uF 100k Resis tors for Lower Cell Count Applications (614, 612) Figure 8-1. BQ75614EVM Schematic Part 1 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 39 TP20 0.47uF 0.47uF R113 CELL0S CELL0S R114 10.0 0.47uF CELL0 0.47uF Figure 8-2. BQ75614EVM Schematic Part 2 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 40 C3_R C9_R C15_R C2_R C8_R C14_R C1_R C7_R C13_R C6_R C12_R Figure 8-3. BQ75614EVM Schematic Part 3 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 41 ISO_COMML_P ISO_COMMH_P 470uH 470uH TP41 ISO_COMML_N COMML_N_OPT COMMH_N_OPT ISO_COMMH_N 2200pF 2200pF Figure 8-4. BQ75614EVM Schematic Part 4 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 42: Assembly
BQ75614EVM Schematic, Assembly, Layout, and BOM www.ti.com 8.2 Assembly Figure 8-5. BQ75614EVM Assembly Top BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 43: Layout
BQ75614EVM Schematic, Assembly, Layout, and BOM Figure 8-6. BQ75614EVM Assembly Bottom 8.3 Layout See section 7.3 for same drawings as for BQ79616. SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 44: Bq75614Evm Bill Of Materials (Bom)
J1, J2, J5, Header, 2.54mm, 1x2, Header, PEC01DAAN Sullins J6, J18, J21 Tin, Black, TH 2.54mm, 2x1, Connector Solutions BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 45 0603 R100ELF R40, R49, RES, 0, 5%, 0.25 W, 1206 ERJ-8GEY0R0 Panasonic R122 AEC-Q200 Grade 0, 1206 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 46 Keystone TP39 Black, TH Multipurpose Testpoint TP37, TP40 Test Point, Multipurpose, 5010 Keystone Red, TH Multipurpose Testpoint BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 47 R38, R41 R29, R30 RES, 100, 1%, 1 W, 2512 CRCW2512100 Vishay-Dale AEC-Q200 Grade 0, RFKEG 2512 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 48 RES, 499, 1%, 0.1 W, 0603 RC0603FR-074 Yageo R117, R118 0603 99RL T1, T2 BMS TRANSFORMER SMT_TRANS HMU1228NL Pulse FORMER_8M M89_10MM09 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
-
Page 49: Bq79656Evm Schematic, Assembly, Layout, And Bom
SVN Rev: Version control disabled Assembly Variant: warrant that this design will meet the specifications, will be suitable for your application or fit for any particular purpose, or will operate in an implementation. Texas Instruments and/or its Drawn By: File: BMS021E3_CoverSheet.SchDoc... - Page 50 Version control disabled Assembly Variant: Sheet: warrant that this design will meet the specifications, will be suitable for your application or fit for any particular purpose, or will operate in an implementation. Texas Instruments and/or its Drawn By: File: BMS021E3_bq79616.SchDoc Size: http://www.ti.com...
- Page 51 TP20 0.47uF 0.47uF R113 CELL0S CELL0S R114 10.0 0.47uF CELL0 0.47uF Figure 9-3. BQ79656EVM Schematic Part 2 SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 52 File: BMS021E3_Communications.SchDoc Size: http://www.ti.com not warrant that this de will meet the specifications, will be suitable for youapplication or fit for any particular purpose, or will operate in an implementation. Texas Instruments and/or its Engineer: Taylor Vogt Contact: http://www.ti.com/support ©...
-
Page 53: Assembly
BQ79656EVM Schematic, Assembly, Layout, and BOM 9.2 Assembly Components marked 'DNP' must not be populated. Figure 9-6. BQ79656EVM Assembly Top SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 54: Layout
Components marked 'DNP' must not be populated. Figure 9-7. BQ79656EVM Assembly Bottom 9.3 Layout See section 7.3 for same drawings as for BQ79616. BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... -
Page 55: Bq79656Evm Bill Of Materials (Bom)
H1, H2, H3, NY PMS 440 B&F Fastener #4-40 x 1/4, Nylon, Philips Screw 0025 PH Supply panhead SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated... - Page 56 AEC-Q200 Grade 0, 0603 0K0FKEA RES, 402, 1%, 0.1 W, CRCW06034 R9, R12 0603 Vishay-Dale AEC-Q200 Grade 0, 0603 02RFKEA BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 57 RT5, RT6, 2%, 0603 J1VG103GA RT7, RT8 Switch, SPST 8Pos, 9.65X8X22.4 S1, S2 76SB08ST Grayhill Rocker, TH SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 58 R27, R28, R38, R41 R115, R116, RES, 499, 1%, 0.1 W, RC0603FR-0 0603 Yageo R117, R118 0603 7499RL BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules SLUUC37C – JULY 2019 – REVISED AUGUST 2023 Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 59 • Changed contents of the Name column in the Pin Description table............... • Added Section 8 .............................. SLUUC37C – JULY 2019 – REVISED AUGUST 2023 BQ79616-Q1, BQ75614-Q1, and BQ79656-Q1 Evaluation Modules Submit Document Feedback Copyright © 2023 Texas Instruments Incorporated...
- Page 60 STANDARD TERMS FOR EVALUATION MODULES Delivery: TI delivers TI evaluation boards, kits, or modules, including any accompanying demonstration software, components, and/or documentation which may be provided together or separately (collectively, an “EVM” or “EVMs”) to the User (“User”) in accordance with the terms set forth herein.
- Page 61 www.ti.com Regulatory Notices: 3.1 United States 3.1.1 Notice applicable to EVMs not FCC-Approved: FCC NOTICE: This kit is designed to allow product developers to evaluate electronic components, circuitry, or software associated with the kit to determine whether to incorporate such items in a finished product and software developers to write software applications for use with the end product.
- Page 62 www.ti.com Concernant les EVMs avec antennes détachables Conformément à la réglementation d'Industrie Canada, le présent émetteur radio peut fonctionner avec une antenne d'un type et d'un gain maximal (ou inférieur) approuvé pour l'émetteur par Industrie Canada. Dans le but de réduire les risques de brouillage radioélectrique à...
- Page 63 www.ti.com EVM Use Restrictions and Warnings: 4.1 EVMS ARE NOT FOR USE IN FUNCTIONAL SAFETY AND/OR SAFETY CRITICAL EVALUATIONS, INCLUDING BUT NOT LIMITED TO EVALUATIONS OF LIFE SUPPORT APPLICATIONS. 4.2 User must read and apply the user guide and other available documentation provided by TI regarding the EVM prior to handling or using the EVM, including without limitation any warning or restriction notices.
- Page 64 Notwithstanding the foregoing, any judgment may be enforced in any United States or foreign court, and TI may seek injunctive relief in any United States or foreign court. Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2023, Texas Instruments Incorporated...
- Page 65 TI products. TI’s provision of these resources does not expand or otherwise alter TI’s applicable warranties or warranty disclaimers for TI products. TI objects to and rejects any additional or different terms you may have proposed. IMPORTANT NOTICE Mailing Address: Texas Instruments, Post Office Box 655303, Dallas, Texas 75265 Copyright © 2023, Texas Instruments Incorporated...
