- Page 1 Power supply APS-612 Firmware version 3.00 aps-612_en 10/23 SATEL sp. z o.o. • ul. Budowlanych 66 • 80-298 Gdańsk • POLAND tel. +48 58 320 94 00 www.satel.pl...
- Page 2 Changes, modifications or repairs not authorized by the manufacturer shall void your rights under the warranty. SATEL aims to continually improve the quality of its products, which may result in changes in their technical specifications and software. Current information about the changes being introduced is available on our website.
-
Page 3: Table Of Contents
CONTENTS 1. Features ..........................2 2. Description ........................3 Description of terminals ....................4 Outputs ..........................5 3. Configuration ........................5 4. Installation ......................... 5 5. Standard requirements for battery ..................8 6. Battery testing ........................9 7. Specifications ........................9... -
Page 4: Features
APS-612 SATEL The APS-612 switching power supply is designed for powering 12 VDC devices. It is provided with a connector for integration with SATEL devices. The power supply meets the requirements of EN 50131 Grade 3. If the power supply is to be integrated with the devices specified below, make sure their firmware version is at least: −... -
Page 5: Description
SATEL APS-612 • Short-circuit and overload protection of the power output. • Input interference filter. • Suitable for mounting in enclosures, as well as in distribution switchboards on 35 mm DIN rail. 2. Description Figure 1 shows the power supply enclosure. -
Page 6: Description Of Terminals
F2 slow-blow fuse (T 3.15 A) – battery charging circuit protection. connector for integration with a SATEL device provided with a connector of the same type. It is used to power the device and send information about the power supply status. -
Page 7: Outputs
SATEL APS-612 – OC type output signaling 230 VAC power loss. – OC type output signaling low battery (voltage below 11.5 V or too high internal resistance of the battery). – OC type output signaling power output overload (current consumption above 3 A). - Page 8 Before you proceed to installation, estimate the current consumption by all devices which are to be powered from the APS-612 power supply. The sum of currents consumed by these devices must not exceed 3 A.
- Page 9 SATEL APS-612...
-
Page 10: Standard Requirements For Battery
APS-612 SATEL 5. Standard requirements for battery If the alarm system is to meet the standard requirements for Grade 3, the power supply battery should ensure 30 hours of device operation. The power supply should be able to charge the battery to 80% in 24 hours. -
Page 11: Battery Testing
SATEL APS-612 Battery capacity Charging current Power supply output current Grade 3 90 Ah 60 Ah 30 Ah 3 A or 1.5 A Grade 2 18 Ah 3 A or 1.5 A 12 Ah 1.5 A 7 Ah 1.5 A 6.
