4. Battery LED
Solid blue: the battery level is sufficient.
Solid red: the battery level is low.
Blinking blue: the battery is charging. The LED
flashes in solid blue when the battery is fully charged.
OFF: the router is in the power saving mode.
5. SMS LED
Blinking blue: there is an unread message.
NOTE Log in to the web UI )see the IP address on
the label inside the router(, and locate the SMS tab to
read the message.
OFF: there is no unread message, or the router is in
the power saving mode.
6. Micro USB port
Used to connect to a power supply )5 V/1 A( through
the provided USB cable.
7. Power button
Press for 3 seconds to power on or off your router.
Press for 6 seconds to reboot your router.
Press to recover from the power saving mode.
Power saving mode
If you do not use the router buttons for three
minutes, all LEDs will automatically turn off.
