1
1. Signal LED
Solid blue: the signal is strong.
Solid purple: the signal is good.
Solid red: the signal is weak.
OFF: the signal is not available, or the router is in the
power saving mode.
2. Wi‑Fi LED
Blinking blue: WPS connection is available.
Solid blue: Wi-Fi is enabled.
OFF: Wi-Fi is disabled, or the router is in the power
saving mode.
3. WPS button
Press for 3 seconds to enable the WPS function. The
WPS function will be automatically disabled if a WPS
connection is not established within 2 minutes.
2 3
5 6 7
EN-1
4
