MikroTik CRS326-24G-2S+IN Manual

CRS326-24G-2S+IN
CRS326-24G-2S+IN

Safety Warnings

Before you work on any equipment, be aware of the hazards involved with electrical circuitry, and be familiar with standard practices for preventing
accidents.
Ultimate disposal of this product should be handled according to all national laws and regulations.
The Installation of the equipment must comply with local and national electrical codes.
Failure to use the correct hardware or to follow the correct procedures could result in a hazardous situation to people and damage to the system.
Read the installation instructions before connecting the system to the power source.

Quick start

Connect two powering units to the AC source using power cords.
The Initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility.
Use Winbox to connect to the default IP address of 192.168.88.1 from any port, with the username
choose the Neighbors tab and connect to the device using the MAC address.
We recommend clicking the "Check for updates" button and updating your RouterOS software to the latest version to ensure the best
performance and stability. The device needs to have an active internet connection.
To upgrade manually go to our download page
Choose packaged based on your device model.
Download to your PC.
Upload packages to the Files menu in WinBox and reboot the device.
Set up your password to secure the device.

Mounting

The device is designed to use indoors and it can be placed on the desktop.
The device has no protection from water contamination, please ensure the placement of the device in a dry and ventilated environment.
We recommend Cat6 cables for our devices.
Mounting and configuration of this device should be done by a qualified person.

Extension slots and ports

24 of Gigabit Ethernet ports.
Two 10G SFP+ ports.
1x RJ45 console port (set at 115200bits/s, 8 data bits, 1 stop bit no parity).
Please visit wiki pages for MikroTik SFP module compatibility and configuration table:
/MikroTik_SFP_module_compatibility_table

Powering

The device accepts power in the following ways:
https://mikrotik.com/download
https://wiki.mikrotik.com/wiki
admin
and no password. If IP is no available
