CRS328-24P-4S+RM
CRS328-24P-4S+RM
Quick start
Mount unit in a rackmount cabinet or place on the flat surface (see "
Connect to the power source (see "
The Initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility.
Set IP for your PC to 192.168.88.2
Use Winbox to connect to the default IP address of 192.168.88.1 from any port, with the username
Update the device by clicking the "Check for updates" button to v6.46 or the latest RouterOS software to ensure the best performance and
stability. The device needs to have an active internet connection.
To manually update the device, go to our download
Choose your architecture (ARM) and download the latest packages from any channel to your PC.
Open Winbox and upload packages in the Files menu.
Reboot the device.
Updating software will ensure the latest security fixes and regulations set by local law.
Set up your password to secure the device.

Mounting

The device is designed to use indoors and it can be mounted in a rackmount enclosure using provided rack mounts, or it can be placed on the desktop.
Please attach rubber pegs on the bottom of the router if the desired placement is on the flat surface or use a Phillips screwdriver to attach rackmount ears
on both sides of the device if designated use is for rackmount enclosure:
1. Attach rack ears to both sides of the device and tighten four screws to secure them in place, as shown in the picture.
2. Place the device in the rackmount enclosure and align with the holes so that the device fits conveniently.
3. Tighten screws to secure it in place.
The device has no protection from water contamination, please ensure the placement of the device in a dry and ventilated environment.
We recommend Cat6 cables for our devices.
Mounting and configuration of this device should be done by a qualified person.

Powering

CRS328-24P-4S+RM#Powering
page https://mikrotik.com/download
CRS328-24P-4S+RM#Mounting
").
").
admin and no password.
