IM7200 Quick Start Guide
The IM7200 Quick Start Guide documents installation, configuration and local operation.
01. Check the kit's contents are complete
# item
1 IM7200 Infrastructure Manager
Rack mount kit (2 ears, 4 rack screws for cage,
1
4 case nuts, & 6 screws)
2 region-specific IEC power cables
2 DC screw connector blocks
2 UTP RJ-45 patch cables
DB9F-to-RJ45, Cisco Straight-to-modem/DCE,
1
X2 pinout mode serial adapter
DB9F-to-RJ45, crossover Cisco Straight-to-PC/
1
DTE X2 pinout mode serial adapter
DB9M-to-RJ45, Cisco Straight-to-3rd-party-
1
console X2 pinout mode serial adapter
1 X2 pinout mode loopback test cable (black)
DB9F-to-RJ45, Cisco Rolled-to-modem/DCE,
1
X1 pinout mode serial adapter
DB9F-to-RJ45, Cisco Rolled-crossover-to-PC/
1
DTE X1 pinout mode serial adapter
RJ45-to-DB9M, Cisco Rolled-straight-to-3rd-
1
party-console X2 pinout mode serial adapter
1 X1 pinout mode loopback test cable (red)
1 2.4 GHz SMA Wi-Fi diversity antenna

02. Power up the IM7200 and connect other hardware

01. Power up the IM7200.
DAC models have dual universal AC power supplies with automatic failover. Use the supplied,
region-specific power cables to plug these models into mains electricity.
DDC models have dual DC power supplies with automatic failover. Use the included external
screw connector blocks to connect these models to DC power sources.
02. Connect the IM7200 to your primary network via a NET1 port.
03. For Out-of-Band (OoB) management: connect a NET2 port to a management network and acti-
vate the NET2 interface (see step 06 below).
IM7200 Quick Start Guide (520062 — revision 1.6.3)
part # links to Opengear stores
varies
590001 US UK
n/a DAC only. Not sold separately
n/a DDC only. Not sold separately
440016 US UK
319014 US UK
319015 US UK
319016 US UK
n/a Not available separately.
319017 US UK
319018 US UK
319019 US UK
n/a Not available separately.
569022 US UK
EU AU INT
EU AU INT
EU AU INT
EU AU INT
EU AU INT
EU AU INT
EU AU INT
EU AU INT
EU AU INT
