IM7216-2-24E Quick Start Guide
The IM7216-2-24E Quick Start Guide documents installation, configuration and local operation.
01. Check the kit's contents are complete
#
item
1
IM7216-2-24E Infrastructure Manager
Rack mount kit (2 ears, 4 rack screws for cage,
1
4 case nuts, & 6 screws)
2
region-specific IEC power cables
2
DC screw connector blocks
2
UTP RJ-45 patch cables
DB9F-to-RJ45, Cisco Straight-to-modem/DCE,
1
X2 pinout mode serial adapter
DB9F-to-RJ45, crossover Cisco Straight-to-PC/
1
DTE X2 pinout mode serial adapter
DB9M-to-RJ45, Cisco Straight-to-3rd-party-
1
console X2 pinout mode serial adapter
1
X2 pinout mode loopback test cable (black)
DB9F-to-RJ45, Cisco Rolled-to-modem/DCE,
1
X1 pinout mode serial adapter
DB9F-to-RJ45, Cisco Rolled-crossover-to-PC/
1
DTE X1 pinout mode serial adapter
RJ45-to-DB9M, Cisco Rolled-straight-to-3rd-
1
party-console X2 pinout mode serial adapter
1
X1 pinout mode loopback test cable (red)
1
2.4 GHz SMA Wi-Fi diversity antenna
02. Power up the IM7216-2-24E and connect other hardware
01. Power up the IM7216-2-24E.
DAC models have dual universal AC power supplies with automatic failover. Use the supplied,
region-specific power cables to plug these models into mains electricity.
DDC models have dual DC power supplies with automatic failover. Use the included external
screw connector blocks to connect these models to DC power sources.
02. Connect the IM7216-2-24E to your primary network via a NET1 port.
03. For Out-of-Band (OoB) Failover management: connect a NET2 port to a management network
and activate the NET2 interface (see step 06 below).
IM7216-2-24e Quick Start Guide (520093 — revision 1.0.0)
part #
links to Opengear stores
varies
590001
US
UK
n/a
DAC only. Not sold separately
n/a
DDC only. Not sold separately
440016
US
UK
319014
US
UK
319015
US
UK
319016
US
UK
n/a
Not available separately.
319017
US
UK
319018
US
UK
319019
US
UK
n/a
Not available separately.
569022
US
UK
EU
AU
INT
EU
AU
INT
EU
AU
INT
EU
AU
INT
EU
AU
INT
EU
AU
INT
EU
AU
INT
EU
AU
INT
EU
AU
INT
