23 TECHNICAL DATA
Sport
Rebound damping
Comfort
Standard
Sport
Spring preload
Spring rate
Weight of rider: 65 ... 75 kg (143 ... 165 lb.)
Weight of rider: 75 ... 85 kg (165 ... 187 lb.)
Weight of rider: 85 ... 95 kg (187 ... 209 lb.)
Spring length
Gas pressure
Static sag
Riding sag
Fitted length
Shock absorber oil
23.9
Fitting, inlet sleeve to throttle
valve body
Hose clamp, radiator
Remaining screws, chassis
Screw for spoiler attachment
Screw, air filter box, on subframe
Screw, combination switch
(FE 350 EU)
Screw, fuel pump
Screw, intake air temperature sen-
sor (FE 350 EU)
Screw, pressure regulator
(FE 350 EU)
Screw, start button
Screw, emergency OFF switch
(FE 350 EU)
Screw, fixed grip
Spoke nipple, front wheel
Spoke nipple, rear wheel
Remaining nuts, chassis
Remaining screws, chassis
Screw, battery terminal
Screw, brake line guide on link
fork
Screw, frame protector
Screw, ground wire in tail section
144
Chassis tightening torques
-
-
EJOT PT
EJOT PT
EJOT PT
EJOT PT
EJOT PT
EJOT PT
EJOT PT
M3
M4
M4
M4.5
M4.5
M5
M5
M5
M5
M5
M5
1.5 turns
17 clicks
15 clicks
13 clicks
12 mm (0.47 in)
39 N/mm (223 lb/in)
42 N/mm (240 lb/in)
45 N/mm (257 lb/in)
260 mm (10.24 in)
10 bar (145 psi)
37 mm (1.46 in)
110 mm (4.33 in)
477 mm (18.78 in)
Shock absorber fluid (SAE 2.5)
(50180751S1) (
2.8 Nm (2.07 lbf ft)
2.4 Nm (1.77 lbf ft)
®
K60x25‑Z
1 Nm (0.7 lbf ft)
®
K60x23/18
2.5 Nm (1.84 lbf ft)
®
K70x25
5 Nm (3.7 lbf ft)
®
K50x18
2 Nm (1.5 lbf ft)
®
K60x25-Z
2.5 Nm (1.84 lbf ft)
®
K50x18
0.7 Nm (0.52 lbf ft)
®
K60x25‑Z
2.3 Nm (1.7 lbf ft)
0.4 Nm (0.3 lbf ft)
0.4 Nm (0.3 lbf ft)
5 Nm (3.7 lbf ft)
6 Nm (4.4 lbf ft)
6 Nm (4.4 lbf ft)
5 Nm (3.7 lbf ft)
5 Nm (3.7 lbf ft)
2.5 Nm (1.84 lbf ft)
5 Nm (3.7 lbf ft)
3 Nm (2.2 lbf ft)
5 Nm (3.7 lbf ft)
p. 148)
®
Loctite
243™
