1.2.2. Display

INFRAGAS-196 in its full configuration has on the front panel 5 displays; displays are
splitted into 4 sets.
In the normal operating mode, after the first automatical calibration,displays are showing:
- CO =======> Carbon monoxide in Vol % from 0,00 to 9,99.
- CO2 =======> Carbon dioxide in Vol % from 00,0 to 19,9.
- HC =======> Hydrocarbons in ppm from 0000 to 5000.
- FUNC =====> Oxygen in Vol % from 0,00 to 21,4.
- =======>
- during warm-up time the CO display shows the PEF value, HC shows the writing
"PEF", and the FUNC display shows the Warm-up time remaning in minutes.
- during self-calibration stage CO and CO2 displays show "Cal" message on, the
FUNC display shows "ben ", the
shows "4-SP".
- in case of an insufficient flow on gas path occurs, on CO CO2 and HC displays
the messages
measurement is inhibited (see Troubleshooting chapter)
- in case of condensate excess, on CO, CO2 and HC displays the message "Con"
appears indicating that instrument has stopped. During this stage any further
action is inhibited.
The display "FUNC " is able to show several values of other measurements. Values
shows are: Oxygen, Lambda, RPM, Temperature, Barometric pressure, NO-Nitrogen
oxide, NOx - Nitrogen dioxide, CO Correct.
Measures are selected by the Keyboard using the FUNC key. The symbol that appears
on the display
ASSEMBLAD S.r.l. - Costruzioni Elettroniche - Via Marzabotto, 4 - 50013 Campi Bisenzio - Firenze - Italy
Tel. +39-055-890485 - Fax +39-055-890496 - E-mail: info@assemblad.it - Web: www.assemblad.it
= Measure selected by keyboard using the FUNC key (see
below)
"Err1", "Err2" ..... "Err5"
means:
Infragas-196 and Infragas-196 PC-Module * Operating manual
display shows "
appears. In this conditions gas
"and the HC display
