EcoxGear SOUNDEXTREME SEI-ETAMPBAT7700 20 Series User Manual

8 inch tower speakers
Hide thumbs Also See for SOUNDEXTREME SEI-ETAMPBAT7700 20 Series:
Table of Contents

Advertisement

Quick Links

Download this manual
8 inch Tower Speakers
ExtremeTower TA8
Models: SEI-ETAMP7700...20
Bluetooth Amplified
1
Tower Speaker
1
Passive Tower Speaker
2
Bluetooth Amplified Tower Speakers +
ExtremeTower
User Guide
ExtremeTower TBB8
Models: SEI-ETAMPBAT7700...20
ExtremeTower TB8
Models: SEI-ETBAT7700...20
Bluetooth Amplified
1
Tower Speaker
1
Passive Tower Speaker
1
Battery
2
Batteries

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the SOUNDEXTREME SEI-ETAMPBAT7700 20 Series and is the answer not in the manual?

Questions and answers

Related Manuals for EcoxGear SOUNDEXTREME SEI-ETAMPBAT7700 20 Series

Summary of Contents for EcoxGear SOUNDEXTREME SEI-ETAMPBAT7700 20 Series

  • Page 1 ExtremeTower 8 inch Tower Speakers User Guide ExtremeTower TA8 ExtremeTower TB8 Models: SEI-ETAMP7700...20 Models: SEI-ETBAT7700...20 Bluetooth Amplified Bluetooth Amplified Tower Speaker Tower Speaker Passive Tower Speaker Passive Tower Speaker Battery ExtremeTower TBB8 Models: SEI-ETAMPBAT7700...20 Bluetooth Amplified Tower Speakers + Batteries...
  • Page 2 ECOXGEAR audio and LED lighting EcoSystem, which includes LEDCast and EcoCast Innovations. Look for the LEDCast and EcoCast logos on the growing family of ECOXGEAR and SoundExtreme audio and lighting solutions. EcoCast-enabled audio products are designed to be paired with one or more EcoCast-enabled products.

  • Page 3: Power Mode Switch

    Switches Power Mode Switch Power Standby The Power Mode Switch (Red Switch) is located behind the rear Cover. · Remove the back Cover to view the switch. This switch modifies the Power On State when you turn on your vehicle ignition switch. ·...
  • Page 4 Buttons and LED Status Indicators Buttons and LED Status Indicators Only the Amplified Tower Speakers have Control Buttons. The Passive Tower Speakers do not have any Control Buttons and must be controlled via the connected Amplified Speakers. For models with two amplified speakers, the speakers function independently or can be paired wirelessly together via the EcoCast function.
  • Page 5 Buttons and LED Status Indicators · L and R LED Lights On: Both speakers will play the Left and Right Audio Channels (Mono). 4. Mode Button with LED Indicator · Short-press to change Modes. The Mode LED Status Indicator will change color to indicate the current Mode: ·...
  • Page 6 Buttons and LED Status Indicators · PRESS AND HOLD a Preset Button for 2 seconds to save the station that you are currently listening to to that Preset Button. 7. Play/Pause Button · Short-press to play or pause audio playback. 8.

  • Page 7: Audio Functions

    Audio Functions Connecting and Playing Bluetooth Audio 1. Turn the speaker on and place the speaker into Bluetooth Mode. 2. Short-press the Mode Button until you hear, “Speaker Mode. Ready to connect,” announced. 3. On your phone’s Bluetooth settings, select ‘SoundEx-ETA8’ to pair.

  • Page 8: Listening To Fm Radio

    Audio Functions Listening to FM Radio The first time you listen to FM Radio on your ExtremeTower Speakers, check the FM ANT Switch position to make sure it is in the correct position. If you use the Internal Antenna, the switch should be in the INT position.
  • Page 9 Speaker will receive audio from an EcoCast Transmitting speaker, soundbar, or radio. Notes: · When set to Speaker Mode, the Amplified Speaker turns the EcoCast capability off. · When you have two or more Amplified Speakers or other ECOXGEAR or SoundExtreme speakers bearing the EcoCast...
  • Page 10 Audio Functions symbol, you can build a broadcast system by initiating EcoCast Transmitting Mode in one Amplified Speaker and broadcasting your music to one or more EcoCast-enabled speakers in EcoCast Receiving Mode. EcoCast: First Two Amplified Speakers Follow the steps below to pair two Amplified Tower Speakers: 1.
  • Page 11 Audio Functions EcoCast: Additional Receiving Speakers 1. Turn on the additional EcoCast-enabled speakers (Speaker C and Speaker D) and press the Mode Button to cycle through to and initiate EcoCast Receiving Mode. The Mode LED Status Indicator will flash Green, and the speaker will announce, “EcoCast receiving.”...
  • Page 12 Audio Functions re-connect to the speaker in EcoCast Transmitting Mode (Speaker A). If they do not automatically re-connected, please follow the above steps to reconnect. · The EcoCast functionality has a maximum range of 30 feet between speakers. · While connecting the ExtremeTower Speakers, make sure that the speakers are within a few feet of each other.
  • Page 13 Audio Functions Play Audio Streams From Another EcoCast-Enabled Speaker If there is an EcoCast-enabled speaker in EcoCast Transmitting Mode nearby, you can set your Amplified Tower Speaker (Speaker A) to EcoCast Receiving Mode and play audio streams from the EcoCast Transmitting speaker (Speaker T): 1.
  • Page 14 Lighting Control Concepts LED Lighting Zones, Modes, and Scenes The Amplified ExtremeTower Speaker can also be controlled by the included SoundExtreme Universal Remote Control and the SoundExtreme Smartphone App. Below are some terms and definitions to help you better understand the Remote Control and the SoundExtreme App.
  • Page 15 Lighting Control Concepts allows you to customize each of the 20 Party Modes, allowing for nearly unlimited color, cascading, and LED chasing options. 3. Music Mode: There are 16 Music Modes accessible via the Remote Control and SoundExtreme Smartphone App. Scene A Scene is programed via the SoundExtreme Smartphone App.

  • Page 16: Rf Remote Control

    RF Remote Control Power Button Zone Buttons: Z1 · · · Z4 Audio Playback Control Buttons Common Buttons: Mode, Scene, Zone-Mode Buttons: Bright, Speed, Z1-M · · · Z4-M and Color Radio Presets and Remote Pairing Buttons: MFB, P1 · · · P3 Each Amplified ExtremeTower Speaker comes with a SoundExtreme Universal Remote Control.
  • Page 17 RF Remote Control 2. LED Lighting Control Buttons: The Amplified Tower Speaker only has two LED Lighting Zones. · Zone 1 is set for the speaker RGB LED Party Lights on the Amplified Speaker and the Passive Speaker. Zone 1 LEDs have all the LED Lighting Modes and features mentioned in Section LED Lighting Zones, Modes, and Scenes.
  • Page 18 RF Remote Control If the speaker does not react when you press a button on the Remote Control, check if the battery isolator (clear plastic strip) on the Remote battery compartment is removed (pulled out) completely. Then, follow the steps below. Remote Control Pairing 1.
  • Page 19 RF Remote Control Speaker Party Lights and Dome Light Control When the Amplified ExtremeTower Speaker is on, you can use the Remote Control to change the Party Lights and Dome Light. Zone 1: Party Lights – Lighting Mode Control 1. Press the Z1 Button. The Party Lights will briefly light up Green in ascending order and then enter Scene 1 –...
  • Page 20 Remote Functions Overview BUTTON ACTION FUNCTION Short-Press To turn on / off the Amplified speaker. Short-Press To play / pause audio. Short-Press · In Bluetooth Mode: To skip to the previous or the next track. · In FM Mode: To tune in a station. Press and Hold In FM Mode: To seek a strong station.
  • Page 21 Remote Functions Overview NOTES · If the Amplifier Tower Speaker is controlled by the vehicle ignition, when the ignition is on, the Remote can turn the Amplified Tower Speaker off or on. When the ignition is off, the Power Button does not turn the speaker on or off. ·...
  • Page 22 Remote Functions Overview BUTTON ACTION Short-Press To turn on / off Zone 1 (Party Lights). Short-Press To turn on / off Zone 2 (Dome Light). NOT APPLICABLE FOR Short-Press To cycle through the three LED Mode categories for Zone 1. Double-Click To cycle back to the previous LED Mode for Zone 1.
  • Page 23 Remote Functions Overview NOTES · When turned on, LEDs in Zone 1 will light up Green in ascending order. When turned off, the LEDs light up Red in descending order. THIS PRODUCT · There are 44 distinct LED Modes: 8 Color Modes, 20 Party Modes, and 16 Music Modes.
  • Page 24 Remote Functions Overview BUTTON ACTION FUNCTION Short-Press To cycle through the 5 defined Scenes for Zone 1. Short-Press To cycle through 5 levels of Brightness for Zone 1. Short-Press To cycle through 5 levels of Speed for Zone 1. Short-Press To select the corresponding Color for Zone 1.
  • Page 25 Remote Functions Overview NOTES · There are 8 Color Buttons on the Remote Control: Red, Green, Blue, White, Orange, Yellow, Cyan, and Purple. You can also use the SoundExtreme Smartphone App create a custom color. · Refer to Select a Speaker to Control for more details. ·...

  • Page 26: Download And Install

    SoundExtreme Smartphone App. Download and Install For iPhones, download the app from the following URL: https://apps.apple.com/us/app/soundextreme/id1670708941 For Android phones, download the app from the following URL: https://play.google.com/store/apps/details?id=com.cchip.ecoxgear Alternatively, use the following QR Codes to download the SoundExtreme Smartphone App. Android App Overview Password Secured: The app is password protected so others cannot gain access and control your ExtremeController.
  • Page 27 SoundExtreme App Create and save Scenes: A Scene is a preprogrammed light show that you can save for later quick access. We have created 5 default Scenes that are fully customizable and programmable. Set Up a Group: Create and set up a group of devices (multiple Amplified Tower Speakers, or other SoundExtreme products with LEDCast built-in).
  • Page 28 SoundExtreme App 3. If your Amplified Tower Speaker is powered on, it will show up as LEDs-ETA8 on the app’s Connect Device screen. Tap the device name on the screen. A checkmark will appear on the right. Tap the Connect button.
  • Page 29 SoundExtreme App 4. A dialog window will popup asking you to enter a password. The Amplified Speaker default password is 0000. After entering the password, click the Confirm button. The app will show the device is connected. Tap the Back button on the top-left. It will take you to the Device List screen.

  • Page 30: Set Up Zones

    SoundExtreme App Set Up Zones You can set up the LED Light Mode for Zone 1 (Party Lights) with the following steps: 1. On the Device List screen, select your Amplified Tower Speaker (LEDs-ETA8) and the app will bring you to the Zone screen.
  • Page 31 SoundExtreme App · If you tap the Save button on the screen, the app will save your setting for the selected Zone. · If you tap the Cancel button or exit the LED Mode Settings screen, your Mode selection will not be saved and LEDs connected to that Zone will display the previously selected LED Mode.
  • Page 32 SoundExtreme App Control Speaker Dome Light You can control the Amplified ExtremeTower Speaker Dome Light with the following steps: 1. On the Device List screen, select your Amplified Tower Speaker (LEDs-ETA8) and the app will bring you to the Zone screen. 2.

  • Page 33: Set Up Scenes

    SoundExtreme App Set Up Scenes 1. On the Device List screen, select your Amplified ExtremeTower Speaker (LEDs-ETA8) and the app will bring you to the Zone screen. Tap the Scene tab. The app will show 5 predefined scenes on your Amplified Tower Speaker.

  • Page 34: Change Password

    SoundExtreme App Change Password To add extra security, you can change the default password of 0000 to your desired 4-digit numeric password. Please note that the password is stored in your Amplified ExtremeTower Speaker, not the SoundExtreme App. So, after you change the password, please make a note in case you forget your password.

  • Page 35: Factory Reset

    SoundExtreme App 5. If the change is successfully saved, the app will display a confirmation message. This is a one-time event. You do not have to enter in your password every time you launch the app, as your app will remember your password.

  • Page 36: Specifications

    Specifications Dimensions Weight - Passive Speaker 9.66 lbs / 4.38 kg (with mount); 8. 1 6 lbs / 3.7 kg (without mount) Weight - Amplified Speaker without Battery 10.32 lbs / 4.68 kg (with mount); 8.82 lbs / 4 kg (without mount) Audio Output Power 300 Watt max (100 Watt RMS)
  • Page 37 Specifications Power Input Battery Charger 12V, 20A (if included) - Input 100 - 240VAC 50/60Hz, 0.6A Blade Fuse 20A, 32V Battery Charger (if included) - Output Speaker Party Lights 12V, 2.0A Addressable RGB LEDs Storage Temperature Rechargeable Battery Pack -40°F to 122°F / -40°C to 50°C (if included) - Power Operating Temperature 12V, 13.4Ah Lithium-Ion...

  • Page 38: Important Legal Information

    Important Legal Information FCC STATEMENT: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1.) This device may not cause harmful interference, and 2.) This device must accept any interference received, including interference that may cause undesired operation. WARNING: Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment.
  • Page 39 4.) Store your unit with all caps properly sealed to avoid long term internal moisture damage inside your unit. 5.) Completely dry and clean your ECOXGEAR prior to attempting to charge the unit. 6.) Return the unit to SoundExtreme if you suspect water ingress into the unit or if the unit has experienced a severe impact that may have affected the integrity of the unit to take on water.
  • Page 40 ExtremeTower by SoundExtreme Inc., Houston, Texas. Designed in Texas. Made in China. This product is protected under patent US 9,307,307 B2 and several patents pending.
