ASSEMBLY INSTRUCTIONS FOR
THE HG935 LAT MACHINE
The HG935 consists of the DF906 Lat
Machine, the DF832 Pec Attachment and
the DF935 Stack Kit
(888) 258-0533
FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY
*NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HG935 and is the answer not in the manual?

Questions and answers

Related Manuals for Deltech Fitness HG935

Summary of Contents for Deltech Fitness HG935

  • Page 1 The HG935 consists of the DF906 Lat Machine, the DF832 Pec Attachment and the DF935 Stack Kit (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 2 REVOLVING CHROME ROW BAR QTY 1 ASSEMBLY REVOLVING CHROME INSTRUCTIONS LAT CABLE LAT BAR QTY 1 QTY 2 QTY 1 *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 3 QTY 1 QTY 1 QTY 1 HARDWARE PACK FLANGE OLYMPIC ADAPTER ROLLER PAD QTY 1 QTY 2 QTY 2 QTY 2 *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 4 3-1/2” PULLEY PULLEY BUSHING SNAP HOOK QTY 3 QTY 6 QTY 5 (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 5 DF906 HARDWARE M10 x 76MM BOLT M10 x 43MM BOLT CHAIN M10 x 67MM QTY 5 QTY 4 QTY 1 CARRIAGE BOLT QTY 7 M10 LOCKNUT M10 WASHER RUBBER M10 x 25MM BOLT QTY 23 QTY 16 BUMPER QTY 6 QTY 1 REDUCER QTY 2...

  • Page 6: Bottom Frame Assembly

    BOTTOM FRAME ASSEMBLY (NOTE: THE NUTS USED ON THIS BENCH ARE LOCK NUTS, THIS MEANS YOU MUST TIGHTEN THEM DOWN PAST THE PLASTIC INSERT.) TOOLS REQUIRED: METRIC WRENCHES OR SOCKET SET Some components may be pre-installed from the factory ATTACH THE FOOT (N) TO THE BOTTOM FRAME (C) USING THE M10 x 76MM BOLTS (FF), M10 WASHERS (II), AND M10 LOCKNUTS (JJ).

  • Page 7: Seat Frame Assembly

    SEAT FRAME ASSEMBLY ATTACH THE SEAT PAD (H) TO THE SEAT BRACKET (I) USING THE M10 x 25MM BOLTS (HH) AND THE M10 FLAT WASHERS (II). THEN SLIDE THE SEAT BRACKET (I) INTO THE SEAT SUPPORT (J). (WAIT TO COMPLETE THE FOLLOWING STEP UNTIL THE CABLES ARE INSTALLED) INSTALL THE 4 ½”...
  • Page 8 LEG HOLD DOWN ASSEMBLY SLIDE THE HOLD-DOWN TUBE (L) INTO THE HOLD-DOWN SUPPORT (M) NEXT SLIDE THE LEG PAD TUBE (O) INTO THE HOLD-DOWN TUBE (L). THEN SLIDE THE ROLLER PADS (P) OVER THE LEG PAD TUBE (O) AND INSERT THE PLASTIC CAPS (U).

  • Page 9: Floating Pulley Assembly

    FLOATING PULLEY ASSEMBLY ASSEMBLE THE FLOATING PULLEY ASSEMBLY BY USING 4-1/2” PULLEYS (Y), FLANGES (Q), M10 x 43 BOLTS (GG), M10 WASHERS (II), AND M10 LOCKNUTS (JJ).
  • Page 10 UPPER PULLEY FRAME ASSEMBLY (NOTE: THE NUTS USED ON THIS BENCH ARE LOCK NUTS, THIS MEANS YOU MUST TIGHTEN THEM DOWN PAST THE PLASTIC INSERT.) ASSEMBLE THE 3 ½” PULLEYS (AA) INTO THE UPPER PULLEY FRAME (G) USING THE M10 x 76MM BOLTS (FF), M10 NUTS (JJ) AND PULLEY BUSHINGS (BB). ( DO NOT TIGHTEN AT THIS TIME- YOU WILL NEED TO REMOVE THEM TO INSTALL THE CABLE) INSTALL THE 2”...
  • Page 11 UPPER PULLEY FRAME INSTALLATION ASSEMBLE THE UPPER PULLEY FRAME ASSEMBLY ONTO THE FRONT AND BACK SUPPORTS (A,B) USING THE M10 x 25MM BOLTS(HH) AND M10 WASHERS (II)

  • Page 12: Final Assembly

    FINAL ASSEMBLY MAIN FRAME ASSY LEG HOLDDOWN ASSY SEAT FRAME ASSY BOTTOM FRAME ASSY LAY THE BOTTOM FRAME ASSEMBLY ON ITS SIDE. ATTACH THE MAIN FRAME AS- SEMBLY, THE LEG HOLDDOWN ASSEMBLY, AND THE SEAT FRAME ASSEMBLY USING THE M10 x 67MM CARRIAGE BOLTS (EE), M10 WASHERS (II), AND M10 LOCK- NUTS (JJ).
  • Page 13 ASSEMBLY INSTRUCTIONS FOR THE DF935 STACK KIT (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 14 QTY 2 TOP PLATE AS- QTY 1 SEMBLY QTY 1 200 LB WEIGHT STACK HARDWARE QTY 1 PACK QTY 1 *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 15 WEIGHT STACK RUBBER DOUGHNUTS QTY 2 QTY 2 ADJUSTMENT PIN QTY 1 (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...

  • Page 16: Lower Frame Assembly

    LOWER FRAME ASSEMBLY INSTALL THE RUBBER CAPS (F) 0NTO THE BOTTOM SUPPORT(B). ATTACH THE BOTTOM SUPPORT (B) TO THE LAT MACHINE USING THE 3/8” x 3” BOLTS (G) THE 3/8” FLAT WASHERS (H) AND THE 3/8” LOCK NUTS (I).

  • Page 17: Weight Stack Assembly

    WEIGHT STACK ASSEMBLY INSTALL THE RUBBER DOUGHNUTS (L) ONTO THE BOTTOM OF THE CHROME RODS (C) , LEAVING APPROXIMATELY 2” PROTRUDING. INSERT THE CHROME RODS INTO THE TWO OUTER HOLES IN THE BOTTOM SUPPORT. ASSEMBLE THE WEIGHT STACK (E) BY SLIDING EACH PLATE OVER THE CHROME RODS (C) AND ON TO THE BOTTOM SUPPORT.
  • Page 18 WEIGHT STACK ASSEMBLY WEIGHT STACK ASSEMBLY INSTALL THE UPPER SUPPORT ASSEMBLY (B) TO THE LAT MACHINE USING 3/8” x 3” BOLTS (G), 3/8” WASHERS (H), AND 3/8” LOCKNUTS (I). ATTACH THE UPPER SUPPORT FRAME ASSEMBLY TO THE CHROME RODS USING 3/8” x 1” BOLTS (M).
  • Page 19 UPPER CABLE INSTALLATION UPPER PULLEY FRAME REMOVED FOR CLARITY NOTE: UPPER CABLE IS SHORTER THAN THE BOTTOM CABLE FLOATING PULLEY ASSEMBLY INSTALL UPPER CABLE OVER FRONT PULLEY, BACK TO REAR PULLEY, DOWN TO TOP PULLEY OF FLOATING PULLEY ASSEMBLY, UP TO STACK ASSEMBLY PULLEY AND DOWN TO SELECTOR ROD ASSEMBLY.
  • Page 20 LOWER CABLE INSTALLATION FLOATING PULLEY ASSEMBLY INSTALL LOWER CABLE UNDER FRONT PULLEY, THROUGH SEAT FRAME, LEG HOLD DOWN FRAME, FRAME POLE, AND BACK TO REAR PULLEY. CONTINUE UP AND OVER LOWER PULLEY OF FLOATING PULLEY ASSEMBLY. ATTACH 8MM SNAP HOOK TO END OF CABLE AND THEN TO FRAME POLE BRACKET.
  • Page 21 ADJUSTING THE WEIGHT STACK: MAKE SURE LAT BAR IS RESTING IN CATCH BEFORE CHANGING WEIGHT STACK PIN LOCATION.
  • Page 22 ASSEMBLY INSTRUCTIONS FOR THE DF832 PEC ATTACHMENT (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 23 DF832 BOX CONTENTS ARM MOUNT SWIVEL PULLEY FIXED PULLEY SWIVEL PULLEY QTY 1 MOUNT BRACKET BRACKET BRACKET QTY 1 QTY 1 QTY 2 RIGHT HAND CAM LEFT HAND CAM FLOATING PULLEY ARM PAD QTY 1 QTY 1 BRACKET QTY 2 QTY 1 CABLE BACKREST PAD...
  • Page 24 M10 LOCK NUT QTY 2 QTY 2 QTY 2 QTY 8 (888) 258-0533 FOR YOUR SAFETY READ ALL INSTRUCTIONS CAREFULLY *NOTE IF YOU ARE MISSING HARDWARE OR HAVE ANY FIT UP PROBLEMS PLEASE CONTACT DELTECH FITNESS TOLL FREE (888) 258-0533...
  • Page 25 ARM & PULLEY MOUNT INSTALLATION FRONT OF MACHINE TOOLS REQUIRED: WRENCHES OR METRIC SOCKET SET ASSEMBLE THE ARM MOUNT (A) AND THE SWIVEL PULLEY MOUNT BRACKET (D) TO THE FRONT SUPPORT OF THE LAT MACHINE USING THE M10 x 75MM BOLTS (R), M10 FLAT WASHERS (W) AND M10 LOCK NUTS (AA) NOTE: THE NUTS USED ON THIS PRODUCT ARE LOCK NUTS SO YOU MUST USE A WRENCH TO TIGHTEN THE BOLT.
  • Page 26 CAM & ARM PAD ASSEMBLY INSTALL THE ROLLER PADS (H) ON THE ARMS (K,J). (NOTE IT MAY HELP TO TAKE A DAMP CLOTH AND WET THE ARM BEFORE SLIDING THE PAD ON THE ARM) NEXT INSTALL THE CAMS (E,F) ON THE ARMS. THERE IS A LEFT HAND AND A RIGHT HAND SIDE SO YOU WILL NEED TO LOOK AT THE DIAGRAM TO ENSURE CORRECT INSTALLATION NOW INSERT THE 2”...
  • Page 27 ARM INSTALLLATION INSERT THE ARM BUSHINGS (N) INTO THE ARM MOUNT (A). NOW ASSEMBLE THE WEIGHT ARMS TO THE ARM MOUNT (A) USING THE M19 LOCKNUTS (Y)

  • Page 28: Swivel Pulley Assembly

    SWIVEL PULLEY ASSEMBLY ASSEMBLE THE 4 ½” PULLEY (P) INTO THE SWIVEL PULLEY BRACKET (C) USING THE M10 x 50MM BOLT (S), M10 WASHERS (W), AND M10 LOCKNUT (AA). REPEAT FOR OTHER SWIVEL PULLEY ASSEMBLY. SWIVEL PULLEY INSTALLATION INSTALL THE SWIVEL PULLEY ASSEMBLIES TO THE MOUNT BRACKET USING THE M12 x 190MM BOLTS (Q), M12 WASHERS (V), AND...
  • Page 29 FIXED PULLEY ASSEMBLY INSTALL THE 4 ½” PULLEY(P) INTO THE FIXED PULLEY BRACKET (B) USING THE M10 x 50MM BOLT (S) M10 WASHERS (W), AND M10 LOCK NUT (AA). FIXED PULLEY & BACKREST INSTALLATION ASSEMBLE THE BACKREST PAD (I) TO THE FRONT SUPPORT OF THE LAT MACHINE USING THE M8 x 70 BOLTS(T) AND THE M8 FLAT WASHERS (X).
  • Page 30 FLOATING PULLEY ASSEMBLY ASSEMBLE THE 4 ½” PULLEY (P) TO THE FLOATING PULLEY BRACKET (G) USING THE M10 x 50MM BOLT (S), M10 WASHERS (W) AND M10 NUT (AA).

  • Page 31: Cable Installation

    CABLE INSTALLATION SWIVEL PULLEY ASSEMBLIES FIGURE A FLOATING PULLEY ASSEMBLY ATTACH THE PEC CABLE TO THE CAM ON THE LEFT SIDE USING THE M8 x 25MM BOLT, M8 WASHERS , AND M8 LOCKNUT. (SEE FIGURE A) NOTE: THERE ARE ADJUSTMENT HOLES ON EACH CAM TO COMPENSATE FOR CABLE STRETCH AFTER THE MACHINE IS USED FOR A WHILE.
  • Page 32 CABLE INSTALLATION RE-ATTACH LOWER CABLE HERE DISCONNECT LOWER CABLE FROM HERE DISCONNECT THE LOWER CABLE ALREADY ATTACHED TO THE MACHINE AND RUN IT THOUGH THE FIXED PULLEY AND RE-ATTACH IT TO THE RING AT THE BOTTOM OF THE FLOATING PULLEY ASSEMBLY. MAKE SURE ALL YOUR BOLTS ARE TIGHT BEFORE USE.

  • Page 33: Safety Notice

    SAFETY NOTICE WARNING: THE USER OF THIS WEIGHT EQUIPMENT ASSUMES THE POSSIBILITY OF INJURY BY EXERCISING ON THIS EQUIPMENT. THE POSSIBILITY OF RISK CAN BE REDUCED BY ALWAYS FOLLOWING THESE SIMPLE RULES: 1) BEFORE BEGINNING ANY EXERCISE PROGRAM, CONSULT YOUR DOCTOR FOR A COMPLETE PHYSICAL EXAMINATION AND SUGGESTED EXERCISE PROGRAM SPECIFIC FOR YOU.
