H RESOLUTION Adjusts the horizontal size of the image.
VGA, RGB/HV inputs only
V RESOLUTION Adjusts the vertical size of the image.
VGA, RGB/HV inputs only
INPUT RESOLUTION If there is a problem with signal detection, this function forces the monitor to display the
signal at the desired resolution. After selection, execute "AUTO SETUP" if required.
VGA, RGB/HV inputs only
If no problem is detected, the only available option will be "AUTO".
ZOOM MODE Select the aspect ratio of the screen image.
All inputs except TV*
BASE ZOOM
16:9 For input sources that have a 16:9 aspect ratio.
HDMI, DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2, S-VIDEO inputs only
14:9 For input sources that have a 14:9 aspect ratio.
HDMI, DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2, S-VIDEO inputs only
DYNAMIC Expands 4:3 picture to fill the screen. Some of the image is lost due to expansion.
HDMI, DVD/HD1, DVD/HD2, SCART, VIDEO1, VIDEO2, S-VIDEO inputs only
OFF Selecting "OFF" will display the image in a 1 by 1 pixel format. (If the input resolution is
higher than a 1360 x 768 resolution, the image will be scaled down to fit the screen.)
All inputs, except TV*
CUSTOM Displays an image as large as possible without changing the aspect ration.
All inputs, except TV*
ZOOM** Maintains the aspect ratio while zooming.
H ZOOM** Amount of horizontal zoom. Can be adjusted for each BASE ZOOM setting.
V ZOOM** Amount of vertical zoom. Can be adjusted for each BASE ZOOM setting.
H POS** Horizontal position. Can be adjusted for each BASE ZOOM setting.
V POS** Vertical position. Can be adjusted for each BASE ZOOM setting.
ASPECT Selects picture aspect, [FULL], [NORMAL], [WIDE] and [ZOOM]. See page 17.
ADJUST RESET Resets the following settings within the ADJUST menu back to factory setting:
AUTO ADJUST, H POSITION, V POSITION, CLOCK, CLOCK PHASE, H RESOLUTION,
V RESOLUTION, ZOOM MODE, ASPECT.

AUDIO

BALANCE
(Not available)
TREBLE
(Not available)
BASS
(Not available)
PIP AUDIO Selects source of PIP audio.
LINE OUT Selecting "VARIABLE" enables control of the line out level with the VOLUME button.
SURROUND Artificial surround sound.
(Not available)
AUDIO INPUT Selects audio input source [IN1], [IN2], [IN3], [DPORT], [HDMI], [TV]*, [OPTION]*.
AUDIO RESET Resets "AUDIO" options back to factory settings.

SCHEDULE

OFF TIMER Sets the monitor to power off after a length of time.
A time between 1 to 24 hours is available.
SCHEDULE SETTINGS Creates a working schedule for the monitor to use.
SCHEDULE LIST List of schedules.
DATE & TIME Sets the date, time, and daylight saving region. Date & time must be set in order for the
"SCHEDULE" function to operate. See page 27.
YEAR Configures the year for the real time clock.
MONTH Configures the month for the real-time clock.
DAY Configures the day for the real-time clock.
TIME Configures the time for the real-time clock.
DAYLIGHT SAVING Configures daylight savings on or off.
*: The product you purchased may not have this feature.
English-21
-
-
AUTO
-
CUSTOM
1.00
1.00
1.00
0%
0%
FULL
-
-
-
-
MAIN AUDIO
FIXED
-
Depend on signal input
-
OFF
-
-
-
-
-
-
OFF
**: 16:9, 14:9, CUSTOM only
