- Page 1 OWNER´S MANUAL 2000.4...
-
Page 2: Table Of Contents
Introduction..............................3 Package contents ............................3 Safety instructions ............................4 Assembling and Disassembling the plastic cover..............5 Panels description Audio inputs and controls .................... 6 Power inputs and audio outputs................7 Installation sequence..........................8 Electrical Dimensioning........................... 9 Audio inputs RCA inputs ..........................9 Wiring diagram Four channels wiring diagram ................ -
Page 3: Introduction
INTRODUCTION Dear Consumer, Congratulations, you have just acquired a SounDigital product of the highest technology and quality, so we thank you for your trust. SounDigital products are made with raw materials of the highest quality standards, and the most modern processes, equipment and technology are used in their production. -
Page 4: Safety Instructions
Wear gloves, safety glasses firmly. Avoid fixing to metallic and all necessary PPE during parts of the vehicle, as this the installation of SounDigital procedure may cause ground amplifiers. looping (noise); THIS "WARNING" SIGN ALERTS THE USER OF IMPORTANT INFO. NOT FOLLOWING THESE INSTRUCTIONS MAY CAUSE INJURIES TO THE USER OR DAMAGE TO THE EQUIPMENT. -
Page 5: Assembling And Disassembling The Plastic Cover
ASSEMBLING AND DISASSEMBLING THE PLASTIC COVER The plastic covers have the function of finishing and hiding the amplifier fixing screws. To disassembling and assembling them, follow the instructions below. DISASSEMBLING OF THE PLASTIC COVER 1. Carefully pull out the top of the plastic cover to release the upside latches, as shown in picture 1. 2. -
Page 6: Panels Description
PANELS DESCRIPTION Blue "POWER ON" LED indicator CH /CH Crossover switch key High Pass – Full – Low Pass CH1/CH2 CH /CH Variable Gain control CH1/CH2 Audio input – RCA connectors... -
Page 7: Power Inputs And Audio Outputs
PANELS DESCRIPTION 13 14 15 16 17 18 19 20 +12 VDC Positive power supply connector (+12VDC) Remote power supply connector (REM) Negative power supply connector (GND) Negative speaker connector (-) Speakers output connectors Positive speaker connector (+) Positive speaker connector (+) Speakers output connectors Negative speaker connector (-) -
Page 8: Installation Sequence
INSTALLATION SEQUENCE BEFORE PROCEEDING WITH THE INSTALLATION, UNPLUG THE NEGATIVE TERMINAL FROM ALL OF THE BATTERIES, TO AVOID FIRE, DAMAGE TO THE AMPLIFIER AND THE USER HIMSELF. Warning! Ø Mount the amplifier in such a way you have access to the connectors; Ø... -
Page 9: Electrical Dimensioning
ELECTRICAL DIMENSIONING AND AUDIO INPUTS ELECTRICAL DIMENSIONING For proper operation of your SounDigital amplifier, you need the proper dimensioning of the electrical system and the cables used. The table below shows the minimum section of GND cables, +12VDC cables and speaker output cables according to the power generated by the amplifier. -
Page 10: Wiring Diagram
WIRING DIAGRAM 4 CHANNELS WIRING DIAGRAM (Per channel) REMOTE In case of connections with more than one battery, see the installation diagram page 13 +12 VDC All RCA inputs must be connected for the amplifier to work properly. If the signal source is a mono type, use a "Y"... -
Page 11: Two Channel Wiring Diagram
WIRING DIAGRAM / GAIN SETTING CHANNELS WIRING DIAGRAM ( Bridge) REMOTE In case of connections with more than one battery, see the installation diagram page 13 +12 VDC All RCA inputs must be connected for (BRIDGE) the amplifier to work properly. If the signal source is a mono type, use a "Y"... -
Page 12: Crossovers Set Up
CROSSOVER SET UP "F" All the frequencies will be reproduced "LP" Frequencies below 80Hz will be reproduced "HP" Frequencies above 80Hz will be reproduced Change the switch to "F" position (Full Range) - All the frequencies will be Ø reproduced as in "Figure 1"; -3dB 22kHz Change the switch to "HP"... -
Page 13: Battery Connection Diagram
BATTERY CONNECTION DIAGRAM When necessary the association of one or more battery banks to supply the necessary current to the amplifier, it is recommended to use batteries of the same brand, model, and if possible the same manufacturing lot so that the system has the maximum performance. -
Page 14: Parameters
The values presented are based on measurements performed in Updates of information made in this document will always be SounDigital's laboratories. All the equipment used in the assays, tests, published and made available for consumer consultation, free of measurements and gauging of the technical parameters of SounDigital charge, on the brand's websites.
