INSTALLATION
SPECIFICATIONS
Tornado 1 unit (AK8100S)
26-19/32"
10-5/16"
9-27/32"
11-3/16"
11-3/16"
27-9/16"
2-3/8"
27-9/16"
1/2" Elec. K.O.
6"
C/L
cut out dimension
26-7/8"
(cut-out)
Get other manuals https://www.bkmanuals.com
SPECIFICATIONS
Tornado 2 unit (AK8200S)
15-9/32"
1-3/8"
16-3/16"
5-1/8"
10-5/8"
(cut out)
= cut out dimension
Page 4
INSTALLATION
33-7/16"
34-7/16"
7-7/8"
34-7/16
8"
C/L
cut out dimension
33-1/2"
(cut out)
16-3/16"
2-13/16"
2"
1/2"Elec. K.O.
10"
15-3/8"
(cut out)
= cutout dimension
