- Page 1 Technical Support and E-Warranty Certificate www.vevor.com/support BOTTLE JACK We continue to be committed to provide you tools with competitive price. "Save Half", "Half Price" or any other similar expressions used by us only represents an estimate of savings you might benefit from buying certain tools with us compared to the major top brands and doses not necessarily mean to cover all categories of tools offered by us.
- Page 2 CustomerService@vevor.com This is the original instruction, please read all manual instructions carefully before operating. VEVOR reserves a clear interpretation of our user manual. The appearance of the product shall be subject to the product you received. Please forgive us that we won't inform you again if there are any technology or software updates on our product.
- Page 3 OPERATION INSTRUCTIONS: +To raise: Using the slotted opening at the end of the handle, turn the release-valve clock wise to tighten it. And then put the jack under the load to be lifted. Turn the adjustable screw rod until it contacts with the load, Put the handle in the pressing handle holder and press up the down;...
- Page 4 WARNING BE SURE ALL TOOLS AND PERSONNEL ARE CLEAR BEFORE LOWERING LOAD，DANGEROUS DYNAMIC SHOCK LOADS ARE CREATED BY QUICKLY OPENING AND CLOSING THE RELEASE VALVE AS THE LOAD IS BEING LOWERED THE RESULTING OVERLOAD MAY CAUSE HYDRAULIC SYSTEM FAILURE, WHICH COULD CAUSE SEVERE PERSONAL INJURY AND/OR PROPERTY DAMAGE.
- Page 5 Adding oil 1. With saddle fully lowered and pump piston fully depressed,set jack in its upright,level position. Remove oil filler plug. 2. Fill until oil is level with the filler plug hole,reinstall oil filter plug. Changing oil For best performance and longest life , replace the complete fluid supply at least once per year.
- Page 6 Structural composition PART LIST ITEM ITEM DESCRIPTION DESCRIPTION WIRE PIN "O" RING STEEL BALL 1/4" PISTON SEAL "O" RING GASKET - 5 -...
- Page 7 BACK-UP RING CYLINDER U-SEAL RELEASE VALVE PISTON PUMP SEAL GASKET SCREW PLUG ADDING "O" RING HANDLE SCREW SOCKET COMPRESSION OIL TANK SPRING SEAL BACKING PIN TOP TANK STEEL BALL 3/16" "O" RING BASE FRONT PISTON ROD HANDLE ,LOWER REAL HANDLE, BACK-UP RING LOWER Parameter table...
- Page 8 Technical Support and E-Warranty Certificate https://www.vevor.com/support Made In China...
