- Page 1 QUICK START INSTRUCTIONS HLF 2700 Touch Screen QUICK START INSTRUCTIONS ENGLISH Part Code: 9BQE27G07 Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
-
Page 2: Quick Start Instructions
These Operating Instructions must be read and applied by anyone performing work with or on the equipment described. In particular, it is imperative that all such persons familiarise themselves with the safety instructions. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design... -
Page 3: Installation
• Exposing it to rain, excessive cold or heat, or damp places Receiving the unit NOTE Before to open the box of the HLF 2700 coffee maker, check out the packaging to be sure there is no damage. If damage is noticed, place a claim with the freight forwarder immediately. - Page 4 Extract the coffee hopper/s from the box and install it in the neck on the top lid of the HLF 2700 coffee machine, turn it clockwise until the micro fits into the hole (see image below).
- Page 5 Unscrew all the feet (A) supporting the coffee machine; screw the foot (B) (accessory) to foot (A); fix the support under the machine and repeat for the other 3 supports. (See image below) Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 6 WARNING Don’t try to operate the HLF 2700 coffee maker in case of presence of internal damages. Even if the damages are minimal, it’s strongly recommended to leave the unit disconnected from the power supply and call the technical service.
- Page 7 Refer to the national laws of your country for the connection to the water line. To connect the water line to the HLF 2700, is necessary to use a tube with a female screw of ¾ of inch at each end of it, as showed on the following picture.
- Page 8 QUICK START INSTRUCTIONS Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 9 Then make a hole in the plastic drip tray (see image below). In this way the liquid collected, will be discharged externally through the tube that was previously connect ed (previous step). Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 10 It is possible to download the coffee grounds directly into a larger drawer, external to the machine. • Insert the grounds discharge channel into the compartment located underneath the coffee group (see image below). Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 11 QUICK START INSTRUCTIONS WARNING Refer to planning diagram for the hole positioning. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 12 Insert the power cord on the back of the machine near to the main power switch. WARNING INSERT THE POWER CORD INSIDE A CORRECT WALL PLUG, WITHOUT USING ANY OTHER ELECTRIC ADAPTER. THE USE OF EXTENSION CORDS, ADAPTERS AND/OR MULTIPLE PLUGS IS STRONGLY FORBIDDEN! Loading products Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 13 Remember to open the beans stopper located at the bottom of the coffee beans hopper. (see image A below). NOTE At first installation, strong pull the stopper so that the pin is completely pulled out (see image B below) Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 14 It’s recommended to use a mix of coffee beans for automatic coffee makers, in order to avoid a rapid consumption of the grinder’s blades and also to get the best performance for the HLF 2700 For information refer to a coffee beans dealer. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 15 It’s recommended to do always this operation taking the powder canisters out of the machine, in order to keep the interior of the machine clean from dust. Place back each container in its original position. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 16 Fill up the detergent tank with HLF blue alkaline detergent. Take off the top lid, open the front door and screw the knobs on the left. Remove the top of the tank (as the image below) Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 17 QUICK START INSTRUCTIONS Lift the lid of the tank and disconnect the connection pipe from the tank. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 18 QUICK START INSTRUCTIONS From now it is possible to take out the tank and refill it. IT IS IMPORTANT TO REMOVE THE TANK FROM ITS COMPARTMENT TO REFILL IT Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 19 When the detergent tank needs to be refilled, you will see this alarm in the main screen: If the alarm is still showing, press on the Reset button to show the detergent tank refill request. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 20 We recommended to use a funnel to refill the tank, in this way the detergent can’t goes out. When the tank is empty, reposition it and put the lid on and screw the knobs. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 21 1.2.4.4 Milk WARNING Refer to paragraph 2.2.1.3 for the proper use of the milk with HLF 2700 machine. Open the door of the machine and take out the clear pipe from the inside. Open the fridge door and pass the pipe through the milk tube hole on the side of the machine and then through the hole on the side of the fridge Q.S.I.
- Page 22 QUICK START INSTRUCTIONS Connect the pipe to the black plug of the milk container as indicated on the image below Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 23 QUICK START INSTRUCTIONS Then close the door of the machine and of the fridge. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 24 QUICK START INSTRUCTIONS CAUTION When pouring milk into the container, pay attention to hygiene to ensure that no contaminated milk enters the system. The milk container must be clean and dry. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
-
Page 25: Quick Start Instructions
It means that an Hydraulic Loading has to be run in order to load water into all the hydraulic circuits. Push on the Start button to start the Hydraulic Loading procedure. This operation will take about 5 minutes. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design... - Page 26 QUICK START INSTRUCTIONS If the below screen shot will appear, push on the error icon (top right corner). The following screen shot will appear. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 27 Push on the FLOW METER KO alarm and the following screen shot will appear. This happened because at the first initial water fill in of the machine, the water doesn’t arrive directly to the boiler. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 28 QUICK START INSTRUCTIONS After the press of the RESET button the machine will load the boiler, and the Hydraulic Loading screen will be shown again. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 29 QUICK START INSTRUCTIONS Initial heating Once the cleaning cycle is finished, the following screen will appear. Push on the message icon (top right corner), and you will see the following screenshot: Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 30 When the notification icon disappears, the machine is ready to work. At this point it is possible to: • start delivering drinks • access the software and consult the instruction manual as follows: Push the top left corner. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 31 QUICK START INSTRUCTIONS Then push Main Menu key. Enter the password: 123456 and push OK. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 32 Push Manual. The application will check the version of the instruction manual. If a more recent version will be found (internet connection is required), you will be asked to start the download. Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 33 The possible operations to do are the following: to scroll to the previous page to scroll to the next page to access the manual index and select a section to search words Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 34 1.3.4 Instructions Manual Scan the below QR Code or click on the following link to access the instructions manual of the machine: https://kutt.it/IM-2700_NEW-Eng Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
- Page 35 QUICK START INSTRUCTIONS Q.S.I. HLF 2700 Eng V07-2021 HLF Italian Design...
