3600
Bean to Cup Coffee Machine
Welcome
Thank you for your purchase of the 3600, please follow this guide to ensure that you
get the maximum usage and efficiency from your machine for many years to come.
In addition to the training you received upon installation, please also read the
guidelines given in this document with regard to the cleaning procedures for your
machine.
We cannot stress enough the importance of cleaning the machine correctly and on a
daily basis in order to ensure it's continuing performance and efficiency. It is a fact that
95% of the breakdown calls we receive are due to improper or lack of regular cleaning.
If you have any queries/problems with anything in this guide, please call our helpdesk on 0845 4500 498
Failure to clean your machine properly will
invalidate your warranty
in the event of a breakdown.
General guide lines
C A U T I O N - Drip Tray Full
Carefully remove the drip tray and empty, this is a good time to give it a quick rinse.
Replace and the caution will clear.
C A U T I O N - Grounds Drawer
Open the door and remove and empty the grounds draw. Replace the grounds draw, then press
the top red button inside the door labled cleaning, this will reset the grounds counter and clear the
caution.
Caution - Water Empty
The water tank is empty. Refill the tank and replace it. The machine will now say "Select a Drink"
Caution - Fill Water Tank
The water tank is empty. Refill the tank, open door and press red cleaning button to reset the
machine. When the machine has been reset it will then it will ask "HOLD RED BUTTON" Open the
front door and press the red cleaning button for a 5 seconds. The machine will then say "POWDERS
CLEANING" then "Put empty jug under drink nozz" then PRESS RED BUTTON. Place a container
under the drink outlet and then press the red cleaning button. The machine will dispense a small
amount of water and then the machine will be ready to use.
Caution – Out of Coffee
The machine is out of coffee beans, refill the coffee bean hopper, open the front door and press the
red cleaning button briefly. The machine will reset and then will show "Select a Drink"
3600 Cleaning Guide v27
Page
1

Advertisement

loading
Need help?

Need help?

Do you have a question about the 3600 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HLF Italian Design 3600

Summary of Contents for HLF Italian Design 3600

  • Page 1 Bean to Cup Coffee Machine Welcome Thank you for your purchase of the 3600, please follow this guide to ensure that you get the maximum usage and efficiency from your machine for many years to come. In addition to the training you received upon installation, please also read the guidelines given in this document with regard to the cleaning procedures for your machine.

  • Page 2: Daily Cleaning

    Once finshed the machine will display cleaning cycle, refill the jug with fresh cold water only and repeat steps 1-3 with out adding the cappuccino cleaner. Finally remove the door pin and close the front door. Cleaning Button 3600 Cleaning Guide v27 Page 2...
  • Page 3 Machine clean Turn OFF the 3600 coffee machine. Open the front door. Shut off and remove the bean hopper. (If fitted) Open the machine lid. Remove the water tank by lifting straight up. Clean the water tank inside and out.
  • Page 4 Remove and clean the milk frother Turn OFF the 3600 coffee machine Shut off and remove the bean hopper (If fitted) Open the front door and then the lid. Remove the milk frother and it’s connected tubes from the machine (Shown below and highlighted in red on the right ) Open the milk frother as shown below.
  • Page 5 Wash the mixing bowl in hot soapy water. Dry thoroughly before replacing to ensure any instant drink powder doesn’t stick to it. Replace the mixing bowl and lock in place by pushing the locking lever back the left. 3600 Cleaning Guide v27 Page 5...
  • Page 6 Remove and clean the coffee group The coffee group is located internally on the right side of the 3600 coffee machine. This process needs to be carried out at the end of the day as it should be left over night.
  • Page 7 The group needs to be submerged in hot water for 20 minutes, then thoroughly rinsed to remove any coffee grounds. The group then needs to be dried thoroughly before replacing, preferably left to dry over night. Once dry, work backwards through the steps to reassemble the machine. 3600 Cleaning Guide v27 Page 7...

  • Page 8: Descaling Process

    11 – Press the red cleaning button to start the rinse process. 12 – Once complete; empty the drip and grounds trays; rinse; dry and replace them. 13 – Remove the door pin, close the lid and front door, then replace and open the bean 3600 Cleaning Guide v27 Page 8...

  • Page 9: Moving The Machine

    Once fully drained replace the plug and clip the tube back in to its original position. Do NOT turn the water and electricity back on until the machine has been moved to it’s final position. Black Grey plug exhaust pipe 3600 Cleaning Guide v27 Page 9...
