operating manual
fireplace
DEFRO HOME INTRA SLIM series
model
SM
ME
version
G
BL
BP
translation of original operating manual
edition 9
February 2022

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the INTRA SLIM Series and is the answer not in the manual?

Questions and answers

Related Manuals for Defro Home INTRA SLIM Series

Summary of Contents for Defro Home INTRA SLIM Series

  • Page 1 DEFRO HOME INTRA SLIM series model version translation of original operating manual edition 9 February 2022...
  • Page 2 This Declaration of Conformity becomes invalid if any changes have been made to the DEFRO HOME INTRA SLIM Fireplace, if its construc- tion has been changed without our permission or if the fireplace is used not in accordance with the operating manual. This Declaration shall be handed over to a new owner along with the title of ownership of the fireplace.
  • Page 3 Dear Customer, Dear Customer, We would like to thank you for choosing the high-quality DEFRO prod- We would like to inform you that we make every effort to offer the uct which will ensure your safety and operational reliability. products of quality fulfilling the most restrictive standards and warrant- As our customers, you can always count on the help of the DEFRO ing operational safety.

  • Page 4: Table Of Contents

    Table of contents INFORMATION ........................................5 BASIC SAFETY RULES ....................................... 5 2.1. Safety warnings ......................................5 2.2. Warnings related to operation ..................................6 2.3. Additional information....................................6 INTENDED USE ........................................6 TECHNICAL SPECIFICATION ..................................... 6 4.1. Design ........................................6 4.2. TECHNICAL DATA ....................................

  • Page 5: Information

    1. INFORMATION 2. BASIC SAFETY RULES The operating manual is an integral and essential part of the prod- 2.1. SAFETY WARNINGS uct and must be forwarded to the user also in the case when the prop- • The national and local provisions should be met. erty is transmitted.

  • Page 6: Warnings Related To Operation

    • Avoid contact with water; above all do not wash any Body (1, pictures 1, 2) of the DEFRO HOME INTRA SLIM fireplace insert is a steel jacket, with a combustion chamber located inside (2). painted surfaces until they are fully cured. The coating Floor creating chamber for air intake is a basis for the insert.

  • Page 7: Technical Data

    Picture 2. Design of the DEFRO HOME INTRA SLIM fireplace insert with swing doors. Markings on pictures 1 and 2. 1 – body, 2 – combustion chamber, 3 – doors, 4 – heat-resistant glass pane, 5 – handle with a lock, 6 – frame, 7 - floor, 8 - grate, 9 - ash-pan container, 10 - air intake socket, 11 - adjustment of air inflow, 12 - air inflow adjustment slider, 13 - claddings made of fire-proof concrete, 14 - open- ings from flue gas afterburning system, 15 - deflector, 16 - flue.
  • Page 8 Picture 4.4 Dimensions of the DEFRO HOME INTRA ME SLIM fireplace insert. insert. Picture 5 Dimensions of the DEFRO HOME INTRA SM BP SLIM fire- Picture 6 Dimensions of the DEFRO HOME INTRA ME BP SLIM fire- place insert. place insert.
  • Page 9 Picture 8. Dimensions of the DEFRO HOME INTRA ME SLIM G fireplace place insert. insert. Picture 9 Dimensions of the DEFRO HOME INTRA SM BP SLIM G Picture 10 Dimensions of the DEFRO HOME INTRA ME BP SLIM G fire- fireplace insert. place insert. Page...

  • Page 10: Equipment

    5.2. WORKING ENVIRONMENT busted in it. DEFRO HOME INTRA SLIM fireplace insert should be in- Wood should be seasoned minimum two (2) years. Fir- stalled in compliance with the requirements of the cur-...

  • Page 11: Hot Air Distribution System

    Fireplaces in the G version are not intended for a so-called “hot” installation due to the required cooling of the doors mechanism. Instal- lation of the DEFRO HOME INTRA SLIM G fireplace insert in such a system will void the warranty. It is indicated to use a bigger expansion...

  • Page 12: Forced System For Hot Air Distribution

    Using the gravity system you should use properly insulated and short (not exceeding 3 m) distributing ducts. For this system, it is not recommended to distribute hot air to too many rooms. Also use of too long pipes (over 3 m from the flue) increases resistance and decreases air flow velocity which causes that gravity flow is not effective.

  • Page 13: Usage And Operation

    • It is forbidden to use other materials than described be made of materials resistant to normal mechanical in this manual for firing up, in particular flammable stresses, heat, the action of combustion products and possi- chemicals such as: oil, petrol, solvents and others. ble condensate, •...

  • Page 14: Damping

    Hinged doors should not be opened during combus- tion in the case of the G version of the DEFRO HOME INTRA SLIM fireplace insert. Lifting upwards is a nor- mal method for the opening of guillotine doors.

  • Page 15: Doors/Gaskets

    Opening of guillotine doors in hinged position should be used rarely, only when it its necessary during occa- Picture 19. View of fireplace insert DEFRO HOME INTRA SLIM G with sional cleaning of window panel or other service works. doors in lifted position.

  • Page 16: Flue

    7.3. DOORS DISASSEMBLY In the G version of the DEFRO HOME INTRA SLIM fireplace in- sert all works related to the doors or their mechanism should be en- trusted to the qualified service of the manufacturer.

  • Page 17: Disassembly Of Deflector

    Slid off deflector made of vermiculite from the supporting beam. Picture 22. Window panel dismantling from doors. 7.5. DISASSEMBLY OF DEFLECTOR Lift deflector made of vermiculite (1) with a supporting beam Remove deflector from fireplace’s interior. 7.6. DISASSEMBLY OF CLADDINGS MADE OF FIRE-PROOF CONCRETE Remove deflector made of vermiculite prior to disassembly of the ce- ramic claddings from the combustion chamber.

  • Page 18: Shutting The Stove Down

    7.7. SHUTTING THE STOVE DOWN It is recommended completely shutdown the fireplace and clean the equipment when each heating season is finished. 8. TROUBLESHOOTING Some anomalies indicating irregularities in operation can occur during the operation of the equipment. It can be caused by incorrect installation of the equipment without observation of the applicable build- ing regulations or provisions of this manual or by external causes e.g.

  • Page 19: Removal Due To Wear-Out

    5 years for the correct operation of the equipment, place insert without adults. 2 years for doors lifting system for DEFRO HOME INTRA Flammable liquids must not be used for torching the fuel; only SLIM fireplace inserts in G version (guillotine).

  • Page 20: Warranty Conditions "48H Service

    immediately after a fault has been found and no later than after damages resulting from overheating of the equipment that 14 days. is: discoloration of glass pane, “milky discolorations”, discol- 12) Any fault is to be registered with the Guarantor (Ruda Straw- oration of metal components, “rainbow steel”, blue discolor- czyńska 103a, 26-067 Strawczyn) by sending a complaint sheet ations, chipping of paint, gasket discolorations, deformation...
  • Page 21 Fault removal time may be prolonged for reasons not dependent on DEFRO R. Dziubeła sp. k., such as the necessity of replace- ment of construction elements, lack of spare parts at the supplier, adverse weather conditions /force majeure/. Failure to carry out repairs within this period cannot constitute a ground for any claims against DEFRO R.
  • Page 22 22 | Page...

  • Page 23: Warranty Card

    WARRANTY CARD Confirmation of equipment's quality and completeness In accordance with the conditions stated herein, warranty for a fireplace insert of series has been issued DEFRO HOME INTRA SLIM ..........operated in accordance with the operating manual. Equipment manufacturing number* ......................

  • Page 24: Carried Out Warranty Repairs And Maintenance

    14. CARRIED OUT WARRANTY REPAIRS AND MAINTENANCE. fault description, repaired element, Stamp and signature date comments description of repairs of Service 24 | Page...

  • Page 25: Warranty Card (Copy To Send Back)

    WARRANTY CARD Confirmation of equipment's quality and completeness In accordance with the conditions stated herein, a warranty for a fireplace insert of series has been issued DEFRO HOME INTRA SLIM ..........operated in accordance with the operating man- ual. Equipment manufacturing number* ......................
  • Page 26 26 | Page...

  • Page 27: Complaint Form

    COMPLAINT FORM COMPLAINT FORM made on ........... in connection with complaint no......SUBJECT OF COMPLAINT EQUIPMENT TYPE: ..........Equipment manufacturing date: ..........Equipment serial no.: ..........Equipment purchase date: ..........CLAIMANT Name and surname: ................................... Detailed address: ..................................................................Phone number ...................................
  • Page 28 28 | Page...

  • Page 29: Complaint Form

    COMPLAINT FORM COMPLAINT FORM made on ........... in connection with complaint no......SUBJECT OF COMPLAINT EQUIPMENT TYPE: ..........Equipment manufacturing date: ..........Equipment serial no.: ..........Equipment purchase date: ..........CLAIMANT Name and surname: ................................... Detailed address: ..................................................................Phone number ...................................
  • Page 30 30 | Page...

  • Page 31: Complaint Form

    COMPLAINT FORM COMPLAINT FORM made on ........... in connection with complaint no......SUBJECT OF COMPLAINT EQUIPMENT TYPE: ..........Equipment manufacturing date: ..........Equipment serial no.: ..........Equipment purchase date: ..........CLAIMANT Name and surname: ................................... Detailed address: ..................................................................Phone number ...................................

  • Page 32: Register Of Inspections Of Smoke Duct

    REGISTER OF INSPECTIONS OF SMOKE DUCT date stamp and signature of chimneysweep date stamp and signature of chimneysweep 32 | Page...
  • Page 33 33 | Page...
  • Page 34 34 | Page...
  • Page 35 Model identifier(s): DEFRO HOME INTRA SLIM SM, DEFRO HOME INTRA SLIM SM BP, DEFRO HOME INTRA SLIM SM BL, DEFRO HOME INTRA SLIM SM G, DEFRO HOME INTRA SLIM SM BP G, DEFRO HOME INTRA SLIM SM BL G Indirect heating function: [yes/no] Direct thermal output: 6.7 (kW)
  • Page 36 Properties in the case of operation only with recommended fuel Parameter Designa- Value Unit Parameter Designa- Value Unit tion tion Thermal output Performance (calorific value in operating condition) Rated heat out- Performance at η 82.7 th,nom rated thermal power Minimum heat Performance at η...
  • Page 37 Model identifier(s): DEFRO HOME INTRA SLIM ME, DEFRO HOME INTRA SLIM ME BP, DEFRO HOME INTRA SLIM ME BL, DEFRO HOME INTRA SLIM ME G, DEFRO HOME INTRA SLIM ME BP G, DEFRO HOME INTRA SLIM ME BL G Indirect heating function: [yes/no] Direct thermal output: 8.1 (kW)
  • Page 38 Properties in the case of operation only with recommended fuel Parameter Designa- Value Unit Parameter Designa- Value Unit tion tion Thermal output Performance (calorific value in operating condition) Rated heat out- Performance at η 80.1 th,nom rated thermal power Minimum heat Performance at η...
  • Page 39 39 | Page...
  • Page 40 40 | Page...
