- Page 1 operating manual fireplace DEFRO HOME IMPULS series model SM ME version BL BP original operating manual edition 3 June 2020...
- Page 2 DEKLARACJA ZGODNOŚCI WE DECLARATION OF CONFORMITY EC nr 83/R‐2/01/2017 DEFRO Spółka z ograniczoną odpowiedzialnością Spółka komandytowa 00‐403 Warszawa, ul. Solec 24/253 Zakład produkcyjny: 26‐067 Strawczyn, Ruda Strawczyńska 103A DEKLARUJE / DECLEARS z pełną odpowiedzialnością, że produkt / with all responsibility, that the product Wkład kominkowy powietrzny / Fireplace DEFRO HOME IMPULS (typ/type DEFRO HOME IMPULS) został zaprojektowany, wyprodukowany i wprowadzony na rynek zgodnie z następującymi dyrekty‐ wami: has been designed, manufactured and placed on the market in conformity with directives: Rozporządzenie Parlamentu Europejskiego / Regulation of the European Parliament 305/2011 i niżej wymienionymi normami zharmonizowanymi: and that the following relevant Standards: PN‐EN 13229:2002 dokumentacja techniczna / technical documentation Wyrób oznaczono znakiem: Product has been marked: Ta deklaracja zgodności traci swą ważność, jeżeli we wkładzie kominkowym DEFRO HOME IMPULS wprowadzono zmiany, została prze‐ budowana bez naszej zgody lub jest użytkowana niezgodnie z instrukcją obsługi. Niniejsza deklaracja musi być przekazana wraz z wkła‐ dem kominkowym w przypadku odstąpienia własności innej osobie. This Declaration of Conformity becomes invalid if any changes have been made to the DEFRO HOME IMPULS Fireplace, if its construction has been changed without our permission or if the fireplace is used not in accordance with the operating manual. This Declaration shall be handed over to a new owner along with the title of ownership of the fireplace. Wkład kominkowy DEFRO HOME IMPULS jest wykonywany zgodnie z dokumentacją techniczną przechowywaną przez: DEFRO HOME IMPULS Fireplace has been manufactured according to technical documentation kept by: ...
- Page 3 Dear Customer, Dear Customer, We would like to thank you for choosing the high-quality DEFRO prod- We would like to inform you that we make every efforts to offer uct which will ensure your safety and operational reliability. products of quality fulfilling the most restrictive standards and warrant- As our customers, you can always count on the help of the DEFRO ing operational safety.
-
Page 4: Table Of Contents
Table of Contents INFORMATION ......................................5 BASIC SAFETY RULES ..................................... 5 2.1. SAFETY WARNINGS ..................................5 2.2. WARNINGS RELATED TO OPERATION ............................6 INTENDED USE ......................................6 TECHNICAL SPECIFICATION ..................................6 ... -
Page 5: Information
2. BASIC SAFETY RULES 1. INFORMATION 2.1. SAFETY WARNINGS Operating manual is an integral and essential part of the product The national and local provisions should be met. and must be forwarded to the user also in the case when the property ... -
Page 6: Warnings Related To Operation
4.1. DESIGN washed with water. Body (1, picture 1) of the DEFRO HOME IMPULS fireplace insert Do not allow contact with water and, above all, do not is a steel jacket, with a combustion chamber located inside (2). Floor wash any varnished coatings before curing. -
Page 7: Equipment
Device weight depends on the selected design version and its equipment Picture 4. Dimensions fireplace insert DEFRO HOME IMPULS SM for versions BP and BL (mirror reflection of BP version). Picture 2. Dimensions fireplace insert DEFRO HOME IMPULS SM. -
Page 8: Fuel Parameters
20% (wood seasoned in proper conditions for at least 2 years). The maximum length of chunks is given in table 1. It is allowed to use wood Fireplace insert DEFRO HOME IMPULS should be in- briquet. stalled in compliance with the requirements of the cur-... -
Page 9: Hot Air Distribution System
Flooring in the room, where the fireplace is to be in- The active area of the grille should be selected correspondingly to stalled, should be properly dimensioned, to maintain the power of the insert. It is assumed that is should equal to 40 - 60 the load. -
Page 10: Connection To External Air Intake
5.4. CONNECTION TO EXTERNAL AIR INTAKE As an alternative is it is recommended to use insulated industrial pipe, which can be also used outdoors, to avoid the occurrence of con- Room, where the fireplace insert is installed, should be equipped densate. -
Page 11: First Start-Up And Operation
6.2. FIRST START-UP AND OPERATION use only hardwood (recommended beech, oak, hornbeam) of low mois- ture content (below 20%). Prior to firing up you should set a slider of air inflow adjustment to During combustion, the doors should be opened only when the fuel maximum opening (marking on the handle, presented on picture 10). -
Page 12: Window Panel Cleaning
7.3. DOORS DISASSEMBLY Picture 12. Removal of grate and ash-pan. Slide protecting ring downwards maximally. Re-install the ash container below the grate after the cleaning, making sure that its position is correct. 7.1.2. WINDOW PANEL CLEANING It is recommended using a dry brush to clean the ceramic glass. If the contamination is significant to use suitable cleaning agent spray and spray little amount and then clean the window panel with a cloth. -
Page 13: Window Panel Dismantling
Rotate deflector set by approx. 60º to a vertical position. Lower the doors to ensure that the upper pin of the hinge leaves the upper opening of the frame and remove the doors. 7.4. WINDOW PANEL DISMANTLING It is possible to disassemble the window panel after the doors have been disassembled. -
Page 14: Shutting Down
insufficient chimney draught (carry out chimneysweep in- spection of the flue). Insufficient heating or damping: too low amount of fuel in a furnace (charge furnace in com- pliance with the manual); the too high moisture content of wood used for combustion (use wood with moisture content <20%) a large part of ob- tained energy lost in water evaporation process: ... -
Page 15: Removal Due To Wear-Out
10. REMOVAL DUE TO WEAR-OUT The Purchaser receives Warranty Terms and Conditions, War- ranty Card as well as Operating Manual containing conditions for boiler's usage, installation guide and parameters regarding the A fireplace insert is made of materials neutral for the environment. chimney, fuel and boiler water. -
Page 16: Warranty Conditions "48H Service
claim. Notification about the same defect in this mode is not pos- equipment for free. Not returning the above-mentioned part within sible. 7 working days will be a subject to not accept the claim and to 15) If the fault complained about cannot be removed and after three charge its costs to the buyer. -
Page 17: Warranty Card
13. WARRANTY CARD WARRANTY CARD Confirmation of equipment's quality and completeness In accordance with the conditions stated herein, warranty for a fireplace insert type DEFRO HOME IMPULS ............operated in accordance with the operating. Equipment manufacturing number ......................Equipment power* ..................... -
Page 18: Carried Out Warranty Repairs And Maintenance
14. CARRIED OUT WARRANTY REPAIRS AND MAINTENANCE Stamp and signature date fault description, repaired elements, description of repairs comments of Service... -
Page 19: Warranty Card
15. WARRANTY CARD WARRANTY CARD Confirmation of equipment's quality and completeness In accordance with the conditions stated herein, warranty for a fireplace insert type DEFRO HOME IMPULS ............operated in accordance with the operating. Equipment manufacturing number ......................Equipment power* ..................... -
Page 21: Complaint Form
16. COMPLAINT FORM COMPLAINT FORM made on ............in connection with a complaint no......SUBJECT OF COMPLAINT EQUIPMENT TYPE: ........... Equipment manufacturing date: ..........Equipment serial no.: ........... Equipment purchase date: ..........CLAIMANT Name and surname: ................................Detailed address: ................................ -
Page 23: Complaint Form
17. COMPLAINT FORM COMPLAINT FORM made on ............in connection with a complaint no......SUBJECT OF COMPLAINT EQUIPMENT TYPE: ........... Equipment manufacturing date: ..........Equipment serial no.: ........... Equipment purchase date: ..........CLAIMANT Name and surname: ................................Detailed address: ................................ -
Page 25: Complaint Form
18. COMPLAINT FORM COMPLAINT FORM made on ............in connection with a complaint no......SUBJECT OF COMPLAINT EQUIPMENT TYPE: ........... Equipment manufacturing date: ..........Equipment serial no.: ........... Equipment purchase date: ..........CLAIMANT Name and surname: ................................Detailed address: ................................ -
Page 27: Register Of Inspections Of Smoke Ducts
19. REGISTER OF INSPECTIONS OF SMOKE DUCTS date stamp and signature of chimneysweep date stamp and signature of chimneysweep... - Page 28 1. Identification code of product-type KOM-DHIMPULS-SM, KOM-DHIMPULS-SM-BL, KOM-DHIMPULS-SM-BP 2. Building product (name, type, series) Product name: Fireplace DEFRO HOME IMPULS SM Serial number: See rating plate 3. Application of building product Room heater fired with solid fuel in the buildings 4.
- Page 29 1. Identification code of product-type KOM-DHIMPULS-ME, KOM-DHIMPULS-ME BL, KOM-DHIMPULS-ME-BP 2. Building product (name, type, series) Product name: Fireplace DEFRO HOME IMPULS SM Serial number: See rating plate 3. Application of building product Room heater fired with solid fuel in the buildings 4.
- Page 30 Production plant 26-067 Strawczyn Ruda Strawczyńska 103A MODEL IDENTIFICATION UNIT EQUIPMENT PARAMETERS DEFRO HOME IMPULS SM DEFRO HOME IMPULS SM BL DEFRO HOME IMPULS SM BP Energy efficiency class Direct thermal power Indirect thermal power Energy efficiency Index EEI Efficiency at nominal thermal...
- Page 31 Ul. Solec 24/253 Production plant 26-067 Strawczyn Ruda Strawczyńska 103A MODEL IDENTIFICATION UNIT EQUIPMENT PARAMETERS DEFRO HOME IMPULS ME DEFRO HOME IMPULS ME BL DEFRO HOME IMPULS ME BP A⁺ A⁺ Energy efficiency class Direct thermal power Indirect thermal power...
- Page 32 DEFRO Spółka z ograniczoną odpowiedzialnością Spółka komandytowa 00-403 Warszawa, ul. Solec 24/253 Production plant: Ruda Strawczyńska 103 A 26-067 Strawczyn tel.: 41 303 80 85, biuro@defro.pl NIP 9591968493...
