www.nacebrands.com
User Manual
Thank you for purchasing our product. If there are any
questions, or requests, please do not hesitate to
contact the dealer or technical support.
This manual applies to the Securitytronix HD-TVI Series
cameras.
This manual may contain several technical incorrect
places or printing errors, and the content is subject to
change without notice. The updates will be added to
the new version of this manual. We will readily
improve or update the products or procedures
described in the manual.
For additional information, or if you have any issues
with this product, please visit
Or contact technical support @ 347-817-4342
ST-HDC2FD
QUICK START GUIDE
www.securitytronix.com
www.securitytronix.com
010000120116
Advertisement
Table of Contents
Related Manuals for Security Tronix HD-COAXINATORTVI ST-HDC2FD
Summary of Contents for Security Tronix HD-COAXINATORTVI ST-HDC2FD
- Page 1 ST-HDC2FD QUICK START GUIDE www.nacebrands.com www.securitytronix.com User Manual Thank you for purchasing our product. If there are any questions, or requests, please do not hesitate to contact the dealer or technical support. This manual applies to the Securitytronix HD-TVI Series cameras.
-
Page 2: Regulatory Information
Privacy Notice Surveillance laws vary by jurisdiction. Check all relevant laws in your jurisdiction before using all this product for surveillance purpose to ensure that your use of this product conforms. Regulatory Information FCC Information FCC compliance: This equipment has been tested and found to comply with the limits for a digital device, pursuant to part 15 of the FCC Rules. -
Page 3: Product Features
1 Introduction 1.1 Product Features This series of HD-TVI camera adopts high performance sensors and advanced circuit board design technology. It features high resolution, low distortion, and low noise, etc. Designed for use in surveillance systems.. The main features are as follows: ... -
Page 4: Installation
2 Installation Before you start: Please make sure that the device in the package is in good condition and all the assembly parts are included. Make sure that all the related equipment is powered-off during installation. Check the product specifications for the installation environment requirements. -
Page 5: In-Ceiling Mounting
T y p e I I C a m e r a Type I Camera： ： Figure 2-3 Fix the Camera to the Ceiling 6. Connect the video cable to the monitor and connect the power cable to the power supply. 7. - Page 6 Figure 2-5 Install the Mount 3. Route the cables through the hole of in-ceiling mount and connect the corresponding cables. 4. Fix the camera to the in-ceiling mount with the supplied screws. Type II Camera： Type I Camera： Figure 2-6 Fix the Camera to the Mount 5.
-
Page 7: Menu Description
Mounting with Inclined Base of Type I Camera Steps: 1. Install the inclined base to the ceiling with supplied screws, as shown in Figure 2-9. Figure 2-9 Fix the Inclined Base 2. Route cables through the hole of the in-ceiling mount and connect the corresponding cables. -
Page 8: Exposure Mode
3.1 Format Move the cursor to FORMAT, and press the menu button to enter the FORMAT sub menu. You can set the format of camera and confirm. 3.2 Focus Move the cursor to FOCUS, and press the menu button to enter the FOCUS sub menu. Move the cursor to adjust the camera lens by the FOCUS+, FOCUS-, ZOOM + and ZOOM-. -
Page 9: Video Setting
3.3.3 WB (White Balance) White balance is the white rendition function of the camera to adjust the color temperature according to the environment. It can remove unrealistic color casts in the image. You can set WB mode as ATW, and MWB. In ATW mode, white balance is being adjusted automatically according to the color temperature of the scene illumination. -
Page 10: Ir Reflection Prevention
VIDEO SET TING CONTRAST SHARPNESS COLOR GAIN DEFAULT MIRROR RETURN Figure 3-5 Video Setting CONTRAST This feature enhances the difference in color and light between parts of an image. You can set the CONTRAST value from 1 to 10. SHARPNESS Sharpness determines the amount of detail an imaging system can reproduce.
