Product Specifications
Solar Cells
Solar Cell Material
Solar Cell Efficiency
Solar Cell Surface Coating
Output Power
Max Power Output - Wa‫מּ‬age (W)
Max Power Output - Voltage(Vmp)
Max Power Output - Current (Imp)
Power Tolerance
Open Circuit Voltage (Voc)
Short Circuit Current (Isc)
Operating Temperatures
Operating Temp (°C)
Nominal Operating Cell Temp (NOCT)
Current Temp Coefficient

Safety Information

This section contains important safety information. Before using the product, READ ALL instructions and cautionary markings on or provided with the product, and all appropriate sections of this guide. The product contains no
user-serviceable parts. SAVE THESE INSTRUCTIONS.
WARNING: NO USER SERVICEABLE PARTS
There are no user-serviceable parts within the module. Do not a‫מּ‬empt to repair any part of the module.
WARNING: RISK OF INJURY
Permanent installation should be performed only by qualified personnel.
There is a risk of electric shock if the front surface is broken, the backing is torn, junction box is broken
or wires are frayed.
Do not deploy or handle the panels when they are wet or during periods of high winds.
Do not allow water to pool in or near panel frames.

Maintenance

In order to keep your Portable Solar Panel operating efficiently, periodically clean and maintain your panel using the simple steps below. Keeping the panels clean allows optimal sun exposure for
efficient charging of your PowerSource.
WARNING: DAMAGE TO SOLAR PANEL
Do not clean the panel when the surface is hot. Do not use a pressure washer to clean the panel. Failure to observe these warnings may result in damage to the panel and void your warranty.
Clean the surface of the solar panel when necessary. Always use a soﬞ sponge or cloth for cleaning.
A mild, non-abrasive cleaning detergent may be used to remove stubborn dirt.
Clean your solar panel more frequently during drier months, as it may become covered in dust
more quickly.
Monocrystalline PERC M6-166mm
22.8%
PET
200W
19.5V
10.25A
±3%
23.2V
11.38A
-20 to 50°C / -4 to 122°F
46°± 2° C
0.05% / °C
Voltage Temp Coefficient
Power Temp Coefficient
Max Series Fuse Rating
Cable
Anderson Cable Length
Cable Type
Output Connector
Dimensions and Weight
Product Dimensions - Folded
Product Dimensions - Open
Product Net Weight
WARNING: DAMAGE TO PRODUCT
Do not stand on, drop, scratch, or allow objects to fall on panels as doing so may damage the panels
and void the warranty.
Do not place anything on the modules, even for a moment, because resulting residue may damage
or stain the surface.
Unconnected connectors must always be protected from dust, humidity or foreign particles.
Regularly inspect and clean your panel more frequently if the panel is leﬞ outdoors in dusty, windy
or dirty conditions.
Periodically inspect additional components such as folding support legs, frames, cables, and closures for
dirt, grit, oil and other contaminants; clean as needed.
- 0.35% / °C
- 0.45% / °C
15A
5M / 16.5 ﬞ
14AWG dual conductor, shielded
Anderson Powerpole 15/45
545 x 525 x 60 mm/21.5" x 20.7" x 2.4"
2455 x 525 x 10 mm/96.7" x 20.7" x 0.4"
5.9 kgs/ 13.0 lbs
