Specifications

Air Velocity
m/s (meters per sec)
km/h (kilometers/hour)
ft/min (feet per minute)
mph (miles per hour)
knots (nautical MPH)
Air Flow
CMM (cubic meters/min)
CFM (cubic ft/min)
Air Temperature
Circuit
Display
Sampling rate
Sensors
Automatic Power off
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Operating Altitude
Battery
Battery life
Power Consumption
Weight
Dimensions
All rights reserved including the right of reproduction in whole or in part in any form
Range
0.40 - 30.00 m/s
1.4 - 108.0 km/h
80 – 5900 ft/min
0.9 – 67.0 mph
0.8 to 58.0 knots
Range
0-9999 m
0-9999 ft
Range
o
-10 - 60
Custom LSI microprocessor circuit
Dual function 13 mm (0.5") 4-digit LCD
1 reading per second approx.
Air velocity/flow sensor: Conventional angled vane arms with low-
friction ball bearing
Temperature sensor: NTC-type precision thermistor
Auto shut off after 20 minutes to preserve battery life
0°C to 50°C (32°F to 122°F)
o
-10 to 60 C (14 to 140
<80% RH
<80% RH
2000 meters (7000ft) maximum
One 9 volt (NEDA 1604) battery
80 hours approx. (if the Backlight is used continuously, battery life
will be reduced significantly)
8.3 mA DC approx.
725g (1.6 lbs) including battery & probe
Main instrument: 178 x 74 x 33mm (7.0 x 2.9 x1.2")
Sensor Head: 70mm (2.75") Inside Diameter
Sensor Head: 76.2mm (3.0") Outside Diameter
Copyright © 2013-2018 FLIR Systems, Inc.
ISO-9001 Certified
www.extech.com
Resolution
0.01 m/s
0.1 km/h
0.1 knots
Resolution
3
/min
3
/min
Resolution
o
C (14 - 140 F)
o
F)
9
Accuracy (% of reading)
± (3%rdg + 0.20 m/s)
± (3%rdg + 0.8 km/hr)
1 ft/min ± (3%rdg + 40 ft/m)
0.1 mph ± (3%rdg + 0.4 MPH)
± (3%rdg + 0.4 knots)
1 0 to 9.999m
1 0 to 9.999ft
o
0.1 C/F ±2.0
AN100-en-GB_V3.6 6/18
Area
2
2
Accuracy
o o
C (4.0 F)
