- Page 1 USER INSTRUCTION MANUAL Handy Line Temporary Horizontal Lifeline THESE INSTRUCTIONS APPLY TO THE FOLLOWING MODEL: UFA40110...
-
Page 2: Technical Specification
TENSIONER CONNECTOR INDICATOR APPLICATIONS: The KStrong Horizontal Lifeline System is designed for use as an anchoring means for one or two personal fall arrest systems. Use the Horizontal Lifeline (HLL) where horizontal mobility and fall protection are required. • Limitations: Consider the following application limitations before using this equipment: •... -
Page 3: Installations
Hazards may include, but are not limited to; high heat, caustic chemicals, corrosive environments, high voltage power lines, explosive or toxic gases, moving machinery, or sharp edges. Contact KStrong if you have questions about using this equipment where physical or environmental hazards exist. -
Page 4: Pre-Use Check
KStrong connectors (Snap Hooks and Karabiners) are designed to be used only as specified in each product’s user instructions. NOTE: Large throat-opening snap hooks should not be connected to standard size D-rings or similar objects which will result in a load on the gate if the hook or D-ring twists or rotates. -
Page 5: Operation
CONNECTING SUBSYSTEM: The connecting subsystem is the portion of the personal fall arrest system that is used to connect between the horizontal lifeline subsystem and harness fall arrest attachment element. The connecting subsystem must limit forces applied to the horizontal lifeline to 900lbs. - Page 6 Fall Clearance & Deflection Chart UFA40110 • Single User Pay Out Length (Ft/M) Deflection Fall Clearance (Ft/M)- Fall Clearance (Ft/M)-When used with When used with Micron 6.56ft / 2M Shock Absorbing Lanyard 16.40ft (5m) 4.04ft (1.23m) 17.16ft (5.23m) 23.72ft (7.23m) 19.69ft (6m)
-
Page 7: Operation And Use
TENSIONER user. The SRL, when fully retracted, must INDICATOR UFA40110 be above the harness attachment level. The Fig. A horizontal lifeline system should be positioned at a level that will minimize free fall while allowing ease of use. - Page 8 The maximum angle is 15˚ at which the anchor line should enter or exit intermediate supports, e.g. intermediate anchors or corner anchors. • Anchor device may be used in conjunction with Kstrong retractable type fall arresters. • The potential dangers that arise can include serious injury or death when type C anchor devices are combined with retractable type fall arresters (EN 360) or guided type fall arresters including a flexible anchor line (EN 353-2) which have not been tested together.
-
Page 9: Cleaning And Maintenance
CLEANING AND MAINTENANCE: • Cleaning of soil & dirt with cloth Must be done at a safe area to aroid accumulation of static charge. • In case of any doubt arising about the safe condition of the product such as crack in the housing or any other metal part, hindered retractions, delayed / early locking fall indicator showing red mark, in such cases immediately remove from service &... - Page 10 Always ensure that the lifeline is properly tensioned for arrest a fall, remove from service immediately. Do not use if inspection reveals an optimal performance (refer to user manual for more details). unsafe condition. Contact KStrong should unit need repair. Specifications: 20___ 20___ Minimum Breaking Strength: 5000 lbs.
- Page 11 DISCLAIMER: This information on the product is based upon technical data that KStrong obtained under laboratory conditions and believes to be reliable. KStrong does not guarantee results and takes no liability or obligation in connection with this information. As conditions of end use are beyond our control it is the user’s responsibility to determine the hazard levels and the use of proper personal protective equipment.
- Page 12 KStrong Inc. 150 N. Radnor Chester Road Suite F200 Radnor, Pennsylvania 19087 United States Contact number : 1-833-KSTRONG www.kstrong.com South America Asia...
