Aluminum Beam Walker Super
Slider 12-30" / 5000 lbs.
Model # UFAB1230
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
Patent # US 8,312,966
V3.0-A
Advertisement
Table of Contents
Related Manuals for KStrong UFAB1230
Summary of Contents for KStrong UFAB1230
- Page 1 Aluminum Beam Walker Super Slider 12-30” / 5000 lbs. Model # UFAB1230 WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
- Page 2 PURPOSE The UFAB1230 is an anchorage connector designed to function as an interface between the anchorage and a fall protection, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector”...
- Page 3 PERFORMANCE: REGULATORY COMPLIANCE: Minimum Breaking Strength: 5000-lbf (22kN) ANSI Z359.18 Type A, ANSI Z359.7-2011, Maximum Capacity: One worker with max OSHA 1926.502, OSHA 1910.66, weight of 310-lbs when used as a single EN 795:2012 Class B (CE 2777) point anchorage connector for personal fall arrest or restraint system COMPONENT MATERIALS: DIMENSIONS:...
- Page 4 LOADING CONDITIONS DIAGRAM Placement at or below a user’s working height requires integration of a compatible ANSI Z359.1 shock-absorbing lanyard that does not allow the user to extend more than 6 feet (in any direction) from the anchorage connector before the shock absorber is activated. The beam anchor must be attached to the I-beam flange facing the user (top flange if above, bottom flange if below, etc.).
- Page 5 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). In the EU these forces must be limited to 6 kN (1350-lbf ). (ANCHOR POINT) WORK SURFACE Inspect retaining...
- Page 6 WARNING LABEL LOCATIONS USE ONLY ON STEEL FLANGES THAT CAN SUPPORT AT LEAST 5,000-LBF (22kN) MAX CAPACITY 310-LBS, MIN BREAKING STRENGTH 5,000-LBF (22kN) Super-Slider Model: UFAB1230 MATERIAL: ALUMINUM ALLOY STAINLESS & ZINC PLATED STEEL 1-833-KSTRONG (578-7664) MFD: MM/YYYY LOT: XXX DO NOT USE WITH INCOMPATIBLE CONNECTORS.
- Page 7 MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
- Page 8 Notified Body responsible for the EC type examination and ongoing conformity: SATRA Technology Europe Ltd. Bracetown Business Park Clonee Dublin D15 YN2P Ireland Tel: +353 (0)1 437 2484 150 N. Radnor Chester Road Suite F200 Radnor, PA 19087 1-833-KSTRONG (578-7664) /www.KStrong.com...
