KStrong UFASA058 Operation And Instruction Manual

Swivel anchor
Hide thumbs

Advertisement

Quick Links

Download this manual
OPERATION AND INSTRUCTION MANUAL
Swivel Anchor Model: UFASA058
Patent # US 8,424,638
WARNING:
ALL PERSONS USING THIS EQUIPMENT MUST
READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO
SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD
BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS
EQUIPMENT. ALL INDIVIDUALS WHO USE THIS PRODUCT MUST
BE PROPERLY INSTRUCTED ON HOW TO USE THE DEVICE. AVOID
CONTACT WITH PHYSICAL HAZARDS (THERMAL, CHEMICAL,
ELECTRICAL, ETC.). MAKE ONLY COMPATIBLE CONNECTIONS.
V4.9-A

Advertisement

loading
Need help?

Need help?

Do you have a question about the UFASA058 and is the answer not in the manual?

Questions and answers

Related Manuals for KStrong UFASA058

Summary of Contents for KStrong UFASA058

  • Page 1 OPERATION AND INSTRUCTION MANUAL Swivel Anchor Model: UFASA058 WARNING: ALL PERSONS USING THIS EQUIPMENT MUST READ AND UNDERSTAND ALL INSTRUCTIONS. FAILURE TO DO SO MAY RESULT IN SERIOUS INJURY OR DEATH. USERS SHOULD BE FAMILIAR WITH PERTINENT REGULATIONS GOVERNING THIS EQUIPMENT.
  • Page 2 PURPOSE The UFASA058 is an anchorage connector designed to function as an interface between the anchorage and a fall protection, work positioning, rope access, or rescue system for the purpose of coupling the system to the anchorage. Any references to “anchorage connector”...
  • Page 3 LABEL LOCATIONS 180° 2.25”ø 8”ø (57.15mm) (203.2mm) 5.5” (139.7mm) 360° 3” 1” (76.2mm) (25.4mm) Minimum Breaking Strength (MBS): 10,000-lbf (44kN) Working Load: 2,000-lbs (907kg) Weight: 1.2-lbs (544.3g) Materials: Zinc Plated Steel Regulatory Compliance: Meets or exceeds ANSI Z359.18 Type A, ANSI Z359.7-2011 OSHA 1926.502 LOADING CONDITIONS DIAGRAM LOAD...
  • Page 4 STEEL MOUNTING 1. Use a proper drill and bit for steel. 2. Drill a 5/8” (16mm) hole no less than .25” (6mm) deep 3” (76mm) away from any edge. 3. Hole must be straight and perpendicular to surface. 4. Hole must be free of debris. 5/8”-11 Lock Nut 5/8”...

  • Page 5: Concrete Mounting

    CONCRETE MOUNTING 1. Use a proper drill and bit for concrete (SDS drill bit). 2. Drill a .75” (19mm) hole no less than 5” (114mm) deep 9” (229mm) away from any edge. 3. Hole must be straight & perpendicular to surface. 4.
  • Page 6 WELD ON MOUNTING Grade - 5 or 8 bolt 5/8”-11 x 1-3/4” Internal Tooth Lock Washer Torque Range: 75 to 90 ft-lbs (100-120Nm) Weld Puck * Weld (AISI 1018) 3/8” min (9.5mm) * Welding procedure must be approved by an engineer or other qualified person to be compatible with any and all structural &...
  • Page 7 STRAIGHT LOOP INSERT See Straight Loop Insert Manual for anchorage casting instructions. 1. Strip decking to expose the Straight Loop Insert. 2. Ensure that anchorage was properly installed. Orange indicator should be flush with concrete surface, and at least 9” from any edge or corner. Concrete should be at least 6”...
  • Page 8 *The user shall be equipped with a means of limiting the maximum dynamic forces exerted on the user during the arrest of a fall to a maximum of 8 kN (1800-lbf ). In the EU these forces must be limited to 6 kN (1350-lbf.) (ANCHOR POINT) WORK SURFACE *The structure the...
  • Page 9 KIT CONTENTS PART NUMBER Call for more info. (Steel Mounting Hardware Kit) UFASWK58 (Swivel with Steel Mounting kit) Call for more info. (Straight Loop Insert Mounting Kit) Call for more info. (Swivel with Straight Loop Insert Mounting kit) Call for more info. (Concrete Hardware Kit) UFASWK34 (Swivel with Concrete Mounting Kit)

  • Page 10: Inspection And Maintenance Log

    MAINTENANCE, CLEANING AND STORAGE Cleaning periodically will prolong the life and proper functioning of the product. The frequency of cleaning should be determined by inspection and by severity of the environment. Clean with compressed air and/or a stiff brush using plain water or a mild soap and water solution. Do not use any corrosive chemicals that could damage the product.
  • Page 11 NOTES...
  • Page 12 LIMITATION OF LIABILITY: IN NO EVENT WILL K STRONG BE LIABLE FOR ANY INDIRECT, INCIDENTAL, SPECIAL OR CONSEQUENTIAL DAMAGES INCLUDING, BUT NOT LIMITED TO LOSS OF PROFITS, IN ANY WAY RELATED TO THE PRODUCTS REGARDLESS OF THE LEGAL THEORY ASSERTED. 150 N. Radnor Chester Road Suite F200 Radnor, PA 19087 1-833-KSTRONG (578-7664) /www.KStrong.com...
