PADDED BACK
1. To install the half round padded back first line up the ends of the tubular back with
the locating points. (See Fig. 13).
2. Attach the padded back frame to the main body of the rollator ensuring the locator
pins lock into place (you will hear a click).
WIRE BASKET OR BAG
1. Your rollator is supplied with a bag; raise the padded seat, align the bag with the
frame and close each of the fabric popper ties around the frame to hold the bag in
place and then lower the seat.
STORAGE
Grip the side bar and lift (Fig. 14).
1.
2. Continue lifting until the Rollator fully
closes.
3. You may also wish to remove the half-
round back for storage; to do so pull
the silver coloured locking buttons
located on either side of the tube lock
outwards then lift up the back to
detach.
MAKE SURE ALL WHEELS ARE SECURELY FITTED TO THE FRAME AND WORK PROPERLY
Usage and Maintenance Instructions
Fig. 13
9
Fig. 14
