aidapt VP178X Usage And Maintenance Instructions page 5

ATTACHING THE BACK LEGS AND BRAKE ASSEMBLY
1. Attach the back legs (the back legs are straight) to the back of rollator frame.
2. When attaching the back legs, ensure that the wheels are on the outside of the
frame.
3. Once the legs are at the desired height, make sure the locator pins lock into place
(you will hear a click).
4. Ensure that both legs are set to the same height.
• Attach the brake assemblies to the top of the rollator frame by
Attach the brake assemblies to the top of the rollator frame by c carefully insert the
brake assembly with pre-punched extension tube within the frame. (Fig. 6) brake assembly with pre-punched extension tube within the frame.
• At the required height (there are several holes), secure the brake assemblies
using a thumbwheel on either side. (Fig. 7)
Usage and Maintenance Instructions
5
Fig. 5
arefully insert the
Fig. 6
