CENTRAL LOCKING MECHANISM AND USE
1. Open out and fully extend the Main Rollator Body by pulling the cross bars outwards
in opposite directions forming an inverted 'V' with the main frame.
2. Ensure that your Rollator is fully extended, and check that the side bars are straight
and level (Fig. 3).
ATTACHING THE FRONT LEGS
1. Attach the front legs to the front of the rollator (the front legs are cranked).
2. On the wheel of the front leg you will see a large nut. Ensure that the large nuts on
the front leg wheels are facing inwards.
3. Once the leg is at the desired height make sure the locator pins lock into place
(you will hear a click).
4. Ensure that both front legs are to the same height.
Usage and Maintenance Instructions
4
Fig. 3
Fig. 4
