FREESTANDING FRENCH DOOR GAS RANGE Conforms to CSA / ANSI STD Z21.1 Certified to CSA STD 1.1 INSTALLATION GUIDE SPECIFICATIONS, INSTALLATION, AND MORE MODEL NUMBERS: FFSGS6460-30 FFSGS6460-36 FFSGS6460-48...
Warranty Important Safety Information Door Handle Installation Cooktop Burner Grates Installation Oven Racks Installation Electrical Gas Supply Pressure Regulator Gas Shut-off Valve Product Dimensions and Cabinets Exhaust Hood Installation Gas Conversion Operation Gas Supply Connection Ignition Simmer and Boil Burner Grates Griddle Operation Cooktop Cleaning Tips LED Light Switch...
Page 3
Thank you for purchasing a FORNO product. Please read the entire instruction manual before operating your new appliance for the first time. Whether you are an occasional user or an expert , it will be beneficial to familiarize yourself with the safety practices, features, operation and care recommendations of your appliance.
Page 4
30-Day Cosmetic Warranty The Purchaser must inspect the product at the time of delivery. Forno warrants that the Product is free from manufacturing defects in materials and workmanship for a period of thirty (30) days from date of the original retail purchase of the Product.
DAMAGES CAUSED BY THE USE, MISUSE OR INABILITY TO USE THIS PRODUCT, REGARDLESS OF THE LEGAL THEORY ON WHICH THE CLAIM IS BASED, AND EVEN IF FORNO HAS BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES. NOR SHALL RECOVERY OF ANY KIND AGAINST FORNO BE GREATER IN AMOUNT THAN THE PURCHASE PRICE OF THE PRODUCT SOLD BY FORNO AND CAUSING THE ALLEGED DAMAGE.WITHOUT PREJUDICE TO THE FOREGOING, PURCHASER ASSUMES ALL RISK AND...
Page 6
Consumer information Range Safety Your safety and the safety of others are very important. We have provided many important safety messages in this manual and on your appliance. Always read and obey all safety messages. This is a safety alert symbol. It will alert you to potential personal or property safety hazards. Obey all safety messages to avoid any property damage, personal injury or death.
Make sure the anti-tip bracket is installed. Range back panel Slide range forward. Make sure the anti-tip bracket is securely attached to the wall behind the range. Anti-tip bracket WARNING This product can expose you to chemicals including carbon monoxide, which is known to the State of California to cause developmental harm.
Page 8
3. Any adjustment and service should be performed only by a qualified gas range installer or service technician. Do not attempt to repair or replace any part of your range unless it is specifically recommended in this manual. 4. Your range is shipped from the factory set for use with natural gas or propane (LP) gas. It can be converted for use with either.
Page 9
WARNING DO NOT carry or lift the cooking range by the oven door handle or the control panel! CORRECT INCORRECT INCORRET WARNING Never pour cold water to hot surfaces in a hot oven. The steam created could cause serious burns or scalding and the sudden change in temperature can damage the enamel in the oven. WARNING Cook food thoroughly to help protect against foodborne illness.
Page 10
WARNING COOKTOP SAFETY INSTRUCTIONS Never leave the surface burners unattended at medium or high heat settings. Foods, especially oily foods, may ignite resulting in fire that could spread to surrounding cabinets. Never leave oil unattended while frying. If allowed to heat beyond its smoking point, oil may ignite resulting in fire that may spread to surrounding cabinets.
Page 11
Features of Your Range 8 burners 6 burners 5 burners Oven Vents Cooktop Burner Grates Griddle (on some models) LED Light Switch Control Panel Rotisserie Convention Fan Control Panel Oven Lights Oven/Broil Burner Kick Panel Leveling System Not all features are on all models.Appearance may vary. Wok Support...
Page 12
Installation Instructions Before using your range 1. Remove all packaging material. 2. Check to make sure you have all of the accessories listed below FFSGS6460-30 17 sets 0.46, 0.9, 1.39, 1.19, FFSGS6460-36 20 sets LPG injector (*1.12 only for 48")
YOU NEED TOOLS FOR INSTALLATION. (not supplied with the range) Tape measure Screwdriver Wrench Socket wrench Allen key &Pencil Protective Adjustable Hammer Adjustable Drill gloves wrench pliers Door Handle Installation The door handle is not preinstalled. Find it in the front side of the whole package.
Cooktop Burner Grates Installation Remove the packing materials from the cooktop burner grates. Place the burner grates to the right position. Pay attention to the middle right grates as illustrated, as the thicker side should be in the left. Put the griddle (only for FFSGS6460-48) and the wok support to the burner(s) you like to cook.
this cooking range is equipped with a three-prong (grounding) plug for your protection against shock hazard and should be plugged directly into a properly grounded three-pronged receptacle. cut or removes the grounding prong from the plug. Label all wires prior to disconnection when servicing controls. Wiring errors can cause improper and dangerous operation.
Electric Power Supply Requirements Recommended power outlet area 34" (866) 46" (1169) 28" (715) For reference only, please refer to the real object. Pressure Regulator Since service pressure may fluctuate with local demand, every gas cooking range must be equipped with a pressure regulator on the incoming service line for safe and efficient operation.
Product Dimensions and Cabinets FFSGS6460-30 FFSGS6460-36 FFSGS6460-48 This range may be installed directly adjacent to existing countertop-height cabinets (36" or 91.5 cm from the floor).To achieve the best look, the cooktop should be level with the cabinet countertop. This can be accomplished by raising the unit using the adjustment spindles on the...
Page 18
1/ Remove the two screws in the back of the range. 2/ Install the wall-against mat instead.
Exhaust Hood Installation The bottom of the hood should be 30" min. to 36" above the countertop. This would typically result in the bottom of the hood being 66" to 72" above the floor. These dimensions provide safe and efficient operation of the hood. After Installation: 1.
Page 22
The conversion is not completed if all 8 steps have not been concluded properly. Before performing the gas conversion, locate the package containing the replacement nozzles shipped with every range. STEP 1: Pressure Regulator To access the gas regulator, pull the range away from the cabinet wall. The gas regulator is located at the bottom back left corner of the range.
Page 23
COOKTOP BURNERS ORIFICE FOR NATURAL GAS (NG) A. 20,000BTU & LIQUID PROPANE (LP) 1.38 x 2 (OUTER) 0.75 x 1 (CENTER) 0.9 x 2 (OUTER) 0.46 x 1 (CENTER) Model:FFSGS6460-30 Model:FFSGS6460-36...
Page 24
Remove 2 screws which holding the nozzle bracket and locate the nozzle. Replace with oven burner nozzle, size 1.32mm and tighten. Replace the nozzle bracket, aligning the new nozzle into the air shutter of the oven burner. Repeat upon steps for 18”oven (48" ranges only). Model:FFSGS6460-36 Model:FFSGS6460-30 Model:FFSGS6460-48 Oven 1.39 1.39 1.39...
Page 25
Using a 5/8”or 19mm open wrench, remove the gas line from the nozzle holder. Using a ½”open wrench, remove the nozzle from the orifice holder. Replace with 0.94 mm oven broiler nozzle. Model:FFSGS6460-30 Model:FFSGS6460-36 Model:FFSGS6460-48 Broil 1.19 1.19 1.19 STEP 5: Gas Valve a.
Page 26
STEP 7: Air Shutter Oven Burner (no necessary) The air shutter for the oven burner may need adjustment, especially if the unit has been converted for use with LP. The approximate flame height at the oven burner is one inch (distinctive inner blue flame).
Gas Supply Connection All connections to the gas piping must be wrench-tightened. Do not overtighten or allow pipes to turn when tightening. When all connections have been made, check that all range controls are in the “OFF” position and turn on the main gas supply valve. If a flexible metal connector is being used, verify it is not kinked, then attach the gas supply line to the regulator on the range.
Heat Settings: Ignites the burners. Simmer Melting small quantities, steaming rice, warming food, melting chocolate or butter. Melting large quantities. Low-Medium Low-temperature frying, simmering large quantities, heating milk, cream sauces, gravies. Medium Sautéing and browning, braising, pan-frying, maintaining slow boil on large quantities. Medium-Hi High-temperature frying, pan boiling, maintaining slow boil on large quantities.
Start low and don't overheat! - You might get the urge to turn your burners up to full blast the first time you use the FORNO grill/griddle, but don't! Burners only need to be set to 1/3 to 1/2 power to heat the grill/griddle to over 500 degrees.
Some ranges are equipped with an automatic rotisserie for roasting. The rotisserie feature allows for an even cooking and all-over browning of the meat while preventing the meat from cooking in its rendered grease. The rotisserie will turn the meat allowing it to baste itself while roasting.
Convection Roast The convection fan circulates the heated air evenly over and around the food. Using a broiler pan, heated air will be circulated over the around the food being roasted. The heated air seals in juices quickly for a moist and tender product, while at the same time creating a rich golden brown exterior. When convection roasting, it is important that you use the broiler pan for best convection roasting results.
If it's the case, remove them from, clean them thoroughly and remove any excess of water. Forno is not responsible for any maintenance related issues. Control knobs Using a damp cloth, wipe with a mild detergent or spray degreaser;...
Page 33
Troubleshooting Tips Before you call for service Check that power is on. Range does not operate Check that electrical power to range and home circuit breaker is on. Burners Do Not Light Or Spark Electrical plug is not plugged into a live power outlet. Randomly Gas supply not turned on.
Page 34
Incorrect cookware or cookware of improper size being used. Racks in the wrong position. See the Baking or Roasting section. Use a foil tent to slow down browning during roasting. Food Does Not Broil Properly This model is designed for closed door broiling only. Close the door.
PLEASE READ BEFORE USING YOUR OVEN For Forno Commercial Style Ranges Models: FFSGS6444, FFSGS6356, FFSGS6460, FFSGS6387, FFSGS6439, FFSGS6325 Useful information for your oven: • This oven is very powerful. • To avoid burns, please use oven mitts when manipulation oven racks and be careful not to touch the oven door when in use.
