Figure 3. Arduino connectors board top view
GPIO LED
Camera
module
connector
Buzzer
LCD touch display
connector
Figure 4. Arduino connectors board bottom view
Arduino Uno extension connector
Arduino Uno
extension connector
Arduino Uno extension connector
2022.9.13
6
Rev 1.30
