AT-START-F403 User Manual
Get started with AT32F403ZGT6
Introduction
AT-START-F403 is designed to help you explore the high-performance features of the 32-bit
®
microcontroller, AT32F403 embeded with ARM Cortex
-M4 core with FPU, and help develop your
applications.
AT-START-F403 is an evaluation board based on AT32F403ZGT6 chip with LED indicators,
TM
buttons, an USB micro-B connector, Arduino
Uno R3 extension connector and an expanded 16
MB SPI Flash memory. This evaluation board embeds debugging/programming tool AT-Link-EZ
without the need of other development tools.
2019.12.25
1
Rev 1.3
www.arterytek.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for ARTERY AT-START-F403
Summary of Contents for ARTERY AT-START-F403
- Page 1 AT-START-F403 User Manual Get started with AT32F403ZGT6 Introduction AT-START-F403 is designed to help you explore the high-performance features of the 32-bit ® microcontroller, AT32F403 embeded with ARM Cortex -M4 core with FPU, and help develop your applications. AT-START-F403 is an evaluation board based on AT32F403ZGT6 chip with LED indicators,...
-
Page 2: Table Of Contents
AT-START-F403 User Manual Contents Features ........................5 Conventional terms ....................6 Quick start ......................7 Get started........................ 7 Toolchains supporting AT-START-F403 ..............7 Hardware and layout ..................... 8 Programming and debugging ................. 10 4.1.1 Embedded AT-Link-EZ ....................10 ® 4.1.2 20-pin ARM standard JTAG connector .............. - Page 3 AT-START-F403 User Manual List of tables Table 1. ON/OFF definition ........................6 Table 2. Boot mode selection jumper setting ..................12 Table 3. USB and SPIM jumper setting ..................... 13 Table 4. 0 Ω resistor setting ....................... 14 Table 5. Arduino Uno R3 extension connector pin definition ............
- Page 4 AT-START-F403 User Manual List of figures Figure 1. Hardware block diagram ...................... 8 Figure 2. Top layer ..........................9 Figure 3. Bottom layer ......................... 9 Figure 4. Schematic (AT-Link-EZ) ..................... 17 Figure 5. Schematic (microcontroller) ....................18 Figure 6. Schematic (power supply and peripherals) ................ 19 Figure 7.
-
Page 5: Features
− The on-board AT-Link-EZ can be used for programming and debugging. (AT-Link-EZ is a simplified version of AT-Link, and does not support offline mode) − If AT-Link-EZ is separated from this board by bending over along the joint, AT-START-F403 can be connected to an independent AT-Link for programming and debugging ... -
Page 6: Conventional Terms
AT-START-F403 User Manual Conventional terms Table 1 shows the definitions of some conventional terms used in this document. Table 1. ON/OFF definition Conventional terms Definition Jumper JPx ON Jumper installed Jumper JPx OFF Jumped not installed Short by solder or 0Ω resistor... -
Page 7: Quick Start
JP8 one-piece jumper is connected to the USB on the right. 2. Connect the AT-START-F403 board to the PC through a USB cable (Type A to micro-B), and the board will be powered via AT-Link-EZ USB connector CN6. LED1 (red) is always on, and other three LEDs (LED2 to LED4) start to blink in turn. -
Page 8: Hardware And Layout
AT-START-F403 User Manual Hardware and layout AT-START-F403 board is designed around an AT32F403ZGT6 microcontroller in LQFP144 package. Figure 1 shows the connections between AT-Link-EZ, AT32F403ZGT6 and their peripherals (buttons, LEDs, USB, SPI Flash memory and extension connectors) Figure 2 Figure 3 show these features on the AT-Link-EZ and AT-START-F403 board. -
Page 9: Figure 2. Top Layer
AT-START-F403 User Manual Figure 2. Top layer AT32F403ZGT6 LQFP144 I/O extension connector External 7~12V power SPI Flash memory Arduino Uno extension connector User LED Boot mode selection jumper USART1 connector 20-pin ARM standard JTAG connector HSE 8 MHz crystal AT-Link-EZ... -
Page 10: Programming And Debugging
3.3 V voltage regulator (U2) on the board. The 5 V pin of J4 or J7 can also be used as an input power source. The AT-START-F403 board must be powered by a 5 V power supply unit. -
Page 11: Led Indicators
AT-START-F403 User Manual LED indicators Power LED1: red indicates that the board is powered by 3.3 V User LED2: red, connected to the PD13 pin of AT32F403ZGT6 User LED3: white, connected to the PD14 pin of AT32F403ZGT6 User LED4: green, connected to the PD15 pin of AT32F403ZGT6... -
Page 12: Boot Mode Selection
AT-START-F403 User Manual Boot mode selection At startup, three different boot modes can be selected by means of the pin configuration. Table 2. Boot mode selection jumper setting Boot mode selection pins Jumper Setting BOOT1 BOOT0 Boot from the internal Flash memory with the jumper... -
Page 13: Usb Device
AT-START-F403 User Manual USB device AT-START-F403 board supports USB full-speed device communication through an USB micro-B connector (CN1). V can be used as 5 V power supply of AT-START-F403 board. When using USB, the JP8 one-piece jumper, as shown in... -
Page 14: Ω Resistors
AT-START-F403 User Manual 0 Ω resistors 4.10 Table 4. 0 Ω resistor setting Resistors State Description When JP3 is OFF, 3.3V is connected to the microcontroller to provide power supply (Microcontroller power When JP3 is OFF, 3.3V allows an ammeter to be connected... -
Page 15: Extension Connectors
The I/O ports of AT32F403ZGT6 are 3.3 V compatible with Arduino Uno R3, but 5V incompatible. Note 2: Set R17 OFF if it is needed to supply power through the J3 pin 8 AREF of AT-START-F403 to the of AT32F403ZGT6 by means of Arduino Uno R3 daughter board. -
Page 16: 4.11.2 Lqfp144 I/O Extension Connector
4.11.2 LQFP144 I/O extension connector The extension connectors J1 and J2 can connect the AT-START-F403 to external prototype/packing board. The I/O ports of AT32F403ZGT6 are available on these extension connectors. J1 and J2 can also be measured with the oscilloscope, logic analyzer or voltmeter probe. -
Page 17: Schematic
AT-START-F403 User Manual Schematic Figure 4. Schematic (AT-Link-EZ) 2019.12.25 Rev 1.3... -
Page 18: Figure 5. Schematic (Microcontroller)
AT-START-F403 User Manual Figure 5. Schematic (microcontroller) 2019.12.25 Rev 1.3... -
Page 19: Figure 6. Schematic (Power Supply And Peripherals)
AT-START-F403 User Manual Figure 6. Schematic (power supply and peripherals) 2019.12.25 Rev 1.3... -
Page 20: Figure 7. Schematic (Extension Connectors)
AT-START-F403 User Manual Figure 7. Schematic (extension connectors) 2019.12.25 Rev 1.3... -
Page 21: Revision History
AT-START-F403 User Manual Revision history Document revision history Table 6. Date Revision Changes 2018.1.15 Initial release 1. Modified 5V power selection and canceled 5V power selection jumper 2. Modified LED color, and changed the connecting sequence of PD13~15 to 2018.3.19 LED2~4 3. - Page 22 Purchasers hereby agrees that Artery’s products are not authorized for use as, and purchasers shall not integrate, promote, sell or otherwise transfer any Artery’s product to any customer or end user for use as critical components in (a) any medical, life saving or life support device...
