Enviro Cube Unpacking & Setup Instructions

Cube Unpacking & Setup Instructions

Contents

• Black sea ember wool (x1)
• Rear Vent Top Cover (x1)
• Unpacking & Setup Guide
(x1)
1. Remove the crate and packaging from the
unit. The unit is attached to the pallet and
will be removed at a later step.
2. Remove the safety screen from the front of
the unit. Lift the screen up to disengage the
hooks and pull away from the unit. Refer to
Figure 1.
3. The rear panel is attached to the unit using
four (4) #8 T20 screws, two (2) on each side
near the back of the unit. Detach these
screws and remove the back panel. Refer to
Figure 2.
Figure 1: Safety Screen Removal
Figure 2: Back Cover Removal
