- Page 1 Spare Parts Customer Support www.argos-support.co.uk 0345 640 2020 Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 14/05/21...
-
Page 2: Care And Maintenance
BEFORE LIFTING DON'T LIFT WITHOUT MATTRESS Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered office: 33 Holborn, London, EC1N 2HT, registered number: 03261722 (England and Wales). Both companies are subsidiaries of J Sainsbury's plc. - Page 3 Fittings (Shown to scale) 8x25mm Bolt x 18 8x30mm Bolt x 22 4x45mm Wood screw x 8 Nut x 6 12mm Spring washer x 24 17mm Flat washer x 46 8x45mm Bolt x 6...
- Page 4 Parts INSIDE Side rail x 2 (4'6-1930 × 310mm) INSIDE (5'-2030 × 310mm) Headboard (4'6-1460 × 1075mm) (5'-1610 ×1075mm) INSIDE Footboard Hinge Mechanism (x 1 pair) (4'6-1460 × 475mm) NOTE: PISTON ATTACHED (5'-1610 × 475mm) Foot x 4 (25mm) Fabric base x1 (4'6-1960 ×...
- Page 5 Parts Double slat caps x 14 (4'6-55mm) Bentwood slats x28(4'6-675 x 9 x 53mm) Double slat caps x 15 (5'-55mm) Bentwood slats x30(5'-750 x 9 x 53mm) Mattress support bracket x 2 Stretcher x 1 (4'6-1390 x 25mm) (5'-1540 x 25mm) Single slat caps x 28 (4'6-55mm) 16 Ottoman frame centre support Single slat caps x 30 (5'-55mm)
-
Page 6: Tools Required
Tools required Ruler/tape Allen key (Supplied) measure (Not Supplied) Spanner (Supplied) Phillips screwdriver (small & medium) (Not Supplied) Box spanner (Supplied) - Page 7 8x25mm Bolt x 18 8x30mm Bolt x 22 4x45mm Wood screw x 8 Nut x 6 8x30mm Bolt x 12 17mm Flat washer x 12 12mm Spring washer x 12 12mm Spring washer x 24 17mm Flat washer x 46 8x45mm Bolt x 6 5mm Allen key x 1...
- Page 8 4x45mm Wood screw x 4 Frame must be square...
- Page 9 Turn Product 4x45mm Wood screw x 4...
- Page 10 Turn Product 8x30mm Bolt x 10 17mm Flat washer x 10 5mm Allen key x 1 Opening from right side Important Use fixing holes with blue stickers Headboard fixing holes position Headboard fixing holes position Headboard Headboard BLUE BLUE Footboard fixing holes position Footboard fixing holes position Footboard Footboard...
- Page 11 Turn Product 8x30mm Bolt x 10 17mm Flat washer x 10 5mm Allen key x 1 Opening from left side Important Use fixing holes with red stickers Headboard fixing holes position Headboard fixing holes position Headboard Headboard Footboard fixing holes position Footboard fixing holes position Footboard Footboard...
- Page 12 8x25mm Bolt x 18 17mm Flat washer x 18 12mm Spring washer x 12 5mm Allen key x 1 Turn Product...
- Page 13 Nut x 6 17mm Flat washer x 6 8x45mm Bolt x 6 5mm Allen key x 1 Spanner x 1 Box spanner x 1 Important Two people required. Frame to be fully supported at all times.
- Page 14 Repeat 4'/4'6 Repeat...
