- Page 1 Jenson Mirror 940/0371 Spare Parts Customer Support Visit: www.argos-support.co.uk Call: 0345 640 2020 Email: Help@ClickSpares.co.uk Call: 0330 016 1114 Issue 1 - 08/12/20...
- Page 2 Safety Important - Please read these instructions fully before starting assembly • WARNING: To prevent • Warning: This unit weighs possible overbalancing this unit approximately 34kgs. must be secured to a wall using Please lift with care. the 2 overbalance protector kits •...
- Page 3 Cabinet Panels Please remove protective film from any gloss panels 137.1 x 28.8cm 137.1 x 28.8cm 135.3 x 58.7cm 55.6 x 35.5cm 59.5 x 29cm 54.9 x 14cm 56.1 x 5.8cm 54.9 x 8.7cm...
- Page 4 Drawer Panels Note: the internal drawer panels are grey 11 26 x 6.8cm 55.6 x 9.6cm 10 26 x 6.8cm 12 52.85 x 6.8cm 13 53.95 x 25.1cm...
-
Page 5: Table Of Contents
Fittings Use these drawings to correctly identify the fittings Bag 1 x 16 x 16 x 16 x 25 Bag 2 Bag 4 Bag 3 x 24 x 18 Bag 5... - Page 6 Fittings Shoe Boys Tools Only used for drilling walls...
-
Page 7: Bag 1
Fitting Ball Bearing Runners www.youtube.com/watch?v=yG4x�JJeSg Bag 1 x 16 x 16 x 16 x 25 2nd hole Finished front edge Finished front edge 2nd hole... - Page 8 x 12...
-
Page 9: Bag 4
Bag 4 Shoe Boys IMPORTANT: Carefully snap off these fittings from the Shoe Boys... - Page 10 x 12 x 12 Finished front edge Finished front edge Finished Finished front edge front edge Finished front edge Finished front edge IMPORTANT: Support panels until other end panel is fitted in the next step Finished front edge...
- Page 11 Finished front edge Finished front edge Only use 1 Screw to fit each Bracket...
-
Page 12: Bag 5
Bag 5 Finished front edge... - Page 13 Squaring up a Chest and fitting the Back Panel www.youtube.com/watch?v=FeaI6541z7o A = B Make sure measurement A and B are the same before attaching the back panel x 25...
- Page 15 WARNING! In order to prevent overturning this product must be used with the 2 wall attachment devices provided See the next section for a guide to wall mounting and fixings Slide the Brackets against the wall. Fit the 2nd screws supplied with the Brackets into the underside of the Top panel.
- Page 16 A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
- Page 17 Bag 4 Warning: Glass! Handle with care Shaped front edge Shoe Boys IMPORTANT: Carefully snap off the rest of the fittings from the Shoe Boys to use later...
- Page 18 Bag 3 x 24 x 18 Finished front edge...
- Page 19 Finished front edge IMPORTANT: Support this panel until the Shoe Boy is fitted in the next step...
- Page 21 Door Stop IMPORTANT: Lift and position the Doors so that the Door Stops are fitted between the 2 lugs at the top of the Shoe Boys...
- Page 22 Slot the Divider panels down into 1 of the 3 positions shown Finished front edge Finished front edge Finished front edge...
- Page 23 Drawer Push adjustment. Finely adjust the Magnetic Catches to suit your requirements. Just a 1/4 of a turn can make a difference.
- Page 24 Drawer Assembly Bag 2 Standard Drawer Box Assembly https://www.youtube.com/watch?v=HclfJdkm-Lg Warning: Glass! Handle with care...
- Page 25 Ensure the drawer base sits flush by turning the shelf studs clockwise or anti-clockwise...
- Page 27 Fitting Ball Bearing Runners www.youtube.com/watch?v=yG4x�JJeSg Warning: Use a screwdriver to position the runners as they could have sharp edges Slide both the runners forward and locate the drawer sides between them, lining up the holes in the drawer sides with the 2nd 'threaded' holes in the runners. Working from the inside of the drawer, insert 2 screws through the drawer sides and out into the 2nd threaded hole in the runner.
- Page 28 Adjust the Drawer Push Finely adjust each Door Push to suit your requirements. Just a 1/4 of a turn can make a difference. Assembly is complete Please remove any blue protective film from panel edges and clear protective film from panel surfaces and clean the mirror ALR3703...
