Hallingford
802/6622 767/2565
Spare Parts
Visit: www.argos-support.co.uk
Email: Help@ClickSpares.co.uk
Call: 0330 016 1114
930/0842
856/7985
Customer Support
Call: 0345 640 2020
Issue 4 - 02/09/20

Advertisement

loading
Need help?

Need help?

Do you have a question about the Hallingford 802/6622 and is the answer not in the manual?

Questions and answers

Summary of Contents for Argos Hallingford 802/6622

  • Page 1 Hallingford 802/6622 767/2565 930/0842 856/7985 Spare Parts Customer Support Visit: www.argos-support.co.uk Call: 0345 640 2020 Email: Help@ClickSpares.co.uk Call: 0330 016 1114 Issue 4 - 02/09/20...
  • Page 2: Care Advice

    Safety Important - Please read these instructions fully before starting assembly • WARNING: To prevent • Warning: This unit weighs possible overbalancing this unit approximately 14kgs. must be secured to a wall using Please lift with care. the overbalance protector kit •...
  • Page 3: Cabinet Panels

    Cabinet Panels 1 55.6 x 37.2cm 2 55.6 x 37.2cm 3 37.5 x 39.6cm 4 34.1 x 6cm 5 53.5 x 36.6cm Drawer Panels Note: the internal drawer panels are grey 6 36 x 16cm 7 35 x 13cm 8 35 x 13cm 10 30.85 x 13cm 9 31.95 x 34.7cm...
  • Page 4 Fittings Use these drawings to correctly identify the fittings Bag 1 x 12 x 20 Bag 2 x 12...
  • Page 5 Fitting Ball Bearing Runners www.youtube.com/watch?v=yG4xtiJJeSg Bag 1 x 12 x 12 x 20 2nd hole Finished front edge Finished front edge 2nd hole...
  • Page 7 Finished front edge...
  • Page 8 Finished front edge Only use 1 Screw to fit the Bracket Finished front edge...
  • Page 9 Finished front edge Squaring up a Chest and fitting the Back Panel www.youtube.com/watch?v=FeaI6541z7o A = B Make sure measurement A and B are the same before attaching part 5...
  • Page 10 x 20...
  • Page 11 WARNING! In order to prevent overturning this product must be used with the wall attachment device provided See the next section for a guide to wall mounting and fixings Slide the Bracket against the wall. Fit the 2nd screw supplied with the Bracket into the underside of the Top panel.
  • Page 12: A Guide To Wall Mounting & Fixings

    A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit.
  • Page 13: Drawer Assembly

    Drawer Assembly Bag 2 x 12 x 12 Drawer Assembly www.youtube.com/watch?v=InNBV_uuMmo...
  • Page 16 Fitting Ball Bearing Runners www.youtube.com/watch?v=yG4xtiJJeSg Warning: Use a screwdriver to position the runners as they could have sharp edges Starting with the Bottom Drawer and working your way up, slide both its Runners forward and locate the Drawer Sides between them, lining up the holes in the Drawer Sides with the 2nd 'threaded' holes in the Runners.
