Summary of Contents for Argos Emberton 927/5788
- Page 1 Emberton Spare Parts Customer Support 0345 640 2020 www.argos-support.co.uk Help@ClickSpares.co.uk 0370 112 1928 Issue 1 - 27/04/20...
- Page 2 ●Regularly check and ensure that all bolts and fittings are tightend properly. ●Maximum user weight 100 kgs. Sainsbury's Argos is a trading name of both: Argos Limited, Registered office: 489-499 Avebury Boulevard, Milton Keynes, United Kingdom, MK9 2NW, registered number: 01081551 (England and Wales); and Sainsbury's Supermarkets Limited, Registered office: 33 Holborn, London, EC1N 2HT, registered number: 03261722 (England and Wales).
- Page 3 (1040 x 57mm) Left headboard foot (726 x 218mm) Side panel x2 (1040 x 57mm) Right headboard foot Drawer bottom x4 (497 x 295mm) (910x 70mm) Slats x12 Drawer Front x2 (686 x 183mm) Headboard Panel (874 x 588mm) Headboard rail (874 x 89mm) (500 x 140mm) Drawer right side x2...
- Page 4 Fittings Large wooden dowel x 38 3.5 x 16mm Screw x34 10 x 40mm 4.5 x 50mm Screw x 3 4 x 35mm Screw x 36 1/4 x 100mm Bolt x 4 Cab. 17 Headless bolt 1/4 x 70mm x 4 Nut 1/4 x 4 Half moon nut 1/4 x 4 Large Metal dowel x 8...
-
Page 5: Tools Required
Fittings Fittings Large Locking nut x 16 Plastic bracket x 10 Drawer handle x 4 Thin wooden dowel x 16 8 x 35mm M4 x 25 bolt x 4 4 x 30mm Screw x 18 Small Metal dowel x 8 Drawer left side runner x2 Right side runner x2 Left side runner x2... - Page 6 Large Locking nut x 16 Plastic bracket x 10 Large wooden dowel x 38 3.5 x 16mm Screw x34 10 x 40mm Drawer handle x 4 Thin wooden dowel x 16 8 x 35mm 4.5 x 50mm Screw x 3 4 x 35mm Screw x 36 4 x 30mm Screw x 18 M4 x 25 bolt x 4...
- Page 7 Plastic bracket x 10 Repeat Small hammer...
- Page 8 Option - 01 4 x 30mm Screw x 2 Make sure holes are positioned as shown!
- Page 9 Option - 02 4 x 30mm Screw x 2 Make sure holes are positioned as shown!
- Page 10 Option - 01 4 x 30mm Screw x 8...
- Page 11 Option - 02 4 x 30mm Screw x 8...
- Page 12 Large Metal dowel x8...
- Page 13 Large Locking nut x 8...
- Page 14 1/4 x 100mm Bolt x 4 Cab. 17 Half moon nut 1/4 x 4 Allen Key x 1...
- Page 15 Headless bolt 1/4 x 70mm x 4 MAKE SURE TO SCREW THE HEADLESS BOLT ALL THE WAY...
- Page 16 Wascher x 4 Spanner x1 Nut 1/4 x 4...
- Page 17 Option - 01 4.5 x 50mm Screw x 3 Option - 02...
- Page 18 6 x 7mm Screw x 8 Right side runner x 2 Left side runner x 2 Option - 01 Correct position of the screws. Option - 02 Correct position of the screws.
- Page 19 Option - 01 3.5 x 16mm Screw x 20 ALIGN UPWARDS...
- Page 20 12.1 Option - 02 3.5 x 16mm Screw x 20 ALIGN UPWARDS...
- Page 21 Thin wooden dowel x16 8 x 35mm Repeat Repeat Repeat...
- Page 22 Small Metal dowel x8 Large Locking nut x8 Repeat Repeat...
- Page 23 4 x 30mm Screw x 8 Repeat Repeat...
- Page 24 Drawer handle x 4 M4 x 25 Screw x 4 Rotate Repeat Product...
- Page 25 Drawer right side runner x2 Drawer left side runner x2 3.5 x 16mm Screw x 12 Correct position of the screws. IN FLUSH Repeat Rotate Product...
- Page 26 3.5 x 16mm Screw x 12 First, align the drawers using the alignment screws shown below, then, add the extra screws as per below drawing. Extra Screws Alignment screws Repeat OPTION - 01 OPTION - 02...
- Page 27 82mm Spacer x2 4 x 35mm Screw x 36...
