Summary of Contents for Argos Jenson
- Page 1 JENSON Gloss 940/0508 938/0226 Spare Parts Customer Support Visit: www.argos-support.co.uk Call: 0345 640 2020 Email: Help@ClickSpares.co.uk Call: 0330 016 1114 Issue 1 - 11/12/20...
-
Page 2: Care Advice
Safety Important - Please read these instructions fully before starting assembly • WARNING: To prevent • Warning: This unit weighs possible overbalancing this unit approximately 33kgs. must be secured to a wall using Please lift with care. the 2 overbalance protector kits •... -
Page 3: Cabinet Panels
Cabinet Panels Please do NOT remove any protective film until after assembly 42.3 x 42.9cm 42.3 x 42.9cm 42.3 x 41.5cm 57.7 x 6.0cm 117.8 x 36.5cm 57.7 x 41.4cm 57.7 x 39.6cm 120.3 x 45.0cm 59.6 x 32.7cm... - Page 4 Fittings Use these drawings to correctly identify the fittings Bag 1 x 14 x 22 x 14 x 10 Tools Only used for drilling walls...
- Page 5 Bag 1 x 14 x 22 x 14 x 10 Finished front edge Finished front edge...
- Page 6 Finished front edge Finished front edge Finished front edge Finished front edge...
- Page 8 Finished front edge...
- Page 9 Finished front edge Finished front edge...
- Page 11 Squaring up a Chest and fitting the Back Panel www.youtube.com/watch?v=FeaI6541z7o The Back panel must be flush with the Back Rail. A = B Make sure measurement A and B are the same...
- Page 12 x 10 Only use 1 Screw to fit each Bracket Finished front edge...
- Page 13 IMPORTANT: The Back panel must slot into the groove in the Top panel Finished front edge...
- Page 15 WARNING! In order to prevent overturning this product must be used with the 2 wall attachment devices provided See the next section for a guide to wall mounting and fixings Slide the Brackets against the wall. Fit the 2nd screws supplied with the Brackets into the underside of the Top panel.
-
Page 16: A Guide To Wall Mounting & Fixings
A Guide to Wall Mounting & Fixings Important: When drilling into walls always Important note: check that there are no hidden wires or pipes etc. If plastic wall plugs Make sure that the screws and wall plugs being used are supplied with your are suitable for supporting your unit. - Page 18 Pre-mounted Hinge Fitting & Adjustment https://www.youtube.com/watch?v=b4NeCGnpjP8 Press the screws into the holes in the panels When the hinges have been pushed in, tighten up their screws Repeat for both doors...
- Page 19 Pre-mounted Hinge Fitting & Adjustment https://www.youtube.com/watch?v=b4NeCGnpjP8 Adjust the Door if required Height adjustment. Loosen screws A on Hinge Plates and move Door up or down as required. Retighten screw A. Forward and Back adjustment. Loosen screw B on Hinge Plate and move door in or out as required.
- Page 20 Assembly is complete Please remove any blue protective film from panel edges and clear protective film from panel surfaces ALR3719...
